Bios Introduction - Spectra PowerBox 3000C Series User Manual

4.1 BIOS Introduction

The BIOS (Basic Input/ Output System) is a program located on a Flash Memory on the
motherboard. When you start the computer, the BIOS program will gain control. The BIOS
first operates an auto-diagnostic test called POST (power on self-test) for all the necessary
hardware, it detects the entire hardware device and configures the parameters of the
hardware synchronization.
BIOS Setup
Power on the computer and by pressing <Del> immediately allows you to enter Setup. If the
message disappears before your respond and you still wish to enter Setup, restart the
system to try again by turning it OFF then ON or pressing <Ctrl>, <Alt> and <Delete> keys.
Control Keys
<←> <→>
<↑> <↓>
<Esc>
<Enter>
<Page Up/+>
<Page Down/->
<Tab>
<F1>
<F2>
<F3>
<F10>
Main Menu
The main menu lists the setup functions you can make changes to. You can use the arrow
keys ( ↑↓ ) to select the item. The on-line description of the highlighted setup function is
displayed at the bottom of the screen.
Sub-Menu
If you find a right pointer symbol appears to the left of certain fields that means a sub-menu
can be launched from this field. A sub-menu contains additional options for a field parameter.
You can use arrow keys ( ↑↓ ) to highlight the field and press <Enter> to call up the sub-menu.
Then you can use the control keys to enter values and move from field to field within a
sub-menu. If you want to return to the main menu, just press the <Esc >.
Spectra GmbH & Co. KG
sales@spectra.de
Move to select screen
Move to select item
Quit the BIOS Setup
Select item
Increases the numeric value or makes changes
Decreases the numeric value or makes changes
Select setup fields
General help
Previous value
Load Optimized defaults
Save configuration and Exit
User Manual
Spectra PowerBox 3000C
71
