- Page 1 AT-TQ6602 Enterprise-class Wi-Fi 6 802.11ax Indoor Wireless Access Point with 2.4GHz and 5GHz Radios Management Software User’s Guide 613-002960 Rev.B...
- Page 2 * Neither the name of Allied Telesis, Inc. nor the names of the respective companies above may be used to endorse or promote products derived from this software without specific prior written permission.
- Page 3 Telesis, Inc. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesis, Inc. has been advised of, known, or should have known, the possibility of such damages.
-
Page 5: Table Of Contents
Contents Preface ....................................11 Safety Symbols Used in this Document ........................12 Contacting Allied Telesis ............................... 13 Chapter 1: Getting Started ..............................15 Features ..................................16 Hardware Features ..............................16 Software Features ..............................16 Wi-Fi 6 (IEEE802.11ax) ............................16 Hybrid Operation (Multi-Channel)...........................16 Security and Encryption ............................17 Frequency Range and Bandwidth for the 2.4GHz Radio .................. - Page 6 AT-TQ6602 Access Point User’s Guide VAP Introduction................................64 VAP Guidelines ..............................64 Configuring Basic VAP Parameters..........................65 Authenticating Wireless Clients with an External RADIUS Server ................69 Configuring VAP Security ..............................73 No Security ................................73 WPA Personal (Pre-Shared Key) ...........................74 WPA Enterprise ..............................76 Configuring VAP Fast Roaming.............................81 Configuring Advanced VAP Settings ..........................84...
- Page 7 List of Figures Figure 1: Log On Window..........................24 Figure 2: Sample Management Window ......................26 Figure 3: Main Menu Button ..........................27 Figure 4: Network DHCP Window ........................32 Figure 5: Network Static IP Address Window....................34 Figure 6: Time Window - NTP Option......................36 Figure 7: Daylight Savings Time Settings......................
- Page 8 AT-TQ6602 Access Point User’s Guide Figure 46: Reboot Window ..........................142 Figure 47: Support Window ........................... 143...
- Page 9 List of Tables Table 1. Network DHCP Window ........................33 Table 2. Network Static IP Selection Window ....................35 Table 3. Time Window - NTP Option ......................37 Table 4. Time Window - Manually Option ....................... 40 Table 5. SNMP Window ..........................42 Table 6.
- Page 10 AT-TQ6602 Access Point User’s Guide...
-
Page 11: Preface
Preface This guide contains instructions on how to manage the features of the AT-TQ6602 access point with the web browser management interface. This preface contains the following sections: “Safety Symbols Used in this Document” on page 12 “Contacting Allied Telesis” on page 13... -
Page 12: Safety Symbols Used In This Document
AT-TQ6602 Access Point User’s Guide Safety Symbols Used in this Document This document uses the following conventions. Note Notes provide additional information. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. -
Page 13: Contacting Allied Telesis
guides, software release notes, white papers and data sheets for your product. Warranty - View a list of products to see if Allied Telesis warranty applies to the product you purchased and register your warranty. Allied Telesis Helpdesk - Contact a support representative. - Page 14 AT-TQ6602 Access Point User’s Guide...
-
Page 15: Chapter 1: Getting Started
Chapter 1 Getting Started Here are the sections in this chapter: “Features” on page 16 “Management Tools” on page 19 “Starting the First Management Session” on page 21 “Starting a Management Session” on page 24 “Management Windows” on page 26 ... -
Page 16: Features
AT-TQ6602 Access Point User’s Guide Features This section lists the features of the access point. Hardware Here is a list of hardware features: Features One 2.4GHz radio One 5GHz radio 4x4 MU-MIMO 2.4GHz Internal antennas 4x4 MU-MIMO 5GHz Internal antennas ... -
Page 17: Security And Encryption
Chapter 1: Getting Started Dynamic Host Control Protocol (DHCP) client Network Time Protocol (NTP) client System log Syslog client Autonomous Management Framework (AMF) Guest node Security and Encryption Open system Shared key authentication WPA Personal or Enterprise security with auto, CCMP (AES), or ... - Page 18 AT-TQ6602 Access Point User’s Guide Vista Manager mini with AWC plug-in Autonomous Management Framework (AMF) Security or Security Mini (AMF-Sec mini)
-
Page 19: Management Tools
Chapter 1: Getting Started Management Tools The access points support the following management tools. Web Browser The access point has a web browser management interface for configuring the device from your management workstations. The web browser interface allows you to manage one unit at a time and supports both non-secure HTTP and secure HTTPS management sessions. -
Page 20: Snmpv1, Snmpv2C, And Snmpv3
AT-TQ6602 Access Point User’s Guide SNMPv1, You can use SNMPv1, SNMPv2c, and SNMPv3 to view the parameter settings of the access point. The MIB is available from Allied Telesis SNMPv2c, and website. For instructions on how to configure the access point for SNMP, SNMPv3 see “Configuring SNMPv1, SNMPv2c and SNMPv3”... -
Page 21: Starting The First Management Session
Chapter 1: Getting Started Starting the First Management Session After you install and power on the access point, it queries the subnet on the LAN port for a DHCP server. If a DHCP server responds to its query, the unit uses the IP address the server assigns to it. If there is no DHCP server, the access point uses the default IP address. -
Page 22: Starting The First Management Session Without A Dhcp Server
AT-TQ6602 Access Point User’s Guide 1. Connect one end of a network cable to the LAN port on the access point and the other end to the Ethernet network port on your computer. 2. Change the IP address on your computer to 192.168.1.n, where n is a number from 1 to 254, but not 230. - Page 23 Chapter 1: Getting Started If your network has VLANs, check to be sure that your computer and the access point are connected to ports on the Ethernet switch that are members of the same VLAN. This might require accessing the management software on the switch and listing the VLANS and their port assignments.
