VENETA 65101-21735-I How To Install

How to install your
Corded PVC Venetian Blind
#65101-21735-I
measuring
Required Tools
tape
1
Included Hardware
Installation Brackets
Installing inside the window frame...
At the top of the window frame measure 85mm in from each side
The hardware can be found in
and measure 68mm (99mm for blind with valance) back from the
the end of every box.
front of the window opening; this is the edge of the back of the
bracket.
Place bracket in position and mark where the screws will go.
We recommend drilling pilot holes for the screws using a 2mm bit.
Use the double sided tape from the hardware box and stick the
brackets at the marked location for easy installation if needed,
Installation
then fix bracket into position using 2 long screws.
Bracket
If more brackets are supplied, space them evenly between the first
two brackets.
Hold Down
Bracket
Child Safety
Cleat
Medium & Long
Installing outside the window frame...
Screws for Wood
Measure 85mm in from the top left and top right of where the blind
will be positioned and 45mm up from the top of the window opening;
this is the edge of the top of the bracket.
Place the brackets in position and mark where the screws will go.
Wall Plugs for Brick
We recommend using a spirit level to align brackets if not installing on
or Cement using
the architrave.
a 6mm Bit
We recommend drilling pilot holes for the screws using a 2mm bit.
(if requested)
Use the double sided tape from the hardware box and stick the
brackets at the marked location for easy installation if needed, then fix
bracket into position using 2 long screws.
Valance Connector If more brackets are supplied, space them evenly between the first two
or
brackets.
(Optional)
2
Install Blind Without Valance
Clip Plug
(Optional)
Position the top front of the blind under the top front
lip of the brackets.
Push the blind up at the back and click into position
as per diagram.
Clip Receptor
Ensure the blind has clicked firmly into place.
(Optional)
①
Valance Return
Joinery
(Optional)
Difficulty: ★ ☆ ☆ ☆ ☆
drill with phillips bit or pencil
2mm bit screwdriver
With or Without Valance
②
③
How to install your
Corded PVC Venetian Blind
#65101-21735-I
knife
Need HELP?
Customer Service
1800 836 382
"the best compliment
you can give
is a referral"
1
3
Install Valance Connector (Optional)
Valance Connector is only supplied for connecting spliced valances.
Put the valance connector into the slots on the back of the valance as below drawing:
The valance is connected as below drawing:
4
Install Blind With Valance (Optional)
Hook the adjustable valance clip receptors onto the headrail
and space them evenly.
Make sure receptors are not in an obstructive position with
the drum support inside the headrail and brackets.
Attach the headrail to bracket as the ways described in
step 2.
Attach the adjustable valance clip plug into the channel on
the backside of the valance. Refer to the receptor position
on the headrail to decide where to position on the valance.
Attach the valance return joinery if needed.
(Outside Mount)
2
