Levelflex M FMP43 with FOUNDATION Fieldbus
Endress+Hauser
Virtual communication references (VCRs)
Permanent Entries 1
Client VCRs 0
Server VCRs 24
Source VCRs 23
Sink VCRs 0
Subscriber VCRs 23
Publisher VCRs 23
Link Settings
Slot time 4
Min. Inter PDU delay 6
Max. response delay 10
Transducer Blocks
Block Content
Sensor Block contains all parameters related to the measurement
Diagnsotic Block contains diagnostiv information
Display Block contains parameters to configure the local display
1) depending on the configuration of the sensor-block
Function Blocks
Block Content
Resource Block The Resource Block contains all the data that uniquely
identifies the field instrument. It is an electronic version
of a nameplate of the instrument.
Analog Input The AI block takes the manufacturer's input data,
Block 1 selected by channel number, and makes it available to
Analog Input other function blocks at its output.
Block 2
PID Block The PID block serves as proportional-integral-derivative
controller and is used almost universally to do closed-
loop-control in the field including cascade and
feedforward.
Arithmetic Block This block is designed to permit simple use of popular
measurement math functions. The user does not have to
know how to write equations. The math algorithm is
selected by name, chosen by the user for the function to
be done.
Input Selector The input selector block provides selection of up to four
Block inputs and generates an output based on the configured
action. This block normally receives its inputs from AI
blocks. The block performs maximum, minimum, middle,
average and 'first good' signal selection.
Signal The signal characterizer block has two sections, each
Characterizer with an output that is a non-linear function of the
Block respective input. The non-linear function is determined
by a single look-up table with 21 arbitrary x-y pairs.
Technical data
Output values
1)
• level or volume (channel 1)
• distance (channel 2)
no output values
no output values
Execution time Functionality
enhanced
30 ms standard
80 ms standard
50 ms standard
30 ms standard
40 ms standard