-
Page 24: Starting A Management Session
AT-TQ6602 Access Point User’s Guide Starting a Management Session This section explains how to start a management session on the access point from your management workstation, using a web browser. The procedure assumes that the access point has already been assigned an IP address, either manually or from a DHCP server. - Page 25 Chapter 1: Getting Started Note If you use HTTPS management, your web browser might display a warning message stating that the site certificate is invalid. If this occurs, select an appropriate option to continue to the web site. To avoid the message in future management sessions, make the web site a trusted site in your web browser.
-
Page 26: Management Windows
AT-TQ6602 Access Point User’s Guide Management Windows This section has a brief overview of the management windows and menus. The main parts of the management windows are identified in Figure 2. Sub-menu Navigator Main Menu Content Figure 2. Sample Management Window... -
Page 27: Navigation
Chapter 1: Getting Started If the main menu is not displayed, the window might be too small to display the menu and content together. To display the main menu, you can either enlarge the window or click the main menu button, shown in Figure 3. Clicking the main menu button displays the menu over the content window. -
Page 28: Saving And Applying Your Changes
AT-TQ6602 Access Point User’s Guide Saving and Applying Your Changes You need to click the SAVE & APPLY button to save and activate your changes when you are finished configuring the parameters in a management window. The button is located in the bottom of the windows. -
Page 29: Ending Management Sessions
Chapter 1: Getting Started Ending Management Sessions You should always log off when you are finished managing the unit. To log off, select Account > Logout. Click OK at the confirmation prompt. For added security, close your web browser. -
Page 30: What To Configure First
AT-TQ6602 Access Point User’s Guide What to Configure First Here are suggestions on what to configure during the first management session: 1. Set the country code. Refer to “Setting the Country Code Setting” on page 61. Note The country code for units sold in North America, Japan, and Taiwan is preset and cannot be changed. -
Page 31: Chapter 2: Basic Settings
Chapter 2 Basic Settings This chapter contains the following procedures: “Assigning a Dynamic IP Address from a DHCP Server” on page 32 “Assigning a Static IP Address to the Access Point” on page 34 “Setting the Date and Time with the Network Time Protocol (NTP)” on ... -
Page 32: Assigning A Dynamic Ip Address From A Dhcp Server
AT-TQ6602 Access Point User’s Guide Assigning a Dynamic IP Address from a DHCP Server This section explains how to activate the DHCP client so that the access point receives its IP address from a DHCP server on your network. The unit uses the address to communicate with devices on your network, such as management workstations, syslog servers, and RADIUS servers. -
Page 33: Table 1. Network Dhcp Window
- The first or last character cannot be a hyphen. - The access point can have only one hostname. - The default is AT-TQ6602. - If you want the DHCP server to supply the hostname, enable the Get Hostname from DHCP Server option in this window. -
Page 34: Assigning A Static Ip Address To The Access Point
AT-TQ6602 Access Point User’s Guide Assigning a Static IP Address to the Access Point This section explains how to manually assign an IP address to the access point. The unit uses the address to communicate with devices on your network, such as management workstations, syslog servers, and RADIUS servers. -
Page 35: Table 2. Network Static Ip Selection Window
- The first or last character cannot be a hyphen. - The access point can have only one hostname. - The default is AT-TQ6602. Connection Type Select Static IP. Static IP Address Enter the new IP address for the access point. -
Page 36: Setting The Date And Time With The Network Time Protocol (Ntp)
AT-TQ6602 Access Point User’s Guide Setting the Date and Time with the Network Time Protocol (NTP) The access point has a Network Time Protocol (NTP) client for setting its date and time from an Simple Network Time Protocol (SNTP) server on your network or the Internet. -
Page 37: Table 3. Time Window - Ntp Option
Chapter 2: Basic Settings 4. Configure the fields by referring to Table 3. Table 3. Time Window - NTP Option Item Name Description Set System Time Select Network time protocol (NTP) to synchronize the date and time of the product with the NTP server. -
Page 38: Figure 7: Daylight Savings Time Settings
AT-TQ6602 Access Point User’s Guide Table 3. Time Window - NTP Option (Continued) Item Name Description NTP Server Specify the SNTP server using one of the following methods: - IP address (example, 12.34.56.78) - Fully qualified domain name (FQDN) (example, ntp.mydomain.com) -
Page 39: Manually Setting The Date And Time
(Jan 1 00: 00: 00 2018) when the device is reset or powered off. Note Allied Telesis recommends using an SNTP server to set the date and time. For instructions, refer to “Setting the Date and Time with the Network Time Protocol (NTP)” on page 36. -
Page 40: Table 4. Time Window - Manually Option
AT-TQ6602 Access Point User’s Guide 3. Configure the parameters by referring to Table 4. Table 4. Time Window - Manually Option Field Description Set System Time Select Manually. This is the default. Current System Displays the current date and time settings. -
Page 41: Configuring Snmpv1, Snmpv2C And Snmpv3
Chapter 2: Basic Settings Configuring SNMPv1, SNMPv2c and SNMPv3 You can use SNMP to view the settings and client statistics on the access point, and receive traps. Here are the guidelines: You cannot use SNMP to change the settings on the access point. ... -
Page 42: Figure 10: Snmp Window - Snmp Enabled
AT-TQ6602 Access Point User’s Guide Figure 10. SNMP Window - SNMP Enabled 4. Configure the parameters by referring to Table 5. Table 5. SNMP Window Field Description Status Use this option to activate or deactivate the SNMP agent on the access point. The options... - Page 43 Chapter 2: Basic Settings Table 5. SNMP Window (Continued) Field Description Read-Only Specifies the community name. Community Name Note This parameter applies only to SNMPv1 and SNMPv2c. Port Specify the port number for SNMP. The range is 1 to 65535. The default is 1. Restrict the Source Restricts the use of SNMP to specific subnets of SNMP Requests...
