IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
Part List
A.
Top
1 pc.
F.
Fixed Shelf
1 pc.
H.
Back Panel
1 pc.
Hardware List
M x
6 35
Hex Wrench
Head Cap Bolt
1 pc.
8 pcs. (+1 extra)
Small
Hex Wrench
Cam Lock
1 pc.
22 pcs. (+4 extra)
Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/8" Drill Bit
Home Styles Customer Service: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com,
20 05506 0307
Hutch
B.
Side Panel
1 pc.
I.
Back Panel
1 pc.
Adjustable Pin
12 pcs. (+1 extra)
Cam Lock Screw
22 pcs. (+2 extra)
C.
Side Panel
1 pc.
M
3.5
x1
5
M
3.5 20
Wood Screw
Wood Screw
for Hinge
for Bracket
24 pcs. (+1 extra)
8 pcs. (+1 extra)
M4x25
Hinge
Machine Screw
4 pcs.
4 pcs.
888-680-7460, 877-831-0319
E.
D.
Middle Panel
Middle Panel
1 pc.
1 pc.
G.
Shelf
3 pcs.
J.
K.
Door
Door
1 pc.
1 pc.
x
Handle
2 pcs.
Bracket
2 pcs.
