Installation
Process connection
78
Ø 56
Ø 39
92
Ø 68
Ø 51
63
Ø 42,9
64 64
30,4 30,4
127
152,4
16
Designation
DIN11851 DN40 PN40
with slotted nut F40*
P = 16 bar
max
21
DIN11851 DN50 PN40
with slotted nut F50*
P = 16 bar
max
22
DIN11864-1 A DN25
Pipe DIN11850
with slotted nut F25*
P = 16 bar
max
21
NEUMO BioControl
DN25 PN16*
P = 16 bar
max
1-1/2" 150lbs RF
Flange ANSI B16.5*
P = 16 bar
max
17,5
2" 150lbs RF
Flange ANSI B16.5*
P = 16 bar
max
19,1
Levelflex M FMP43 with FOUNDATION Fieldbus
Versions Approvals
• 0.76 μm
• EHEDG
• 0.76 μm
• 0.38 μm
electropolished
• 0.76 μm
Option
MQJ
MRJ
MAJ
S1J
AEJ
AFJ
