- Page 1 Installation Guide Integrated Safety System Ford Transit equipped with Non-Tow Mirrors 4.2” Radio Display Only...
-
Page 2: Prior To Installation
FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Prior to Installation Cover all surfaces with tape or plastic protection film to protect against scratching and damage. EchoMaster is in no way responsible for any damage that may incur during installation. -
Page 3: Recommended Tools
FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Vehicle Preparation & Protection CAUTION Consult your vehicle owner’s manual to disconnect the battery. Do not disconnect ANY airbag connectors or indicators. Doing so may result in activating a diagnostic code. These codes will require the dealer to perform the reset procedure which may incur a reset fee. -
Page 4: Removing The Radio
FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Removing the Radio 4.2” Radio Display Only Step 1 Using a nylon trim removal tool, remove the cover from behind the radio display. There are several tabs holding the cover in place. - Page 5 FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Removing the Radio - (cont’d) Step 4 Remove the front cover using a nylon trim removal tool. Pry the cover from the dash and remove. Step 5 Remove the 2 x 7mm screws from the radio control panel.
- Page 6 FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Removing the Dash Panel(s) Passenger side Step 1 Remove the cup holder by using a nylon pry tool to pry it straight up. Remove the 3 x 7mm bolts holding the side dash panel in place.
- Page 7 FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Removing the Dash Panel(s) - (cont’d) Passenger side Step 3 Remove the side cover and cup holder. Step 4 Remove the glove box. Two tabs need to be released inside the top of the glove box.
- Page 8 FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Removing the Dash Panel(s) Driver’s Side Step 1 Remove the cup holder by using a nylon pry tool to pry it straight up. Remove the 3 x 7mm bolts hold the side...
- Page 9 FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Removing the Dash Panel(s) - (cont’d) Driver’s Side Step 3 Remove the lower panel below the steering column. Pull straight back and release the 8 locking tabs holding it in place.
- Page 10 FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Removing the Dash Panel(s) - (cont’d) Driver’s Side Step 5 Step 5 Remove 2 screws holding the steering column shroud cover. Using a nylon pry tool separate the top and bottom steering column shroud cover.
-
Page 11: Removing The Door Panels
FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors PLEASE NOTE The following sections represent both sides of the vehicle. Each step will need to be done on both driver’s and passenger sides. Removing the Door Panels There are 8 bolts and several snap connectors holding the door panels in place. -
Page 12: Removing The Mirrors
FCTP-FT1602 IIntegrated Safety System Ford Transit - Non-Tow Mirrors Removing the Mirrors Step 1 Remove the mirror glass from the housing. Start with the bottom smaller mirror. Tilt the top of the mirror inward. Place fingers underneath. Pull straight forward to release. - Page 13 FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Removing the Mirrors - (cont’d) Step 3 Remove the 3 rubber grommets from the interior door frame to access the 3 x 10mm nuts holding the mirror. PLEASE NOTE Be sure to protect the side of the vehicle when removing the mirrors.
- Page 14 FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Mounting the Camera to the Mirror Caps Step 1 To assemble camera into the mirror caps, align the flat edge on bottom of the camera to mate with the flat edge on the mirror cap.
- Page 15 FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Routing Camera Harnesses - (cont’d) Route the cable through the large hole in the lower corner. Reinstall the foam gasket removed earlier. Mounting the Camera Mirror Caps Step 1 Once the cable is routed through the mirror, install the plastic housing.
- Page 16 FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Mounting the Camera Mirror Caps - (cont’d) Step 2 Ensure all 6 pressure snaps are locked in place. Reinstall the 2 x T10 torx screws to secure the turn signal or blank in place.
- Page 17 FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Routing the Camera Extension Cables Step 1 Route camera extension harnesses along the inside lower portion of the dash and up to the radio cavity. Connect the T-harness to the radio vehicle harness and the other side to the radio.
- Page 18 FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Routing Camera Extension Cables - (cont’d) Step 3 Route the steering wheel connector harness (14 pin T-harness) to the steering column. Disconnect the 14 pin connector from the turn signal indicator connector.
-
Page 19: Wiring Diagram
FCTP-FT1602 Integrated Safety System Ford Transit - Non-Tow Mirrors Wiring Diagram Illustrations are typical and may not match exact vehicle details email - support@aampglobal.com (US) tel - 1-800-477-2267 (East Coast) - 1-888-883-2790 (West Coast) email - technical.eu@aampglobal.com (Europe) - Page 20 Unit 25B, Woolmer Way, Bordon, Hampshire, United Kingdom, GU35 9QE email - support@aampglobal.com (US) tel - 1-800-477-2267 (East Coast) - 1-888-883-2790 (West Coast) email - technical.eu@aampglobal.com (Europe) tel - +44(0)1420 487110 (sales) - +44(0)1420 470618 (technical) EchoMaster is a Power Brand of AAMP Global. IG-FCTP-FT1602 REV. 111617 EchoMaster.com...
