SATA3: SATA Connector (SATA DOM)
Pin
Definition
1
GND
2
TX2+
3
TX2-
4
GND
POWER1, POWER2, POWER3: Power Connector
Connector Type: 1X4-pin Wafer, 2.0 mm pitch
Pin
1
2
3
4
POWER4: Power Connector
Connector Type: 1X4-pin Wafer, 2.54mm pitch
Pin
1
2
3
4
CLR_CMOS1: Clear BIOS Switch
Pin
1-2 (Left)
2-3 (Right)
PWR_SW1: Power on/ off switch and Thermal LED
Button
ON
OFF
Thermal
Spectra GmbH & Co. KG
sales@spectra.de
Pin
Definition
5
RX2-
6
RX2+
7
NC/+5V
Definition
+5V
GND
GND
+12V
Definition
+5V
GND
GND
+12V
Definition
Normal Status (Default)
Clear BIOS
Definition
Green
Blue
Red
User Manual
Spectra PowerBox 3000C
1    2   3  4
2
1
30
