5 Troubleshooting

When the printer has a malfunction, please handle it with reference to this charter. If it still can not be cleared,
please contact your local dealer.
5.1 Troubleshooting
The error LED flashes and the buzzer beeps when an error or exceptional status occurs. At this time, the printer
stops the printing. Please handle it with reference to the following method:
Error indication mode:
Error message
Print head up
Paper end
Abnormal temperature of
print head
Mark location failure
Mark calibration error
Buzzer
2 beeps Flash 2 times circularly
3 beeps Flash 3 times circularly
No beep Flash 5 times circularly
No beep Flash 6 times circularly
No beep Flash 7 times circularly
- 17 -
Error LED
Display LOGO and "COVER OPEN"
Display LOGO and "PAPER END"
Display LOGO and "PRINT HEAD
TOO COLD OR HOT"
Display LOGO and "MARK ERROR"
Display LOGO and "CALIBRATION
FAILED"
