Summary of Contents for ClearWater Lights Krista
- Page 2 Step 1: Parts List and Bike Preparation Please be sure to read our instructions thoroughly before attempting installation. • Check Parts list below with your kit to be sure all parts are handy. If something is missing, please call us at (916) 852-7029. Page 2 Page 1...
- Page 3 Step 1: Parts List and Bike Preparation Please be sure to read our instructions thoroughly before attempting installation. • Check Parts list below with your kit to be sure all parts are handy. If **NOTE** This page is for the 1290 Super Adventure R only Page 3 Page 2...
- Page 4 Erica / Krista / Sevina are very bright LED auxiliary lights. Do not use these with oncoming traffic present unless the dimmer is turned down all the way. Krista / Erica / Sevina are designed as off road only light’s due to the powerful light output and specific beam pattern they boast.
- Page 5 Step 1: Parts List and Bike Preparation Step 2: Mounting The Lights / Crash Bar Mount Mounting The Lights: (Crash Bar) Mounting the Lights to the Crash Bar is very simple. Pre- assemble the lights, and mounting bracket loosely with the supplied parts.
- Page 6 Step 2: Mounting The Lights / Fender Mount Mounting The Lights: (Fender Mount) -OPTIONAL Clearwater Lights comes with an assortment of stainless steel bolts that can allow a variety of installations. Pre-assemble the lights, mounting bracket, shoulder washers and spacers with new bolts.
- Page 7 Step 1: Parts List and Bike Preparation Step 3: Disassembly Disassembly Step 2 Step 1. Remove windshield (T30 x 4) Step 2. Remove windshield bracket (T30 x 4) Step 3. Remove side covers (T30 x 3) Disconnect fog lights Step 4. Remove tank cover (T30 x 5) and (8mm Bolt Location bolt x 2) Step 1...
- Page 8 Step 3: Disassembly Disassembly Step 5. Remove turn signal covers (T30 x 2) Make note that these bolts are longer than the rest Step 6. Remove headlight (T30 x 4) Disconnect headlight connector, this is the connector that is going to have the jumper in between Step 7.
- Page 9 Step 3: Disassembly **NOTE** This page is for the 1290 Super Adventure R only T30 bolt Headlight adjuster knob T30 bolt Fig. D The headlight assembly is also held down by the bolts shown above in (Fig. D). Remove the top torx bolt (shown above on the left, but also on the right), the lower torx bolt, and the headlight adjuster knob.
- Page 10 Step 4: Wiring Wiring: • We highly recommend you take a minute to review the wiring diagram below before starting the wiring portion of the installation. Once you feel comfortable with the information below you are ready to begin the electrical portion of the installation.
- Page 11 Step 4: Wiring (1290 Super Adventure R, 2017+) **NOTE** This page is for the 1290 Super Adventure R only Page 11 Page 10...
- Page 12 Step 4: Wiring Mounting The Control Knob: (Bar Mount) • Mount the Volume Control Knob to handlebar by using supplied bracket and bolt to the existing controls. • Route wires from lights and volume control knob bracket to area under left side of forks. Connections can be made here and be kept weatherproof.
- Page 13 Step 4: Wiring (1290 Super Adventure R, 2017+) **NOTE** This page is for the 1290 Super Adventure R only Headlight Connector Fig. F Locate the connector that was plugged into the headlight assembly (Shown above in Fig. F). Connect the included jumper plug to the male and female ends of the headlight connector on the bike.
- Page 14 Step 4: Wiring Electrical: • Run the Red and Black power wires directly to the battery. The fuse will protect the system in the event of a short. • Mount the power relay box in a safe location (see photo below for one recommended location).
- Page 15 Step 5: Alignment / Drip Loop Instructions Aligning The Lights: As Erica, Krista, and Sevina are designed as auxiliary lights, adjustment is up to the user depending on his needs. Ask an assistant to help you with this procedure. Make sure the bike is on level ground and have an assistant sit on the bike.
- Page 16 Version 1.8 12/6/17...
