Combo G LED Mode
When selected, this mode setting enables LapTimer to show combined g information to the user via the LEDs whilst also
showing Delta T information on the display. It encourages the user to truly push their car in braking points as well as
turns, in order to improve lap times
Maximum breaking and cornering g, which is indicated by the LEDs, can be configured up to 1.9 g by pressing the
square button. The LED minimum percentage value can be configured to alter when the LED colours appear.
For more information on how this mode affects the LEDs, see the Combo G LEDs section.
Save reference lap
This feature allows the user to save a reference lap for future use, insert an SD card into VBOX LapTimer and use the
menu options shown below. Note that the vehicle must be stationary to make this transfer.
Once this is selected, the following messages show saving has been successful. This will be stored on the SD card as
LAP.REF in the 'Data' folder.
Load reference lap
To load a reference lap file stored from a previous session, put the desired file onto an SD card and load the card into
VBOX LapTimer. The file can have any name, however it must be saved in the Data folder and only one .REF file should
be present. Select the menu options as shown above – but select LOAD REF LAP instead of SAVE. Note that the
vehicle must be stationary to make this transfer. Reference laps will be reset when either a new start/finish is set, or if
the 'reset lap timing data' option is selected from the lap timing menu within main menu.
