Designation Code

Safety light curtains from the SLCS series are designated by a code
according to the following format:
S L C S XX - YYYY - Z - AAAA
XX indicates the obstacle size, YYYY the protection field height, Z the device type,
i.e. transmitter (t) or receiver (R), and AAAA the design specification applicable in
individual cases.
Obstacle size
XX [mm]
14
30
60
90
Designation Code
Obstacle
size [mm]
14
Protection field
height
YYYY [mm]
100, 200, 300, ...
1200
100, 200, 300, ...
2400
300, 600, 900, ...
2400
300, 600, 900, ...
2400
Protection field
height [mm] Complete
100 SLCS14-100
200 SLCS14-200
300 SLCS14-300
400 SLCS14-400
500 SLCS14-500
600 SLCS14-600
700 SLCS14-700
800 SLCS14-800
900 SLCS14-900
1000 SLCS14-1000
1100 SLCS14-1100
1200 SLCS14-1200
Device type Design
specification
Z AAAA
T, R No specification
T, R No specification
T, R No specification
T, R No specification
Transmitter(-T) Receiver(-R)
SLCS14-100-T SLCS14-100-R
SLCS14-200-T SLCS14-200-R
SLCS14-300-T SLCS14-300-R
SLCS14-400-T SLCS14-400-R
SLCS14-500-T SLCS14-500-R
SLCS14-600-T SLCS14-600-R
SLCS14-700-T SLCS14-700-R
SLCS14-800-T SLCS14-800-R
SLCS14-900-T SLCS14-900-R
SLCS14-1000-T SLCS14-1000-R
SLCS14-1100-T SLCS14-1100-R
SLCS14-1200-T SLCS14-1200-R
