Technical data
Terminals
Cable entry
Supply voltage
Lift-off voltage
Basic current
In-rush current
FISCO
FNICO
Polaritätsabhängig
90
Block Content
Integrator Block The Integrator Function Block integrates a variable as a
function of the time or accumulates the counts from a
Pulse Input block. The block may be used as a totalizer
that counts up until reset or as a batch totalizer that has a
setpoint, where the integrated or accumulated value is
compared to pre-trip and trip settings, generating discrete
signals when these settings are reached.
10.1.3 Auxiliary energy
Cable cross-section: 0.5 ... 2.5 mm
• Cable gland M20x1.5 (recommended cable diameter 6 ... 10 mm)
• Cable entry G½ or ½NPT
• 7/8" FOUNDATION Fieldbus plug
9 V ... 32 V
There may be additional restrictions for devices with an explosion protection certificate.
Refer to the notes in the appropriate safety instructions (XA).
9 V
max. 15 mA
≤ 15 mA
U = 17,5 V
i
I = 500 mA; with overvoltage protection 273 mA
i
P = 5,5 W; with overvoltage protection 1,2 W
i
C = 5 nF
i
L = 0,01 mH
i
yes
no
Levelflex M FMP43 with FOUNDATION Fieldbus
2
(20 to 14 AWG)
Execution time Functionality
60 ms standard
