3 Printer operations

3.1 LED, buzzer, feed button and LCD

3.1.1 LED functions

LED name
Work LED (green)
Pause LED (orange)
Error LED (red)

3.1.2 Button functions

Button
Short press
Menu switching
Parameter selection
Enter the menu
Menu selection
Long press
Parameter confirmation
Note:
Short press means the duration from pressing down the button to the time when the button uplifts is less than
0.5s. Long press means the duration of pressing down the button is more than 1s.

3.1.3 Buzzer functions

The buzzer beeps for a short time when the printer is turned on or reset;
1)
The buzzer beeps many times when an exception occurs. For the details, please refer to 5.1
2)
Troubleshooting.

3.1.4 LCD functions

LCD is used to display the printer status and menu and configure the printer parameters by cooperating with
the button.

3.2 Printer status and operation

3.2.1 Printer status

The printer has five statuses: idle, working, pause, configuration, and abnormal. Refer to next page.
Status
Always on
Flash twice
Always on
Flash
Function
Feed In standby status, press the button for a short time to feed label/paper.
Pause During the printing, press the button for a short time to enter pause status.
After the printer enters pause status, press the button for a short time to resume
Continue
the printing.
After entering the menu, press the button for a short time to switch the menu.
After entering the submenu, press the button for a short time to select the
parameter.
When the printer is idle, press the button for a long time to enter the menu.
After entering the menu, press the button for a long time to select the current
menu.
When setting the parameter, press the button for a long time to validate the
current parameter.
Printer is idle or working.
Prompt that the menu or parameter selection becomes effective.
See 3.2.2 Daily operations for details.
Printer is in pause status.
An error occurs. See 5.1 Troubleshooting for details.
Explanation
