Safety Light Curtain SLCS
Appendix
EN
9.1.1
28 - EN
Mechanical specifications
Housing length L
Degree of protection
Connection
Material
Housing
Optical face
Mass

Standards

Functional Safety Data
Safety Integrity Level
(SIL)
Performance Level (PL)
Category
Life time (T )
M
Type
PFHd
1.Finger protection, 14 mm up to a protection field height of 300 mm -> 1.36E-8
Conformity with Standards and Directives
Directive conformity
Machinery Directive
2006/42/EC
EMC Directive
2004/108/EC
Conformity with standards
Functional safety
Standards
See chapter 9.3
IP65 , For indoor use only
Transmitter unit: 4-pin, M12 x 1 connector
Receiver: 8-pin, M12 x 1 connector
Cable cross section min. 0.25 mm
Max. cable length 50 m
extruded aluminum section , gold anodized
Plastic pane , Transparent polycarbonate
See chapter 9.2
SIL 3
PL e
Cat. 4
20 a
4
1
SLCS14-300: 1.36E-8
SLCS14-600: 1.67E-8
SLCS14-900: 1.94E-8
SLCS30-600: 1.31E-8
SLCS30-900: 1.43E-8
SLCS30-1200: 1.55E-8
SLCS30-1800: 1.79E-8
SLCS30-2400: 2.00E-8
SLCS60-xxxx: 1.69E-8
SLCS90-xxxx: 1.58E-8
The PFHd values specified apply up to the maximum ambient
temperature
EN ISO 13849-1:2008; EN 61496-1:2013
EN 61000-6-3:2007+A1:2010; EN 61000-6-4:2007+A1:2011
IEC 61508:2010 part 1-4
IEC 61496-2:2013
2