- Page 44 AT-TQ6602 Access Point User’s Guide Table 5. SNMP Window (Continued) Field Description Only allow from the Specify management workstations permitted to designated hosts use SNMP to view the device. This parameter or subnets applies only to SNMPv1 and SNMPv2c. Here are guidelines: - You can specify only one value in the field.
-
Page 45: Enabling Or Disabling The Leds
Chapter 2: Basic Settings Enabling or Disabling the LEDs The access point has an Eco Mode. When activated, it turns off the LEDs on the top panel. You might activate the mode when you are not using the LEDS to monitor or troubleshoot the device. The default setting for the LEDs is on. -
Page 46: Configuring Poe Negotiation With Link Layer Discovery Protocol (Lldp)
AT-TQ6602 Access Point User’s Guide Configuring PoE Negotiation with Link Layer Discovery Protocol (LLDP) This feature is applicable when the access point is powered by Power over Ethernet (PoE) and the LAN port is connected to a network device that supports LLDP Media Endpoint Devices (LLDP-MED). -
Page 47: Figure 12: Lldp Window
Chapter 2: Basic Settings Figure 12. LLDP Window 3. Select one of the following from the PoE Negotiation: Enabled: Enables PoE negotiation. The access point transmits the Extended Power Management TLV on the LAN port. Disabled: Disables PoE negotiation. This is the default setting. ... -
Page 48: Enabling Or Disabling The Reset Button
AT-TQ6602 Access Point User’s Guide Enabling or Disabling the Reset Button This section explains how to enable or disable the Reset button on the rear panel of the access point. You use the Reset button to restore the default settings to the device. -
Page 49: Chapter 3: 2.4Ghz And 5Ghz Radios
Chapter 3 2.4GHz and 5GHz Radios This chapter has the following procedures: “Configuring the Radios” on page 50 “Displaying Radio Status” on page 57 “Dynamic Frequency Selection (DFS)” on page 60 “Setting the Country Code Setting” on page 61 ... -
Page 50: Configuring The Radios
AT-TQ6602 Access Point User’s Guide Configuring the Radios The radio settings are divided into two groups: “Configuring Basic Radio Settings” next “Configuring Advanced Radio Settings” on page 53 Configuring To configure the basic settings for Radio1 or Radio2, perform the following... -
Page 51: Table 6. Basic Radio Settings Window
Chapter 3: 2.4GHz and 5GHz Radios Table 6. Basic Radio Settings Window Field Description Country Code Select the country code that applies to your country or region. The country code ensures that the device operates in compliance with the codes and regulations of your region or country. - Page 52 AT-TQ6602 Access Point User’s Guide Table 6. Basic Radio Settings Window (Continued) Field Description Mode Select the communications protocol for Radio2 from (Radio2) the pull-down menu. The selections are listed here: - IEEE 802.11a: The access point accepts 802.11a clients.
-
Page 53: Configuring Advanced Radio Settings
Chapter 3: 2.4GHz and 5GHz Radios Table 6. Basic Radio Settings Window (Continued) Field Description Bandwidth Select the bandwidth for Radio2 from the pull-down (Radio2) menu. The available bandwidths for IEEE 802.11a/n/ac/ax are listed here: - 20 MHz. This is the default setting. - 40 MHz - 80 MHz The only bandwidth for IEEE 802.11a is 20 MHz. -
Page 54: Figure 15: Advanced Radio Settings Window
AT-TQ6602 Access Point User’s Guide Figure 15. Advanced Radio Settings Window 4. Configure the parameters by referring to Table 7. Table 7. Advanced Radio Settings Window Field Description Maximum Use this option to specify the maximum number Clients of wireless clients that a radio will support at one time. - Page 55 Chapter 3: 2.4GHz and 5GHz Radios Table 7. Advanced Radio Settings Window (Continued) Field Description Neighbor AP Use this option to control whether the access Detection point listens for neighboring access points. Here are the options: - Enabled: The access point listens for neighboring access points and displays them in the Neighbor AP window.
