Racelogic VBOX LapTimer User Manual

Hide thumbs Also See for VBOX LapTimer:
Table of Contents

Advertisement

Quick Links

VBOX LapTimer User Manual
•
01 - VBOX LapTimer - Introduction
•
02 - VBOX LapTimer - GPS
•
03 - VBOX LapTimer - Speed/Max Speed/Speed Bar
•
04 - VBOX LapTimer - Lap Timing
•
05 - VBOX LapTimer - Predictive Lap Timing
•
06 - VBOX LapTimer - Lap Count
•
07 - VBOX LapTimer - Lateral/Longitudinal g
•
08 - VBOX LapTimer - Menu Options
•
09 - VBOX LapTimer - Square Button Functions
•
10 - VBOX LapTimer - Using as an OLED Display
•
11 - VBOX LapTimer - Technical Properties
•
VBOX LapTimer - EC Declaration of Conformity
•
VBOX LapTimer - PIN OUTS
•
VBOX LapTimer - Standard Inventory
•
VBOX LapTimer - Technical Specification
•
VBOX LapTimer - Upgrading Firmware
•
12 - VBOX LapTimer - Troubleshooting
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VBOX LapTimer and is the answer not in the manual?

Questions and answers

Related Manuals for Racelogic VBOX LapTimer

Summary of Contents for Racelogic VBOX LapTimer

  • Page 1 08 - VBOX LapTimer - Menu Options • 09 - VBOX LapTimer - Square Button Functions • 10 - VBOX LapTimer - Using as an OLED Display • 11 - VBOX LapTimer - Technical Properties • VBOX LapTimer - EC Declaration of Conformity •...

  • Page 2: Compatible Media

    Compatible media VBOX LapTimer can record to MMC, SD, SDHC and SDXC media cards that are formatted in a FAT or FAT32 format. SDXC cards will be formatted as exFAT by default, a format type not supported by VBOX LapTimer. They can still be used, as long as they have been reformatted to FAT32.

  • Page 3: Display Modes Overview

    Display Modes Overview VBOX LapTimer has different display modes, which can be accessed using the Up and Down buttons. The data on each screen is calculated at all times, even if it is not displayed. Live Speed Lap Timing Max. Speed...

  • Page 4: Hardware Connections

    Hardware Connections Standalone https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 5: With Video Vbox Pro

    With Video VBOX Pro https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 6: With Video Vbox Lite

    With Video VBOX Lite https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 7: With Video Vbox Waterproof

    With Video VBOX Waterproof https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 8: Obtaining The Best Gps Quality

    Obtaining the best GPS quality Placement of the GPS antenna is crucial to the quality of the data recorded by VBOX LapTimer. Any metal close to a GPS antenna can disturb the signal in an unpredictable way due to interference from reflections of weak GPS signals.

  • Page 9: Acquiring Satellite Lock

    GPS Coldstart If VBOX LapTimer is struggling to acquire satellite lock, a GPS coldstart may be required. This may be necessary when the unit hasn’t been used for a number of days or has dramatically moved location since its last use. To perform a cold- start, select MENU >...

  • Page 10: Max Speed

    In this mode the screen will display a large clear speed value to 2 decimal places. The speed can be set to display in kph, mph or knots. The number of decimal places displayed can be adjusted through the VBOX LAPTIMER menu.

  • Page 11: Speed Bar

    In this mode the screen will show a set centre speed with a bar graph indicating the speed between the set speed and the actual speed. Bar graph settings If the square button is pressed, the user can set the desired speed and configure the speed display range of the bar graph. https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 12: Fastest Lap

    04 - VBOX LapTimer - Lap Timing All lap times and split times are interpolated to 0.01 second resolution. In this mode the screen can display either a live rolling lap time or a static last lap time and the lap count. This is set from within the menu screen.

  • Page 13: Split Line Display

    Split line display If split lines have been set via the VBOX LapTimer main menu, then split times will be shown for between 2-20 seconds when the split line is crossed. See ‘split time display period’ section for setup info.
  • Page 14 05 - VBOX LapTimer - Predictive Lap Timing For this mode to work, a start/finish line is required. Make sure that a track layout is selected through the main menu, or set a start line manually. • Until the start line is crossed, the screen will show ‘Waiting for start line’...

