How to install your
Cordless Timber Venetian Blind
#65101-20145-A
measuring
Required Tools
tape
1
Included Hardware
Installation Brackets
Installing inside the window frame...
The hardware can be found in
At the top of the window frame measure 85mm in from each side
and measure 72mm (103mm for blind with valance) back from the
the end of every box.
front of the window opening; this is the edge of the back of the
bracket.
Place bracket in position and mark where the screws will go.
We recommend drilling pilot holes for the screws using a 2mm bit.
First peel off the paper at the backside of the bracket and then fix
Installation
brackets into position using 2 long screws.
If more brackets are supplied, space them evenly between the first
Bracket
two brackets.
Hold Down
Bracket
Medium & Long
Screws for Wood
Wall Plugs for Brick
Installing outside the window frame...
or Cement using
Measure 85mm in from the top left and top right of where the blind
a 6mm Bit
will be positioned and 51mm up from the top of the window opening;
(if requested)
this is the edge of the top of the bracket.
Place the brackets in position and mark where the screws will go.
We recommend using a spirit level to align brackets if not installing
Valance Connector
on the architrave.
(Optional)
We recommend drilling pilot holes for the screws using a 2mm bit.
First peel off the paper at the backside of the bracket and then fix
brackets into position using 2 long screws.
Clip Plug
If more brackets are supplied, space them evenly between the first
(Optional)
two brackets.
2
Install Blind
Clip Receptor
(Optional)
Position the top front of the blind under the top front
lip of the brackets.
Push the blind up at the back and click into position
as per diagram.
Wood Wand
Ensure the blind has clicked firmly into place.
Valance Return
Connector
(Optional)
★ ☆ ☆ ☆ ☆
Difficulty:
drill with
phillips bit or
pencil
2mm bit
screwdriver
Without Valance
With Valance
Peel off the paper
With or Without Valance
click!
How to install your
Cordless Timber Venetian Blind
#65101-20145-A
knife
Installation
continued...
1
3
Install Valance Connector (Optional)
Valance Connector is only supplied for connecting spliced valances.
Insert the valance connector into the slot on the back of the valance as below drawing:
The valance is connected as below drawing:
4
Attach the Valance (Optional)
Hook the adjustable valance clip receptors onto the headrail and space them evenly.
Make sure receptors are not in an obstructive position with the drum support or wand tilter
inside the headrail and the brackets.
Attach the adjustable valance clip plug into the channel on the backside of the valance.
Refer to the receptor position on the headrail to decide where to position on the valance.
2