- Page 56 AT-TQ6602 Access Point User’s Guide Table 7. Advanced Radio Settings Window (Continued) Field Description Band Steering Use this option to enable or disable band steering on the radios. Band steering reduces radio congestion by forcing wireless clients that support both 2.4GHz and 5GHz radios to associate with VAPs on a different radio during periods of traffic congestion.
-
Page 57: Displaying Radio Status
Chapter 3: 2.4GHz and 5GHz Radios Displaying Radio Status To display operational information about a radio, perform the following procedure: 1. Select Monitoring > Status from the main menu. 2. Select Radio1 or Radio2 from the sub-menu. You can view only one radio at a time. -
Page 58: Table 8. Radio Status Window
AT-TQ6602 Access Point User’s Guide Note The radio status window for Radio2 includes a DFS (Dynamic Frequency Selection) field. For more information, see “Dynamic Frequency Selection (DFS)” on page 60. The fields are defined in Table 8. Table 8. Radio Status Window... - Page 59 Chapter 3: 2.4GHz and 5GHz Radios Table 8. Radio Status Window (Continued) Field Description Displays the status of DFS (Dynamic Frequency Selection). For background information, refer to (Radio2 only) “Dynamic Frequency Selection (DFS)” on page 60. The possible states are listed here: - IDLE: DFS is inactive because the radio is using a W52 or W58 channel.
-
Page 60: Dynamic Frequency Selection (Dfs)
AT-TQ6602 Access Point User’s Guide Dynamic Frequency Selection (DFS) Dynamic frequency selection (DFS) is an industry standard that defines how wireless access points are to respond to the presence of radar signals on 5GHz channels. The standard states that a wireless access... -
Page 61: Setting The Country Code Setting
Chapter 3: 2.4GHz and 5GHz Radios Setting the Country Code Setting Note You cannot change the country code on units sold in North America, Japan, Canada, or Taiwan. You should set the country code setting of the access point as soon as you install the unit so that it operates in compliance with the codes and regulations of your region or country. - Page 62 AT-TQ6602 Access Point User’s Guide...
-
Page 63: Chapter 4: Virtual Access Points
Chapter 4 Virtual Access Points This chapter contains the procedures for managing virtual access points (VAPs). The chapter contains the following sections: “VAP Introduction” on page 64 “Configuring Basic VAP Parameters” on page 65 “Authenticating Wireless Clients with an External RADIUS Server” on ... -
Page 64: Vap Introduction
AT-TQ6602 Access Point User’s Guide VAP Introduction Virtual access points (VAPs) are independent broadcast domains that function as the wireless equivalent of Ethernet VLANs. They are seen by clients as independent access points, with their own VIDs, SSIDs, and security methods. -
Page 65: Configuring Basic Vap Parameters
Chapter 4: Virtual Access Points Configuring Basic VAP Parameters To configure basic VAP settings, perform the following procedure: 1. Select Settings > VAP / Security from the main menu. 2. Select Radio1 or Radio2 from the sub-menu. The default is Radio1. You can configure only one radio at a time. -
Page 66: Table 9. Virtual Access Point Tab
AT-TQ6602 Access Point User’s Guide Table 9. Virtual Access Point Tab Field Description Status Enable or disable the VAP. Here are the guidelines. - A disabled VAP does not forward any ingress or egress traffic. - The default setting for VAP0 is enabled. - Page 67 Chapter 4: Virtual Access Points Table 9. Virtual Access Point Tab (Continued) Field Description SSID Enter a name for the VAP. Here are the guidelines: A VAP must have a name. A name can be from 1 to 32 alphanumeric ...
- Page 68 AT-TQ6602 Access Point User’s Guide Table 9. Virtual Access Point Tab (Continued) Field Description MAC Filtering Select whether the VAP is to use the MAC filter to control access by wireless clients. For instructions, refer to “Configuring the MAC Address List” on page 87.
