Inserting a SD Memory Card

Insert a SD memory card into the SD memory card slot
with the 'microSD' printed facing upward.
Push the SD memory card until it disengages from the
slot, and then pull it out.

Installation

• Check the wall or ceiling to see if it needs to be
reinforced. The camera may fall off if the wall or
ceiling is not strong enough to support its weight.
• Install the camera in a shaded area. If the camera
is installed in direct sunlight, it may be affected
adversely.
DC-D4216X(-A) / DC-D4216RX(-A)
1
Use the screws, anchors provided with the camera to
secure the bottom cover on a wall or a ceiling.
Use the provided guide pattern to check the distance
between the screw holes if necessary.
2
Connect external devices, the network cable, and
the power adapter.
3
Adjust the angle. For more information, refer to the
Angle Adjustment.
DC-D4216WRX(-A)
1
Push the network cable through the cable rubber,
using the protective connector provided.
Cable rubber
Part 1 – Introduction
Protect
Cable
connector
