Safety Light Curtain SLCS Contents 1 Introduction................. 3 2 Declaration of conformity ..........4 Declaration of Conformity................4 3 Safety ................... 5 Symbols relevant to safety ................5 Intended use ....................5 General Safety Information ................5 4 Product Description ............7 Use and Application ..................7 Indicators and Operating Controls ..............8...
Introduction Introduction Congratulations You have chosen a device manufactured by Pepperl+Fuchs. Pepperl+Fuchs develops, produces and distributes electronic sensors and interface modules for the market of automation technology on a worldwide scale. Before you install this device and put it into operation, please read the operating instructions thoroughly.
European standards and guidelines. Note! A Declaration of Conformity can be requested from the manufacturer or downloaded from www.pepperl-fuchs.com. The product manufacturer, Pepperl+Fuchs GmbH, 68307 Mannheim, Germany, has a certified quality assurance system that conforms to ISO 9001. ISO9001 4 - EN...
Non-observance could interrupt the device and any connected systems and plants, or result in their complete failure. Intended use The SLCS safety light curtain may only be used in accordance with its intended purpose as electro-sensitive protective equipment (ESPE) for securing hazardous areas and dangerous locations.
Page 8
If serious faults occur, stop using the device. Secure the device against inadvertent operation. In the event of repairs, return the device to your local Pepperl+Fuchs representative or sales office. Note! Observe the laws and guidelines applicable to the use or intended purpose. The device is only approved for appropriate and intended use.
■ Description The SLCS safety light curtain consists of an transmitter and a receiver. The protection field is formed by infrared light beams sent from the transmitter to the receiver. The offset between the individual light beams determines the minimum obstruction size (14, 30, 60 or 90 mm) that can be reliably detected in the entire protection field range.
Safety Light Curtain SLCS Product Description Transmitter unit Receiver unit Protection 24 V supply 24 V supply OSSDs Test Beam Code A/B Status / Select RI-RM Restart Interlock (RI) Relay Monitor (RM) Beam Code A/B Figure 4.1 Schematic diagram of a detection device Indicators and Operating Controls The transmitter has two LEDs to display its operating status.
Safety Light Curtain SLCS Product Description Designation LED color Description Restart/status Yellow On: protection field free: system ready to start Indicator flashing at 1 Hz: external fault Indicator flashing at 2.5 Hz: insufficient function reserve Indicator flashing at 5 Hz: internal fault...
Safety Light Curtain SLCS Installation Installation Preparation Safety distance A minimum distance must be maintained between the protection field and the hazardous area to ensure potentially dangerous movements are brought to a stop before there is contact with a person.
Page 14
Safety Light Curtain SLCS Installation Notes on setting up safety light curtains The safety device must be arranged in such a manner that it is impossible to reach over, reach under, or walk behind the protection field. If the distance from the safety device is too great, additional safety equipment must be put in place (see illustration below).
Safety Light Curtain SLCS Installation Mounting Various brackets are available for securing the safety light curtain (see chapter 9.8). Mounting 1. Align the transmitter and receiver so that they are parallel with one another and at the same height. 2. Align the transmitters and receivers parallel with one another.
Page 16
Safety Light Curtain SLCS Installation Example: vertical arrangement = 50 ms = 300 ms Hand protection C = 128 mm S = 2000 mm/s * (350 * 10 s) + 128 mm S = 700 mm + 128 mm = 828 mm As S is >...
Safety Light Curtain SLCS Installation Reflection Reflecting object outside beam area Minimum interval a Sending unit Receiving unit Obstacle Ensure that there are no reflective objects within the transmitter or receiver path that could deflect the beams around an obstruction (EN 61496-2).
Safety Light Curtain SLCS Installation Connection and Operating Mode Setting Both the power supply and the system settings can be connected to the transmitter and receiver. The following operating mode settings are also available: Startup interlock operating mode ■ Relay monitor operating mode ■...
Operating mode A or operating mode B must be configured both on the transmitter and on the receiver. The modes are used to prevent mutual interference from adjacent SLCS safety light curtains (see chapter 6.2). The operating mode is selected by connecting the A/B mode input. When connected to 0 V (recommended) or an open input, the safety light curtain operates in mode A.
Safety Light Curtain SLCS Installation 5.4.2 Signal Inputs on the Transmitter Unit Test input Connect the test input to 24 VDC via an NC contact. The test function is triggered by opening the contact. Note! During operation without a startup/restart interlock, the test time must be limited to 150 ms.
Safety Light Curtain SLCS Installation A/B mode input The A/B mode input is located both on the transmitter and on the receiver. If the input is open or connected to 0 V, the safety light curtain operates in mode A. The inputs must be connected to the supply voltage to switch to mode B.
Page 22
Safety Light Curtain SLCS Installation Relay monitor input Auxiliary contacts on switching elements connected downstream of the OSSDs can be connected to the relay monitor input. This allows these elements to be monitored. Use NC contacts (see chapter 5.4.4). All monitored switching elements must be connected in series.
Safety Light Curtain SLCS Installation 5.4.4 Typical circuits 24 V K2.1 Transmitter unit Receiver Restart unit K1.1 24 V 24 V Relay monitor Mode A/B Status / Select OSSD1 Test OSSD2 Mode A/B Figure 5.5 Connection example with relay monitor and restart in Mode A...