-
Page 69: Authenticating Wireless Clients With An External Radius Server
Chapter 4: Virtual Access Points Authenticating Wireless Clients with an External RADIUS Server The wireless access points have several methods for controlling access by wireless clients to your wireless networks. One method uses the on-board MAC address filter. Alternatively, you can centralize the list of MAC addresses of the wireless clients on an external RADIUS server. -
Page 70: Figure 19: External Radius Selection
AT-TQ6602 Access Point User’s Guide Figure 19. External RADIUS Selection Selecting External RADIUS displays the additional settings shown in Figure 20. Figure 20. External RADIUS Properties 6. Configure the fields described in Table 10 on page 71. -
Page 71: Table 10. Wpa Personal Security Tab
Chapter 4: Virtual Access Points Table 10. WPA Personal Security Tab Field Description Primary RADIUS Enter the IP address of the primary RADIUS server. Server IP This field is required. The address has to be entered in the following format: nnn.nnn.nnn.nnn Primary RADIUS Enter the secret key of the server. -
Page 72: Figure 21: User-Password Format Password Field
AT-TQ6602 Access Point User’s Guide Table 10. WPA Personal Security Tab (Continued) Field Description User-Password Specify the password for the MAC addresses. The Format Format choices are listed here: – User Name: The MAC addresses are used as the password. If you select this option,... -
Page 73: Configuring Vap Security
Chapter 4: Virtual Access Points Configuring VAP Security The procedures for configuring VAP security is provided in the following sections: “No Security” on page 73 “WPA Personal (Pre-Shared Key)” on page 74 “WPA Enterprise” on page 76 No Security VAPs not requiring any security can be set to the None security level. -
Page 74: Wpa Personal (Pre-Shared Key)
AT-TQ6602 Access Point User’s Guide 6. Select another VAP to configure from the sub-menu and repeat Step 4 to Step 5 if necessary. 7. Click the SAVE & APPLY button to save and update the configuration. WPA Personal To configure a VAP for WPA Personal security, perform the following... -
Page 75: Table 11. Wpa Personal Security Tab
Chapter 4: Virtual Access Points 6. Configure the parameters by referring to Table 11. Table 11. WPA Personal Security Tab Field Description Mode Select WPA Personal. WPA Version Select the WPA version. The options are listed here: - WPA and WPA2: Select this option if the VAP has both WPA and WPA2 clients. -
Page 76: Wpa Enterprise
AT-TQ6602 Access Point User’s Guide Table 11. WPA Personal Security Tab (Continued) Field Description IEEE802.11w Control IEEE 802.11w management frame (MFP) protection. This feature is only supported with WPA2 as the WPA Version. It is not supported with WPA and WPA2.The options are listed here: - Enabled: Activates management frame protection. -
Page 77: Figure 24: Wpa Enterprise Tab
Chapter 4: Virtual Access Points Figure 24. WPA Enterprise Tab 6. Configure the parameters by referring to Table 12 on page 78. -
Page 78: Table 12. Wpa Enterprise Tab
AT-TQ6602 Access Point User’s Guide Table 12. WPA Enterprise Tab Field Description Mode Select WPA Enterprise. WPA Version Select the WPA version for the VPA. The options are listed: - WPA and WPA2 - Select this option if the VAP has both WPA and WPA2 clients. - Page 79 Chapter 4: Virtual Access Points Table 12. WPA Enterprise Tab (Continued) Field Description IEEE802.11w Control IEEE 802.11w management frame protection. (MFP) This feature is only supported with WPA2 as the WPA Version. It is not supported with WPA and WPA2.The options are listed here: - Enabled: Activates management frame protection.
- Page 80 AT-TQ6602 Access Point User’s Guide Table 12. WPA Enterprise Tab (Continued) Field Description RADIUS Port Enter the RADIUS port number of the RADIUS server. If you entered IP addresses for both primary and secondary servers, the units must be using the same port number.
-
Page 81: Configuring Vap Fast Roaming
Chapter 4: Virtual Access Points Configuring VAP Fast Roaming The access point supports IEEE 802.11k/v/r for high-speed roaming by wireless clients. Here are the guidelines: High speed roaming applies to VAPs with WPA Personal or WPA Enterprise security. It does not apply to no security. You can view but not configure the IEEE 802.11r settings with the ... -
Page 82: Figure 25: Fast Roaming Window
AT-TQ6602 Access Point User’s Guide Figure 25. Fast Roaming Window 5. Configure the parameters by referring to Table 13. Table 13. Fast Roaming Tab Field Description IEEE802.11r You cannot change the setting with the web browser Fast Transition management interface. Refer to the Vista Manager EX and AWC plug-in documentation. - Page 83 Chapter 4: Virtual Access Points 7. Click the SAVE & APPLY button to save and update the configuration.
-
Page 84: Configuring Advanced Vap Settings
AT-TQ6602 Access Point User’s Guide Configuring Advanced VAP Settings To configure advanced VAP settings, perform the following procedure: 1. Select Settings > VAP / Security from the main menu. 2. Select Radio1 or Radio2 from the sub-menu. The default is Radio1. -
Page 85: Table 14. Advanced Settings Tab
Chapter 4: Virtual Access Points Table 14. Advanced Settings Tab Field Description Inactivity Timer Specifies how long the access point allows inactive wireless clients to remain associated to it. The access point disconnects inactive clients when the timer expires. Here are guidelines: - The default is 300 seconds. - Page 86 AT-TQ6602 Access Point User’s Guide Table 14. Advanced Settings Tab (Continued) Field Description DIMP Period Specifies the Delivery Traffic Indication Maps (DTIMs) period. Access points broadcast a beacon at regular intervals, which includes Delivery Traffic Indication Maps (DTIMs). The DIMP period specifies...
-
Page 87: Configuring The Mac Address List
Chapter 4: Virtual Access Points Configuring the MAC Address List The MAC address filter is used to control which wireless clients can access your network through the VAPs. You configure the filter by entering the MAC addresses of wireless clients whose association requests are to be accepted or rejected by the access point. - Page 88 AT-TQ6602 Access Point User’s Guide 2. From the Action pull-down menu, select one of the following: Deny: Select this option to have the access point reject association requests from wireless clients whose MAC addresses you enter in the filter, and to accept association requests from all other clients.
