VENETA 65101-50725-D How To Install

Cordless roman blind

Advertisement

Quick Links

How to install your
Cordless Roman Blind
#65101-50725-D

Required Tools

Inside Video
Outside Video

Included Hardware

The hardware can be found in
the end of every box.
Installation
Bracket
(Install inside
window frame)
Installation
Bracket
(Install outside
window frame)
Long Screws for
Wood
Wall Plugs for Brick
or Cement using
a 6mm bit
(if requested)
Wand
(if requested)

Child Safety

This product has no Cord or
Chain and is Child and Pet
Safe!
measuring
drill with
tape
2mm bit
1

Installation Brackets

Installing inside the window frame...

At top of window frame, measure 89mm in from each end and
34mm back from the front of the window frame, mark with a
pencil; this is where the screw will go for the outer brackets.
We recommend drilling pilot holes for the screws using a 2mm bit.
Fix the brackets into position using 1 long screw for each bracket.
If more brackets are supplied; on the blind accurately measure
from centre of first bracket to centre of the next bracket and mark
the same distance on window frame.
89mm

Installing outside the window frame...

Measure 89mm in from top left and top right of where the blind will
sit (normally edge of architrave) and mark where the screws will go.
We recommend using a spirit level to align brackets if not installing
on the architrave.
We recommend drilling pilot holes for the screws using a 2mm bit.
Fix the brackets into position using 2 long screws for each bracket.
If more brackets are supplied; on the blind accurately measure
from centre of first bracket to centre of the next bracket and mark
the same distance on window frame.
Valance Returns
2
(inside mount only)
Attach the valance return to the ends of the blind using the
Velcro patches.
3

Install Blind

Slide blind backwards into position ensuring all brackets meet
snugly.
Note the blind click into place.
Great Job... Enjoy your new Veneta Blinds!
phillips bit or
screwdriver
89mm
Bracket
pencil
knife
89
89

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 65101-50725-D and is the answer not in the manual?

Questions and answers

Summary of Contents for VENETA 65101-50725-D

  • Page 1 Child Safety Install Blind Slide blind backwards into position ensuring all brackets meet snugly. Note the blind click into place. This product has no Cord or Chain and is Child and Pet Safe! Great Job… Enjoy your new Veneta Blinds!
  • Page 2 How to operate and maintain your Cordless Roman Blind Operating your Lower your new Roman blind to the desired position by gently pulling down on the fabric handle located at Blind the back of the blind. To raise the blind, gently pull down on the fabric handle for a short distance to unlock the spring and the blind will then rise automatically.
