How to install your
Cordless PVC Venetian Blind
#65101-20146-G
measuring
Required Tools
tape
1
Included Hardware
Installation Brackets
Installing inside the window frame...
The hardware can be found in At the top of the window frame measure 85mm in from each side
and measure 68mm (102mm for blind with valance) back from the
the end of every box.
front of the window opening; this is the edge of the back of the
bracket.
Place bracket in position and mark where the screws will go.
We recommend drilling pilot holes for the screws using a 2mm bit.
Use the double sided tape from the hardware box and stick the
Installation
brackets at the marked location for easy installation if needed,
then fix bracket into position using 2 long screws.
Bracket
If more brackets are supplied, space them evenly between the first
two brackets.
Hold Down
Bracket
Medium & Long
Screws for Wood
Wall Plugs for Brick
Installing outside the window frame...
or Cement using
Measure 85mm in from the top left and top right of where the blind
a 6mm Bit
will be positioned and 45mm up from the top of the window opening;
(if requested) this is the edge of the top of the bracket.
Place the brackets in position and mark where the screws will go.
We recommend using a spirit level to align brackets if not installing
on the architrave.
Valance Connector
We recommend drilling pilot holes for the screws using a 2mm bit.
(Optional)
Use the double sided tape from the hardware box and stick the
brackets at the marked location for easy installation if needed,
then fix bracket into position using 2 long screws.
Clip Plug
If more brackets are supplied, space them evenly between the first
(Optional)
two brackets.
2
Install Blind Without Valance
Clip Receptor
(Optional)
Position the top front of the blind under the top front
lip of the brackets.
Push the blind up at the back and click into position
as per diagram.
Wand
Ensure the blind has clicked firmly into place.
Valance Return
Connector
(Optional)
Difficulty: ★ ☆ ☆ ☆ ☆
drill with phillips bit or pencil
2mm bit screwdriver
With or Without Valance
How to install your
Cordless PVC Venetian Blind
#65101-20146-G
knife
Installation
continued...
1
3
Install Valance Connector (Optional)
Valance Connector is only supplied for connecting spliced valances.
Insert the valance connector into the slot on the back of the valance as below drawing:
The valance is connected as below drawing:
4
Install Blind With Valance (Optional)
Hook the adjustable valance clip receptors onto the headrail and space them evenly.
Make sure receptors are not in an obstructive position with the drum support or wand tilter
inside the headrail and the brackets.
Attach the headrail to bracket as the ways described in step 2.
Attach the adjustable valance clip plug into the channel on the backside of the valance.
Refer to the receptor position on the headrail to decide where to position on the valance.