  • Page 15: Delta-V Leds

    • Above this minimum Combo G selected, the LEDs will show a colour gradient between and GREEN, giving a changing YELLOW/ORANGE colour, dependent on the live Combo G. • The LEDs will show GREEN where the Combo G is equal to or greater than the maximum g threshold selected. https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 16: Save Reference Lap

    Save reference lap This feature allows the user to save a reference lap for future use, insert an SD card into VBOX LapTimer and use the menu options shown below. Note that the vehicle must be stationary to make this transfer.
  • Page 17 The amount of time shown on the bar graph can be altered in the main menu to 2, 5, 10 or 30 seconds. Additionally the LEDs on the front of the VBOX LapTimer indicate Delta-V. Red indicates that velocity is slower than the reference point and green faster.
  • Page 18 The lap count screen will display two lap counts. On the left hand side of the screen the total lap count is displayed – this counter will only be reset by a power cycle of the VBOX LapTimer. The right hand side of the screen displays the current laps and will be reset by removal of the logging media from VBOX LapTimer.
  • Page 19 07 - VBOX LapTimer - Lateral/Longitudinal g Lateral g Displays the current g within the vehicle as a live display whilst also displaying the maximum lateral g reached. This helps the driver push their vehicles that little bit harder during cornering.

  • Page 20: Lateral G Bar Display

    +3.0 g. The target g can be set within the same menu between -3.0 to +3.0 g to help reach the desired g on braking Within the menu, the user can also select to have an inverted target g labelled on the graph. https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 21: View Lap Times

    View lap times VBOX LapTimer will store all the lap times from the current session (maximum of 99 lap times). The lap times will be cleared when a new start line is set or the lap timing data is reset.

  • Page 22: Select Track

    When satellites have been acquired, the VBOX LapTimer will check the GPS location against Racelogic’s track map database and load the layouts available. The user must use this menu option to select the layout they are driving to allow the VBOX LapTimer to load correct start/finish line.

  • Page 23: Logging Status

    This range setting affects the sensitivity of the Delta-V LEDs. Settings of 2 kph, 5 kph and 10 kph are available – the default setting is 5 kph. Note: if the VBOX LapTimer is set to show speed in mph or knots, then these values will be the direct equivalent of the three values.

  • Page 24: Combo G Led Mode

    Save reference lap This feature allows the user to save a reference lap for future use, insert an SD card into VBOX LapTimer and use the menu options shown below. Note that the vehicle must be stationary to make this transfer.

  • Page 25: Lap Timing Menu

    Set Start & Splits After the square button is pressed a new start/finish point is set. After this the VBOX LapTimer will display “Set split 1”. Press square to set the split,▼to skip to additional split points, Finish line and back. If a new start/finish or split line is set then the lap count, best lap and all the best split time values automatically reset.
  • Page 26 Split time display period This function allows you to set how long the split time is shown for on the VBOX LAPTIMER display when a split line or the start/finish line is crossed. There is a choice of: 2 s, 5 s, 10 s, 15 s or 20 s, to select these options navigate to Main Menu - Lap timing Menu then highlight Split Time Display Period and use the square button to cycle through each option.

  • Page 27: Split To Split Time

    When one shot mode is enabled, timing will start when movement is detected, after being stationary for more than 10 seconds. This will automatically reset when the user comes to a stop. After 2 seconds of being stationary, the screen counts down from 5 then shows ARMED – Start when ready. https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 28: Display Menu

    Pressing the square button will cycle through KPH, MPH and KNOTS. Speed decimal places Pressing the square button will cycle through 0, 1, and 2 decimal places. Speed smoothing Pressing the square button will cycle through five smoothing settings. https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 29: Accel Settings

    Pressing the square button will cycle through five brightness settings labeled 1 - 5. The displays screen will change its brightness as each setting is cycled through. LED Brightness Pressing the square button with this option selected will cycle through five brightness settings for the Delta V LEDs used in Predictive LapTiming Mode. https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 30: Gps Options

    If the VBOX LapTimer is being fitted in a permanent install or if it is expected to experience some heavy vibrations when in use, then the user may wish to fix the orientation as this can trigger the sensitive internal gyro to flip the screen.

  • Page 31: Gnss Mode

    A new leap second is usually introduced every 4 to 7 years. The last leap second was added in December 2016. The current offset is 18 seconds - click here for more details. About In this section, the VBOX LapTimer serial number and installed firmware version is listed. https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...
  • Page 32 09 - VBOX LapTimer - Square Button Functions Depending which mode is currently active on the screen, the function of the square button will change. The splash screen shown when scrolling through the menu describes the square button function for each mode.

