- Page 1 FACTORY AUTOMATION MANUAL KFU8-FSSP-1.D-Y Frequency voltage converter (40 kHz version)
- Page 2 KFU8-FSSP-1.D-Y With regard to the supply of products, the current issue of the following document is ap- plicable: The General Terms of Delivery for Products and Services of the Electrical Indus- try, published by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the...
-
Page 3: Table Of Contents
KFU8-FSSP-1.D-Y Safety ................... 4 Introduction ..................4 1.1.1 Contents .................... 4 1.1.2 Target Group, Personnel ..............4 1.1.3 Symbols Used..................4 Product Description ..............6 Device description ................6 Operation..................7 Operating mode ................... 7 Setup mode ..................7 Anhang ..................12 Terminal assignment ................. -
Page 4: Safety
KFU8-FSSP-1.D-Y Safety Safety Introduction 1.1.1 Contents This document contains information that you need in order to use your product throughout the applicable stages of the product life cycle. These can include the following: Product identification ■ Delivery, transport, and storage ■... - Page 5 KFU8-FSSP-1.D-Y Safety Warning Messages You will find warning messages, whenever dangers may arise from your actions. It is mandatory that you observe these warning messages for your personal safety and in order to avoid property damage. Depending on the risk level, the warning messages are displayed in descending order as...
-
Page 6: Product Description
Product Description Product Description Device description The frequency voltage/current converter KFU8-FSSP-1.D-Y is a device for displaying and monitoring periodical signals which occur in almost all areas of process automation, i.e. from general frequencies to specific speeds. The input signals are evaluated and converted into a frequency or speed by a powerful - controller in accordance with the cycle method. -
Page 7: Operation
KFU8-FSSP-1.D-Y Operation Operation Operating mode Signal frequency The frequency voltage/current converter processes input signals of 0.002 Hz ... 40000 Hz or speeds of 0.01 rpm ... 9999 rpm. Signals not having a duty rate of 1:1 must have a minimum pulse pause or pulse duration of 12 s in order to be detected with certainty behind the input... - Page 8 KFU8-FSSP-1.D-Y Operation Note! You can modify the parameters in the parameter value display (flashing digits). The parameters come into effect temporarily until the operating voltage is interrupted. Transition setup mode operating mode Exiting setup mode Press the "Enter" and "+" buttons at the same time.
- Page 9 KFU8-FSSP-1.D-Y Operation Measurement range full scale reading (factory preset: 9999) In frequency measurement, the set value is measured in Hz or in speed measurement it is measured rpm (depending on function selection) it determines the frequency or speed at the analog output of the maximum voltage of 10 V or the maximum current of 20 mA.
- Page 10 KFU8-FSSP-1.D-Y Operation Four measuring and display ranges are available for frequency measurement and three measuring and display ranges are available for speed measurement: Display in parameter Frequency range in Number of decimal editor Speed range in rpm places 0000 0 ... 9999 000.1...
- Page 11 KFU8-FSSP-1.D-Y Operation 5 periods Example: 2 periods division factor = 5 output level high: (5-1)/2 = 2 periods approx. 20 µs approx. 20 µs Figure 3.3 Division factor 5 Range: 1 ... 9999 Software version number Note! You can only read out the version number of the software.
-
Page 12: Anhang
KFU8-FSSP-1.D-Y Anhang Anhang Terminal assignment Term. 1: Sensor power supply GND Term. 10: Not connected Term. 2: Pulse output Term. 11: Power supply 24 V , L + Term. 3: Not connected Term. 12: Power supply 24 V , L - Term. -
Page 13: Connection Diagram
KFU8-FSSP-1.D-Y Anhang Connection diagram Not connected I+ / U+ Not connected Ri ≤ 600 Ω DC-3-wire DC-3-wire Sensor power supply 24 V sensor, PNP sensor, NPN 7, 15 I– Ri ≥ 330 Ω Galvanically isolated input for 13, 14 L–... -
Page 14: Functional Description
KFU8-FSSP-1.D-Y Anhang Functional description Operating mode – MODE – MODE Function selection: MODE X=0: Frequency measurement 0.002 Hz...9999 Hz X=1: Speed measurement 0.01 min ...9999 min ENTER Factory set: X = 1 – Display and measurement range: MODE 0 ≤ X ≤ 3 at frequency measurement 0 ≤... - Page 15 Twinsburg, Ohio 44087 · USA Tel. +1 330 4253555 E-mail: sales@us.pepperl-fuchs.com Asia Pacific Headquarters Pepperl+Fuchs Pte Ltd. Company Registration No. 199003130E Singapore 139942 Tel. +65 67799091 E-mail: sales@sg.pepperl-fuchs.com www.pepperl-fuchs.com Subject to modifications 182827 / DOCT0646C_ENG Copyright PEPPERL+FUCHS • Printed in Germany 09/2016...
