- Page 2 **NOTE** **NOTE** The table below is only a quick summary guide of all the CANopener features. See The table below is only a quick summary guide of all the CANopener features. See Step 1: Parts List and Bike Preparation the details of each feature throughout this manual.
- Page 3 • No separate switch required, uses factory turn signal cancel button Turn Signal Dimming • Clearwater Lights can be set to dim while turn signals are activated. Horn Activation Mode • Programmable to illuminate or strobe with horn button (off road use...
- Page 4 CANopener Mounting Locations The CANopener module can be found mounted under the seat on most liquid The CANopener module can be found mounted under the seat on most liquid cooled BMW’s. cooled BMW’s. CANopener location on a R1200GSW/GSAW Front of Bike...
- Page 5 CANopener Mounting Locations Lean angle sen- Lean angle sen- sor location. sor location. CANopener location on a K1600GT. Front of Bike Front of Bike CANopener location on a R1200RTW. Front of Bike Front of Bike Tire Pressure Monitor hid- Tire Pressure Monitor hid- den here under frame.
- Page 6 Clearwater CANopener operation and features DIMMING CONTROL (Wonder Wheel equipped bikes) DIMMING CONTROL (Wonder Wheel equipped bikes) Information on Dimming Information on Dimming: : Two modulated brightness channels are adjustable using Each channel is programmable for (11) brightness settings (3, the Wonder Wheel.
- Page 7 TURN SIGNAL DIMMING TURN SIGNAL DIMMING The front Clearwater lights, and Billie tail light can be programmed to dim when the turn signals are activated. To toggle the Turn Signal Dimming mode on and off, press and release the (TSC) button, hold the right turn signal while pressing and releasing the front brake lever 5 times.
- Page 8 FTP button (See Fig. A below) (5) times: • Mode 1 – All Clearwater lights turn on 100% when high beam or flash-to- pass is pressed. Krista/Erica/Sevina lights will not turn on with high beam or flash-to-pass if Krista/Erica/Sevina lights are switched off.
- Page 9 FACTORY DEFAULT RESET FACTORY DEFAULT RESET To reset the CANopener to the factory settings, press and release the (TSC) button, hold the left turn signal switch and press and release the flash-to-pass button (6) times . All factory preset dimmer levels and modes will be selected. A successful reset is indicated by five flashes of all Clearwater lights.
- Page 10 Notes Page 10 Page 9 Page 9...
- Page 11 Notes Page 11 Page 10 Page 9...
- Page 12 As Of 3/6/2020...