  • Page 33: Using With Video Vbox

    10 - VBOX LapTimer - Using as an OLED Display Using with Video VBOX VBOX LapTimer can be used as an OLED display when connected to a Video VBOX unit. The LapTimer will check for the presence of a Video VBOX unit when it is powered up.

  • Page 34: Video Vbox Lite

    Video VBOX Lite To connect VBOX LapTimer to a Video VBOX Lite, use a RLCAB123 cable (sold separately). https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 35: Video Vbox Pro

    Video VBOX Pro To connect VBOX LapTimer to a Video VBOX Pro, use a RLCAB122 cable (sold separately). https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 36: Using With Speed Sensor

    Using with Speed Sensor VBOX LapTimer can be used as an OLED display when connected to a Speed Sensor unit. The LapTimer will check for the presence of a connected unit when it is powered up. Connect the VBOX LapTimer as shown below, using the cables specified.

  • Page 37: Using With Vbox

    Using with VBOX VBOX LapTimer can be used as an OLED display when connected to a VBOX unit. The LapTimer will check for the presence of a connected unit when it is powered up. Connect the VBOX LapTimer as shown below, using the cables specified.

  • Page 38: Vbox Laptimer Pin Outs

    11 - VBOX LapTimer - Technical Properties Upgrading VBOX LapTimer VBOX LapTimer EC Declaration Firmware of Conformity VBOX LapTimer Standard VBOX LapTimer PIN OUTS Inventory VBOX LapTimer Technical Specification https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 39: Vbox Laptimer - Ec Declaration Of Conformity

    VBOX LapTimer - EC Declaration of Conformity We declare that this product has been tested to and meet the requirements of: EC directive 2004/108/EC “Adapting to technical progress council directive 72/245/EEC relating to the radio interference (electromagnetic compatibility) of vehicles and amending directive 70/156/EEC on the approximation of the laws of the member states relating to the type-approval of motor vehicles and their trailers.”...

  • Page 40: Connector 1 - Power (Lemo 2 Pin)

    VBOX LapTimer - PIN OUTS Connector 1 - POWER (Lemo 2 PIN) Function Power+ Ground Chassis Ground https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 41: Connector 2 - Rs232 / Can (Lemo 5 Pin)

    Connector 2 - RS232 / CAN (Lemo 5 PIN) Function RS232 Tx RS232 Rx CAN High CAN Low Power Connector 3 - GPS Antenna Function Signal Chassis Ground https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 42: Vbox Laptimer - Standard Inventory

    VBOX LapTimer - Standard Inventory Description Product Code VBOX LapTimer unit VBLAP01 Cigar lighter power cable RLCAB010L VBOX Suction mount RLACS125 4 GB SD Card RLACS137 External GPS/GLONASS Antenna RLACS215 https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 43: Vbox Laptimer - Technical Specification

    VBOX LapTimer - Technical Specification Dimensions https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...
  • Page 44 https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 45: General Specification

    178 g (exc. cable) GPS Specification Velocity Accuracy 0.1 km/h Units km/h or mph Update rate 20 Hz or 10 Hz* Maximum velocity 1800 km/h Minimum velocity 0.1 km/h Resolution 0.01 km/h *Version 1 units 20Hz only, Version 2 units 10Hz only. https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...
  • Page 46 ±5 m ** 95% CEP (Circle of Error Probable) means 95% of the time the position readings will fall within a circle of the stated radius. Acceleration Accuracy 0.5 % Maximum Resolution 0.01 g Heading Resolution 0.01° Accuracy ±0.1° https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...

  • Page 47: Vbox Laptimer - Upgrading Firmware

    VBOX LapTimer - Upgrading Firmware It is recommended to check the web site periodically for updates. The latest firmware for VBOX LapTimer can be found here. To perform an upgrade simply place the .upgrade file on the root directory of an SD card, insert the card into the VBOX LapTimer when it is turned off, hold down the top arrow and then apply power.
  • Page 48 12 - VBOX LapTimer - Troubleshooting See below for possible error messages and causes. YOU ARE >50KM FROM START LINE Over 50 km away from selected SF line. Check you have the correct track selected, note that it may be necessary to first select clear start and splits from the Lap timing Menu.
  • Page 49 To view available pre-loaded track map layouts, go to the LAP TIMING MENU and select CLEAR START & SPLITS. https://racelogic.support/02VBOX_Motorsport/VBOX_LapTimer/VBOX_LapTimer_-_User_Manual/...
