IMPORTANT
Part List
A.
Top
1 pc.
B.
Rail
2 pcs.
C.
Rail
3 pcs.
E.
Bottom
1 pc.
Hardware List
Hex Wrench
1 pc.
Small Hex Wrench
1 pc.
Carton 20 05520 0912 is also needed for assembly.
Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/16" Drill Bit, 3/8" Drill Bit
20 05520 0911
Storage Island
Flat Washer
Cam Lock
12 pcs. (+1 extra)
26 pcs. (+6 extra)
Cam Lock Screw
Adjustable Pin
26 pcs. (+2 extra)
12 pcs. (+1 extra)
D.
Back Panel
1 pc.
F.
Plinth
2 pcs.
M6x32
Spring Washer
Head Cap Bolt
12 pcs. (+1 extra)
12 pcs. (+1 extra)
M3 x
.5 32
M4x16
Wood Screw
Machine Screw
4 pcs. (+1 extra)
8 pcs.
Handle
4 pcs.
