IMPORTANT
Carefully remove all the parts from the carton and
place them individually on a soft cloth to prevent
scratches or other damage.
Carefully and strictly follow these assembly instructions
to ensure a completed product as designed.
Do not use power tools above 8 volts to assemble.
B.
C.
Side Panel
Side Panel
1 pc.
1 pc.
M.
Rail
1 pc.
N.
Rail
4 pcs.
Magnet
2 pcs.
M3x14
Wood Screw for Magnet
4 pcs. (+1 extra)
Carton 20 05427 0691 is also needed for assembly.
Tool(s) required for assembly: Phillips screwdriver, Level, Drill (8 volts or less), 3/8" Drill Bit
Home Styles Customer Service: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com,
20 05427 0692
Pantry
G.
H.
Side Panel
Side Panel
1 pc.
1 pc.
F.
O.
Foot
Door
4 pcs.
1 pc.
M3.5x38
Wood Screw (long)
2 pcs. (+1 extra)
M3x15
Wood Screw
4 pcs. (+1 extra)
I.
J.
Back Panel
Upright
2 pcs.
1 pc.
P.
Door
1 pc.
M4x19
Machine Screw
2 pcs.
Adjustable Pin
16 pcs. (+1 extra)
888-680-7460, 877-831-0319
K.
L.
Back Panel
Upright
2 pcs.
1 pc.
Q.
R.
Door
Door
1 pc.
1 pc.
M4x32
Machine Screw (long)
4 pcs.
Knob
6 pcs.