-
Page 89: Displaying Vap And Lan Port Statistics
Chapter 4: Virtual Access Points Displaying VAP and LAN Port Statistics To view VAP and LAN port status and statistics, select Monitoring > Statistics window. Refer to Figure 28. Figure 28. Statistics Window The columns are defined in Table 15 on page 90. -
Page 90: Table 15. Statistics Window
AT-TQ6602 Access Point User’s Guide Table 15. Statistics Window Column Description Interface Displays the LAN port and VAPs 0 to 15 on Radio1 and Radio2. Status Displays the status (up or down) of the interface. Packets Received Displays the total number of packets received on the interface. -
Page 91: Chapter 5: Wireless Distribution System Bridges
Chapter 5 Wireless Distribution System Bridges This chapter contains the procedures for managing Wireless Distribution Bridges. The chapter contains the following sections: “Introduction to Wireless Distribution Bridges” on page 92 “WDS Bridge Elements” on page 95 “Guidelines” on page 97 ... -
Page 92: Introduction To Wireless Distribution Bridges
AT-TQ6602 Access Points User’s Guide Introduction to Wireless Distribution Bridges A wireless distribution system (WDS) bridge is a wireless connection between access points that allows units to forward traffic directly to each other over a wireless connection, as if they were connected with a physical Ethernet wire. -
Page 93: Figure 30: Example Of Radio And Channel Assignments In A Wds Bridge
Chapter 5: Wireless Distribution System Bridges Additionally, because the access points have to use the same channel, you have to select the channel manually, instead of using the default auto channel setting. In the example in Figure 30, the parent and children are using Radio2 and channel 40 for the WDS bridge. -
Page 94: Figure 31: Example Of An Access Point As Both Parent And Child
Connecting the LAN ports on both parents to the wired network might form a loop in your network topology, which might cause broadcast storms. Allied Telesis does not recommend linking together more than two WDS bridges. The LAN ports on the parent connected to the wired network might not be able to efficiently handle the traffic load of wireless clients of more than two bridges. -
Page 95: Wds Bridge Elements
Chapter 5: Wireless Distribution System Bridges WDS Bridge Elements This section describes the various elements of a WDS bridge. Radio You can use Radio1 or Radio2 for a WDS bridge. Here are the guidelines: The access points must all use the same radio for a bridge. ... -
Page 96: Dynamic Frequency Selection (Dfs)
AT-TQ6602 Access Points User’s Guide Note You cannot use WPA Enterprise on VAP0 of a WDS bridge. Dynamic If a wireless access point is using a DFS 5GHz channel for a WDS bridge and it detects radar signals, it randomly selects another channel so as not Frequency to interfere with the signals. -
Page 97: Guidelines
another. However, it cannot be a parent or child in more than one bridge. The WDS bridge feature on these access points is not compatible with the same feature on other products from Allied Telesis or other companies. -
Page 98: Preparing Access Points For A Wds Bridge
for the bridges. The security level can be none or WPA Personal. Allied Telesis recommends using WPA Personal security. The settings must be the same on all the access points of a WDS bridge. To prepare an access point for a WDS bridge, perform the following procedure: 1. - Page 99 Chapter 5: Wireless Distribution System Bridges Note The access point disables VAPs 1 to 7 on the same radio. 10. Repeat this procedure on all access points to be in the WDS bridge. When an access point is designated as a child, it automatically begins searching for a parent on the designated radio and channel.
- Page 100 AT-TQ6602 Access Points User’s Guide...
-
Page 101: Chapter 6: Web Browser Interface
Chapter 6 Web Browser Interface This chapter contains the following procedures: “Configuring the Web Browser Interface” on page 102 “Changing the Manager’s Login Name and Password” on page 104 “Setting the Language of the Web Browser Interface” on page 106 ... -
Page 102: Configuring The Web Browser Interface
HTTP management is non-secure, meaning the packets exchanged between the access point and your workstation are sent in clear text, leaving them vulnerable to snooping. For this reason, Allied Telesis recommends using HTTPS to manage the access point. To configure the above functions, perform the following procedure: 1. -
Page 103: Table 16. Web Window
Chapter 6: Web Browser Interface 3. Configure the fields by referring to Table 16. Table 16. Web Window Field Description Maximum Sessions Specify the maximum number of active management sessions the access point will support at one time. Here are the guidelines: - The range is 1 to 10 sessions. -
Page 104: Changing The Manager's Login Name And Password
Changing the name and password does not affect your current management session. Note Allied Telesis strongly recommends changing the factory default password during the first management session to protect the device from unauthorized access. To change the login name and password of the manager account, perform the following procedure: 1. - Page 105 Chapter 6: Web Browser Interface 3. To change the password, select the Current Password field and enter the account’s current password. The default password: friend To display the password as alphanumeric characters or asterisks, click the green, double arrow symbol. 4.
