- Page 1 Installation Manual Victory Crossroads, Cross Country and Cross Country Touring Glenda/Darla LED Light Dimmable...
- Page 2 Step 1: Parts List and Bike Preparation Please be sure to read our instructions thoroughly before attempting installation. • Check Parts list supplied with your kit to be sure all parts are handy. • First, park the motorcycle on hard pavement or concrete to insure the bike will be stable during the installation.
- Page 3 Step 2: Mounting The Lights Different Mounting Options: • There are three different mounting options that can be used on the Victory Crossroads and Cross Country bikes. The options are dependant on user preference and available mounting space. Oil Cooler Mount Fork Mount Crash Bar...
- Page 4 Step 2: Mounting The Lights Oil Cooler Mount: • One side at a time, remove fairing bolt at desired mounting location. Be sure to keep fairing from hanging in a manner that damages it. Use a wire tie or piece of wire to hold the fairing until you are ready to install the new bolts.
- Page 5 Step 2: Mounting The Lights Fork Mount: • Pre-assemble the lights, mounting bracket and spacers with new bolts. • Remove the front fender bolt and mount included bracket with new hardware. See image below. • Gently screw all bolts in hand tight. Inspect the bolt length and spacer alignment before tightening the bolts.
- Page 6 Step 2: Mounting The Lights Crash Bar Mount: • Attach the lights to the crash bars using the provided crash bar mounting clamps as shown in the exploded view and picture below. • Do not mount in a position that interferes with your legs or feet while riding. •...
- Page 7 Step 3: Mounting The Volume Control Knob Mounting The Volume Control Knob: (Handlebar Mount) • Mount the volume control knob to handlebar by using supplied bracket, bolt and clamp. • Route wires from lights and volume control knob bracket to area under left side of forks.
-
Page 8: Electrical Connections
Step 4: Wiring Wire Routing: • Be sure to route wires so that they cannot become tangled or caught in either a suspension part or steering part. Check movement of both steering and suspension before riding the bike. • It is sometimes helpful to follow existing wire routing. Electrical Connections: (A) Main power needs to be connected to a switched hot. - Page 9 Step 4: Wiring Page 9...
- Page 10 Step 5: Alignment Aligning the Lights: (Fork mount shown) Ask an assistant to help you with this procedure. Make sure the bike is on level ground and have an assistant sit on the bike. With a right angle board or object, position the board on the floor and slide it up to the light. The goal is to adjust the lights so that the light is level with the ground.
-
Page 11: Helpful Hints
Helpful Hints: Using a Drip Loop: • Though our lights are sealed for ultimate all weather use, sometimes water sneaks by. To make sure this doesn’t happen, we highly suggest using a drip loop. When installing the wiring to your lights, use a drip loop as shown below. - Page 12 Thank you for purchasing your Clearwater lights. We hope this product will help make you a safer rider. Please feel free to send us comments or suggestions at any time. We learn from you. Visit our website for more exciting products.
