Schematic and Bill of Materials
Designator Quantit Value Description
y
U20 1
U23 1
VR1 1
Y1 1
Y2 1
FID1, FID2, FID3, 0
FID4, FID5, FID6
R40 0 0
TP1, TP2, TP14, 0
TP15
TP3, TP4, TP5, 0
TP6, TP11, TP12,
TP13
28 ADCx120EVM-PDK, PCMD3140EVM-PDK Evaluation Module
Table 7-2. AC-MB Bill of Materials (continued)
Level-Translating I2C Bus Buffer/
Repeater, DGK0008A (VSSOP-8)
Low-Capacitance + / - 15 kV ESD-
Protection Array for High-Speed Data
Interfaces, 2 Channels, -40 to +85 degC,
5-pin SOT (DRL), Green (RoHS & no
Sb/Br)
3-A Step-Down Converter with DCS-
Control and Hiccup Short Circuit
Protection in 2x2 HotRod Package,
RLT0007A (VSON-HR-7)
OSC, 24 MHz, 2.25 - 3.63 V, SMD
Crystal, 24.576 MHz, 10pF, SMD
Fiducial mark. There is nothing to buy or
mount.
RES, 0, 1%, 0.1 W, AEC-Q200 Grade 0,
0603
Test Point, Miniature, Red, TH
Test Point, Miniature, Green, TH
Copyright © 2021 Texas Instruments Incorporated
Package Part Number
Reference
DGK0008A TCA9802DGKR
DRL0005A TPD2E001DRLR
RLT0007A TPS62085RLTR
2x1.6mm ASTMLPA-24.000
MHZ-EJ-E-T
2.5x0.5x2.0mm ABM10-24.576MH
Z-E20-T
N/A N/A
0603 RMCF0603ZT0R0
0
Red Miniature 5000
Testpoint
Green Miniature 5116
Testpoint