-
Page 106: Setting The Language Of The Web Browser Interface
AT-TQ6602 Access Point User’s Guide Setting the Language of the Web Browser Interface The access point can display the web browser interface in either English or Japanese. The default is English. To set the language, perform the following procedure: 1. Select Account > Language from the main menu. Refer to Figure 34. -
Page 107: Chapter 7: Quality Of Service
Chapter 7 Quality of Service This chapter describes the following procedures: “Introduction to Quality of Service” on page 108 “Configuring QoS Basic Settings” on page 110 “Configuring AP EDCA Parameters” on page 111 “Configuring Station EDCA Parameters” on page 114 ... -
Page 108: Introduction To Quality Of Service
AT-TQ6602 Access Point User’s Guide Introduction to Quality of Service Each radio in the access point has four QoS egress queues and four ingress queues. There are parameters that control the manner in which the device stores and handles packets in the queues. You should not adjust these values unless you are familiar with QoS. -
Page 109: Figure 35: Qos Window
Chapter 7: Quality of Service Figure 35. QoS Window... -
Page 110: Configuring Qos Basic Settings
AT-TQ6602 Access Point User’s Guide Configuring QoS Basic Settings The fields for the Basic Settings section are defined in Table 17. Table 17. QoS Window - Basic Settings Parameter Description WiFi Multimedia Enable or disable QoS prioritizing and (WMM) coordination. Here are the settings:... -
Page 111: Configuring Ap Edca Parameters
Chapter 7: Quality of Service Configuring AP EDCA Parameters Table 18 defines the AP EDCA parameters in the QoS window in Figure 35 on page 109. Table 18. QoS Window - AP EDCA Parameters Parameter Description Data Type (Queue) Lists the four egress queues: - Data 0 (Voice): High priority queue, with low latency and guaranteed bandwidth. - Page 112 AT-TQ6602 Access Point User’s Guide Table 18. QoS Window - AP EDCA Parameters (Continued) Parameter Description cwMin (Minimum Enter a value (in milliseconds) to be the lower Contention limit of the range from which the access point Window) determines the initial random back-off wait time.for resending packets during transmission...
- Page 113 Chapter 7: Quality of Service Table 18. QoS Window - AP EDCA Parameters (Continued) Parameter Description Max. Burst Specifies the maximum burst length (in seconds) for packet bursts on the wireless network. A packet burst is a collection of multiple frames transmitted without header information.
-
Page 114: Configuring Station Edca Parameters
AT-TQ6602 Access Point User’s Guide Configuring Station EDCA Parameters Table 19 defines the Station EDCA parameters in the QoS window in Figure 35 on page 109. Table 19. QoS Window - Station EDCA Parameters Parameter Description Data Type (Queue) Specifies the four ingress queues: - Data 0 (Voice) - High priority queue, with minimum delay. - Page 115 Chapter 7: Quality of Service Table 19. QoS Window - Station EDCA Parameters (Continued) Parameter Description cwMin (Minimum Enter a value (in milliseconds) to be the lower Contention limit of the range from which the station Window) determines the initial random back-off wait time.for resending packets during transmission conflicts.
- Page 116 AT-TQ6602 Access Point User’s Guide Table 19. QoS Window - Station EDCA Parameters (Continued) Parameter Description TXOP Limit Select the Transmission Opportunity (TXOP) limit. It defines the time intervals that a WME client has the right to initiate transmission to the access point.
-
Page 117: Chapter 8: Lan Port
Chapter 8 LAN Port This chapter describes the following procedures: “Configuring the Management VLAN” on page 118 “Displaying the Status of LAN Port” on page 120 ... -
Page 118: Configuring The Management Vlan
AT-TQ6602 Access Point User’s Guide Configuring the Management VLAN Here are the guidelines to setting the management VLAN: When the management VLAN is disabled, the default setting, the access point handles untagged packets as members of VLAN 1. When the management VLAN is enabled and set to VID 1, the ... -
Page 119: Figure 37: Lan Settings Window - Management Vlan Tag Is Eanbled
Chapter 8: LAN Port Figure 37. LAN Settings Window - Management VLAN Tag is Eanbled 2. Configure the settings by referring to Table 20. Table 20. LAN Setting Window Item Name Description Management Select one of the following: VLAN Tag - Enable: Activates the management VLAN Tag. -
Page 120: Displaying The Status Of Lan Port
AT-TQ6602 Access Point User’s Guide Displaying the Status of LAN Port To display the status of LAN port, perform the following procedure: 1. Select Monitoring > Status from the main menu. 2. Select LAN from the sub-menu. See Figure 38. - Page 121 Chapter 8: LAN Port Table 21. LAN Window (Continued) Item Name Description PoE Mode Displays the PoE mode, as follows. - IEEE802.3at: The access point is powered by PoE. - None: The access point is powered by an external adapter.
- Page 122 AT-TQ6602 Access Point User’s Guide...
-
Page 123: Chapter 9: Monitoring
Chapter 9 Monitoring This chapter has the following procedures: “Displaying Basic System Information” on page 124 “Displaying Neighbor Access Points” on page 127 “Displaying Associated Clients” on page 128 ... -
Page 124: Displaying Basic System Information
AT-TQ6602 Access Point User’s Guide Displaying Basic System Information To display basic information about the access point, such as its firmware version number and MAC address, perform the following procedure: 1. Select Monitoring > Status from the main menu. 2. Select System from the sub-menu. This is the default window. Refer to Figure 39. - Page 125 Chapter 9: Monitoring Table 22. System Window (Continued) Item Name Description System Time Displays the date and time. To set the date and time, refer to “Manually Setting the Date and Time” on page 39 or “Setting the Date and Time with the Network Time Protocol (NTP)”...
