Installing the Rectifier and Converter
Modules
Rectifier and converter modules can be inserted or removed with
power applied (hot swappable).
Rectifiers modules can be installed in any mounting position of
each module mounting assembly. Converter modules can be
installed in any of the three far right mounting positions of the
three lower module mounting assemblies (as viewed from the
front). See Figure 29.
NOTE: Each rectifier and converter module locks into the
module mounting assembly by means of a latch located
on the bottom of the module. The latch and module
handle are interactive. Pushing the handle up into the
module's front panel causes the latch to extend to the
locking position; pulling the handle down out from the
module's front panel causes the latch to retract. See
Figure 29.
WARNING! To prevent damage to the latching
mechanism, ensure the handle is in the open position
Warning
when installing or removing a module. NEVER hold the
handle in the closed position when installing a module
into a shelf.
Spec. No: 582127000100, 582127000103
Model No: 7100
Procedure
1. Unpack the modules.
2. Note the model number located on the front of each
module. Model numbers starting with the letter "R" are
rectifier modules. Model numbers starting with the letter
"C" are converter modules.
3. Place the module into an unoccupied mounting position
without sliding it in completely. Rectifiers modules can
be installed in any mounting position of each module
mounting assembly. Converter modules can be installed
in any of the three far right mounting positions of the
three lower module mounting assemblies (as viewed
from the front). See
4. Loosen the captive screw on the module's handle. Pull
the handle down out from the module's front panel (this
will also retract the latch mechanism). See
5. Push the module completely into the shelf.
6. Push the handle up into the module's front panel. This
will lock the module securely to the shelf. Tighten the
captive screw on the handle.
7. Repeat the above steps for each module being installed
in the system.
8. After the modules are physically installed in the
mounting shelf(s), they are ready for operation
immediately after power is supplied to them.
[44]
Figure 29.
Figure 29.
