- Page 2 Parts List and Bike Preparation Please be sure to read our instructions thoroughly before attempting installation. • Check Parts list below with your kit to be sure all parts are handy. If something is missing, please call us at (916) 852-7029. Page 2 Page 1...
- Page 3 Step 1: Disassembly Bike Preparation: • First, park the motorcycle on hard pavement or concrete to insure the bike will be stable during the installation. If you can mount the bike on a stand with tie-down straps, this will help secure the motorcycle. •...
- Page 4 Step 2: Mounting the lights 5mm Hex Key 5mm Hex Key Fig. 3 Fig. 3 Remove the two M6 bolts as shown above (Fig. 3) on both sides of the bike. It is helpful to remove the bolts and install our bracket on one side at a time.
- Page 5 Step 3: Wiring Page 5 Page 4...
- Page 6 Step 3: Wiring NOTE: Before proceeding with wiring the lights, take a moment to review the wiring diagram. Keep the diagram handy throughout the installation. Mounting The Volume Control Knob: (Bar Mount) Mounting The Volume Control Knob: (Bar Mount) Fig. 6 Fig.
- Page 7 Step 3: Wiring Wire Routing: • Be sure to route wires so that they cannot become tangled or caught in either a suspension part or steering part. Check movement of both steering and suspension before riding the bike. • It is sometimes helpful to follow existing wire routing. •...
- Page 8 Step 3: Wiring Tap white wire from volume control knob to this yellow wire. Fig. 7 Fig. 7 Tap thin red wire from relay Tap thin red wire from relay harness to this orange wire harness to this orange wire Fig.
- Page 9 Clearwater Lights. Aligning the Lights: Ask an assistant to help you with this procedure. Make sure the bike is on level ground and have an assistant sit on the bike.
- Page 10 Notes Page 10 Page 9...
- Page 11 Notes Page 11 Page 10...
- Page 12 Revised 6/22/20...