- Page 126 AT-TQ6602 Access Point User’s Guide Table 22. System Window (Continued) Item Name Description DNS Server Displays the current DNS server address. Refer to “Assigning a Dynamic IP Address from a DHCP Server” on page 32 or “Assigning a Static IP Address to the Access Point” on page 34.
-
Page 127: Displaying Neighbor Access Points
Chapter 9: Monitoring Displaying Neighbor Access Points To view information about other access points that the access point has detected, select Monitoring > Neighbor AP from the main menu. Refer to Figure 40. Figure 40. Neighbor AP Window The columns are defined in Table 23. Table 23. -
Page 128: Displaying Associated Clients
AT-TQ6602 Access Point User’s Guide Displaying Associated Clients To view the active wireless clients on the VAPs of the access point, select Monitoring > Associated Clients from the main menu. Refer to Figure 41. Figure 41. Associated Client Window The columns are defined in Table 24. -
Page 129: Chapter 10: System Log
Chapter 10 System Log This chapter describes the system log in the following sections: “Displaying the System Log” on page 130 “Sending Log Messages to a Syslog Server” on page 132 ... -
Page 130: Displaying The System Log
AT-TQ6602 Access Point User’s Guide Displaying the System Log A wireless access point is a complex piece of network equipment that includes both hardware and software components. Multiple software features operate simultaneously, interoperating with each other and processing large amounts of network traffic. It is often difficult to determine exactly what is happening when an access point appears not to be operating normally, or what happened when a problem occurred. -
Page 131: Figure 42: Log Window For Event Messages
Chapter 10: System Log Figure 42. Log Window for Event Messages... -
Page 132: Sending Log Messages To A Syslog Server
AT-TQ6602 Access Point User’s Guide Sending Log Messages to a Syslog Server To configure the access point to send the log messages to a syslog server on your network, perform the following procedure: 1. Select Settings > System from the main menu. - Page 133 Chapter 10: System Log Table 26. Log Window for Syslog Client (Continued) Field Description Log Relay Select one of the following: - Enabled: Activates the syslog client to transmit the event messages to your syslog server. - Disabled: Deactivates the syslog client to stop the access point from transmitting event messages.
- Page 134 AT-TQ6602 Access Point User’s Guide...
-
Page 135: Chapter 11: Maintenance
Chapter 11 Maintenance This chapter has the following procedures: “Downloading the Configuration of the Access Point to Your Computer” on page 136 “Restoring a Configuration to the Access Point” on page 138 “Restoring the Default Settings to the Access Point” on page 139 ... -
Page 136: Downloading The Configuration Of The Access Point To Your Computer
AT-TQ6602 Access Point User’s Guide Downloading the Configuration of the Access Point to Your Computer This procedure explains how to download the configuration of the access point as a file to your computer. You might perform this procedure to maintain a history of the configurations of the unit so that you can easily restore a configuration, if needed. - Page 137 Chapter 11: Maintenance 4. If desired, change the filename of the configuration file. The filename suffix must be “txt”. 5. Click the Save button. The access point downloads a file with its configuration to your management workstation, which stores it in the designated folder.
-
Page 138: Restoring A Configuration To The Access Point
AT-TQ6602 Access Point User’s Guide Restoring a Configuration to the Access Point This procedure explains how to restore a configuration to the access point. You might perform this procedure to restore a previous configuration to the device, to configure a replacement unit, or to configure multiple access points with the same configuration. -
Page 139: Restoring The Default Settings To The Access Point
Chapter 11: Maintenance Restoring the Default Settings to the Access Point This procedure explains how to restore the default settings on the access point. Review the following information before performing the procedure: The manager name and password are reset to “manager” and ... -
Page 140: Uploading New Management Software To The Access Point
Please review the following information before performing the procedure: The procedure assumes you have already obtained the new image file from the Allied Telesis web site and stored it on your computer or network server. The configuration settings of the access point are retained when a ... -
Page 141: Figure 45: Upgrade Window
Chapter 11: Maintenance Figure 45. Upgrade Window The version number of the current firmware is displayed in the Firmware Information section of the window. 2. Click the Browse button next to the New Firmware Image field and locate the new image file on your computer or network server. 3. -
Page 142: Rebooting The Access Point
AT-TQ6602 Access Point User’s Guide Rebooting the Access Point This section explains how to reboot the access point. You might reboot the device if it is experiencing a problem. Caution The device does not forward network traffic while it reboots. Some network traffic may be lost. -
Page 143: Collecting Technical Support Information To A File
Chapter 11: Maintenance Collecting Technical Support Information to a File If you contact Allied Telesis for technical assistance with the access point, you may be instructed to send Allied Telesis technical support information. Technical support information helps Allied Telesis technicians troubleshoot problems with the device. - Page 144 It is case sensitive. Spaces are not allowed. Be sure to send the key to the technicians at Allied Telesis. The factory default is blank. The file is sent in clear text if you do not enter a key.
