VENETA 65101-40159 How To Install

How to install your
Cordless
(Roller Blinds with No top treatment)
#65101-40159

Required Tools

Included Hardware

The hardware can be found in
the small hardware box included
with your blind.
32mm Round
Head Screw
(for Blind Bracket)
19mm Round Head
Screw
Blind Bracket
(on Tension Dial)
Blind Bracket
(on End Plug end)
Blind Bracket
Cover
Traditional Hold
Down Bracket
(Optional)
Handle
measuring drill with
tape 2mm bit
1

Blind Bracket Installation

Installing inside the window frame...
When installing the blind bracket, the distance from the bracket's front mounting hole to the
①
front edge of the window frame should be at least 19mm.
②
Make sure both blind brackets line up with each other horizontally.
③
First fit the blind bracket cover over the blind bracket, and then screw brackets into wall.
Each blind bracket will require two 32mm round head screws for the installation.
④
Installing outside the window frame...
When installing the blind bracket, the distance from the bracket's front mounting hole to the
①
front edge of the window frame should be at least 19mm.
②
Make sure both blind brackets line up with each other horizontally.
③ Each blind bracket will require two 32mm round head screws for the installation.
④
Fit the blind bracket cover over the blind bracket.
Blind Brackets Installation Tips...
The top & bottom of left & right blind brackets should be at the same horizontal line.
①
The front & back of left & right blind brackets should be at the same horizontal line.
②
phillips bit or
screwdriver
≥19mm
≥19mm
Difficulty:
pencil knife
1 1