Safety Light Curtain SLCS Commissioning Commissioning Functional Testing 1. Check whether the transmitter and receiver are aligned parallel to one another and are at the same height. 2. Switch on the safety light curtain when the protection field is clear.
Page 25
Safety Light Curtain SLCS Commissioning If the transmitter and receiver of two safety light curtains are operated in different modes, an arrangement according to the following figures can also be chosen. Mode A Mode B Figure 6.2 Multiple layout with different beam coding (mode)
Safety Light Curtain SLCS Maintenance and Repair Maintenance and Repair Maintenance The safety light grid is maintenance-free. The prescribed periodic checks must be performed and documented. The checks must determine whether the components are fitted securely and whether the optical surfaces are clean.
Safety Light Curtain SLCS Troubleshooting Troubleshooting Troubleshooting Note! Always carry out a function check on the device after correcting a fault. If a fault occurs, press the test contact (Reset). The receiver removes the fault state by performing a system reset.
Safety Light Curtain SLCS Appendix Appendix Technical Data General specifications Effective detection 0.4 ... 8 m range Light source IRED Light type modulated infrared light , 850 nm LED risk group Free group in accordance with DIN EN 62471 designation Protection field height See chapter 9.2...
Page 29
Safety Light Curtain SLCS Appendix A/B mode input Function Beam Code A: open or 0 V Beam Code B: 24 V DC, 5 mA Inputs on the receiver unit Relay monitor input Input format Break contact Switching voltage 24 V DC (acting on the contact)
Safety Light Curtain SLCS Appendix Mechanical specifications Housing length L See chapter 9.3 Degree of protection IP65 , For indoor use only Connection Transmitter unit: 4-pin, M12 x 1 connector Receiver: 8-pin, M12 x 1 connector Cable cross section min. 0.25 mm Max.
Safety Light Curtain SLCS Appendix Conformity with Standards and Directives CE conformity UL approval cULus Listed UL File Number E215245 CCC approval Products with a maximum operating voltage of 36 V are not subject to approval and are therefore not assigned a CCC mark.
Safety Light Curtain SLCS Appendix Designation Code Safety light curtains from the SLCS series are designated by a code according to the following format: S L C S XX - YYYY - Z - AAAA XX indicates the obstacle size, YYYY the protection field height, Z the device type, i.e.
Safety Light Curtain SLCS Appendix Protective field Response time [ms] height [mm] SLCS14-... SLCS30-... SLCS60-... SLCS90-... 2200 2300 2400 The switch-on time after beam interruption without a restart function is between 80 ms and 200 ms. The time depends on the number of protective beams.
Before installation Have all the applicable standards and regulations been observed? ■ Does the technical data of the SLCS meet the requirements of the ■ application? This especially applies to detection capability, the protection field height, and the operating voltage.
Periodic check Have the requisite tests and test intervals been determined? ■ Is the detection capability of the SLCS tested regularly over the entire ■ protection field height using the test rod? Are the response times checked at regular intervals? ■...
The mounting brackets are also suitable for use as a corner profile if two independently acting light curtains are to be installed. Suitable mounting brackets can be found on the Pepperl+Fuchs website by searching for SLCT-M*. 9.8.1 Mounting Aid OMH-SLCT-01...
Page 40
Safety Light Curtain SLCS Appendix Drücken = Schließen Drücken = Öffnen Push = close Push = open Presser = fermer Presser = ouvrir Apretar = cerrar Apretar = abrir Figure 9.5 Opening and closing of the mounting aid OMH-SLCT-01 Figure 9.6...
Safety Light Curtain SLCS Appendix 9.8.2 Mounting Aid OMH-SLCT-02 Model number: OMH-SLCT-02 The OMH-SLCT-02 mounting aid is used as a fixed bearing and secures the position of the light curtain in the event of thermal expansion, vibration, or shock. OMH-SLCT-02 OMH-SLCT-01 ø...
Page 42
Safety Light Curtain SLCS Appendix 22.3 Figure 9.8 Mounting aid OMH-SLCT-03 (fixed bearing) 22.3 Figure 9.9 Mounting aid OMH-SLCT-04 (loose bearing) Figure 9.10 Example of mounting a mounting aid OMH-SLCT-03 or OMH-SLCT-04 to a mounting column 40 - EN...
SLCS and SLCT series without additional accessories. Features large swivel range of -7° .. +110° ■ very robust ■ easily accessible screws ■ Integrated dovetail for mounting SLCS and SLCT series ■ 25.1 15.2 Figure 9.11 Mounting aid OMH-SLCT-05 EN - 41...
Safety Light Curtain SLCS Appendix 9.8.5 Alignment aid Order code: AA-SLCT-01 The transmitter and receiver should always be aligned at the same height in parallel to one another. The AA-SLCT-01 alignment aid with bubble level assists the perpendicular alignment of the profile. The AA-SLCT-01 alignment aid is simply clipped into the groove on the side of the profile.
Safety Light Curtain SLCS Appendix Figure 9.13 TR 14/30/50/60 test rod 9.8.7 Connection Cables Various 4-pin and 8-pin connection cables are available in a range of lengths. Connection cables are not included in the scope of delivery of a safety light curtain.
