VENETA 65101-21717-B How To Install

How to install your
Aluminium Venetian Blind
#65101-21717-B
Required Tools
Inside Video Outside Video
Included Hardware
The hardware can be found in
the end of every box.
Installation
Bracket
Hold Down
Bracket
Child Safety
Cleat
Medium & Long
Screws for
Wood
Wall Plugs for Brick
or Cement using
a 6mm bit
(if requested)
Need HELP?
Customer Service
1300 836 382
"the best compliment
you can give
is a referral"
measuring drill with
tape 2mm bit
1
Installation Brackets
Installing inside the window frame...
At top of window frame, measure 70mm in from each side and
39mm back from front of window frame and mark with a pencil; this
is the centre back of the outer brackets.
Place brackets in position and mark where the 2 screws will go.
We recommend drilling pilot holes for the screws using a 2mm bit.
Fix the brackets into position using 2 long screws for each bracket.
If more brackets are supplied, space them evenly between the first
two brackets.
Installing outside the window frame...
Measure 70mm in from top left and top right of where the blind will sit
and mark with a pencil; this is the centre of where the brackets will go.
Place brackets in position (normally flush with top of architrave) and
mark where the screws will go.
We recommend using a spirit level to align brackets if not installing
on the architrave.
We recommend drilling pilot holes for the screws using a 2mm bit.
Fix the brackets into position using 2 long screws for each bracket.
If more brackets are supplied, space them evenly between the first
two brackets.
2
Install Blind
With the bottom of the blind angled slightly towards you,
position the top front of the blind onto the top front lip of the
brackets.
Tilt the blind up at the back noticing it click into place.
3
Attach Wand
Slide wand hook through eyelet on headrail.
When wand length is longer than blind width, a connector
will be used.
phillips bit or
screwdriver
Space evenly
(if ordered)
pencil knife
39mm
