  • Page 1 Installation Guide IntelliHaul Integrated Towing Assistance Package...
  • Page 2: Prior To Installation

    Installation Guide FC-GMOESWR-TC Integrated Towing Assistance Package Prior to Installation Cover all surfaces with tape or plastic protection film to protect against scratching and damage. EchoMaster is in no way responsible for any damage that may incur during installation. This product has been validated in the vehicles listed on the application guide only. Care must be taken when installing this accessory to ensure damage does not occur to the vehicle.
  • Page 3: Required Tools

    Installation Guide FC-GMOESWR-TC Integrated Towing Assistance Package Vehicle Preparation & Protection CAUTION Consult your vehicle owner’s manual to disconnect the battery. Do not disconnect ANY airbag connectors or indicators. Doing so may result in activating a diagnostic code. These codes will require the dealer to perform the reset procedure which may incur a reset fee.
  • Page 4: Removing The Dash

    Installation Guide FC-GMOESWR-TC Integrated Towing Assistance Package Removing the Dash Step 1 Using a plastic dash removal tool, remove the LCD display fascia panel. Step 2 If installed, remove the heated seat connector plugs from the display fascia panel. Step 3 Remove the 4 x 7mm bolts from around the LCD display.
  • Page 5 Installation Guide FC-GMOESWR-TC Integrated Towing Assistance Package Step 4 Disconnect the 3 connectors from the back of the LCD display assembly and set aside. Steps 5 & 6 Remove the 2 x 7mm bolts from the CD mechanism. Next, disconnect the CD mechanism and set aside.
  • Page 6 Installation Guide FC-GMOESWR-TC Integrated Towing Assistance Package Removing the Door Sill(s) Step 1 Remove passenger front and rear door sill plastics. Set aside. Route Camera Extension Harness Route 16-pin main camera extension cable down below the dash. This should pass through hole located in the back portion of the radio cavity and exit from bottom of dash.
  • Page 7 Installation Guide FC-GMOESWR-TC Integrated Towing Assistance Package Route Camera Extension Harness (Rear) Route extension harness(s) to the rear of the vehicle (passenger side only). Remove 1 x 7mm bolt from C-pillar panel and remove panel. Route wire to bottom corner of rear window and secure with zip ties. email - gmsupport@echomaster.com (US) - tel - 866-766-2267 Illustrations are typical and may not match exact vehicle details...
  • Page 8 Installation Guide FC-GMOESWR-TC Integrated Towing Assistance Package Installing Wireless Receiver Plug in wireless receiver module. Use double sided adhesive tape to mount to the glass WARNING Be sure to orient the plug correctly otherwise damage will occur. Use two sided tape to fasten to rear window.
  • Page 9: Module Connections

    Installation Guide FC-GMOESWR-TC Integrated Towing Assistance Package Module Connections Next, connect the 8-pin power harness and the 16-pin main camera extension cable to module. Then, fasten harnesses to the bracket using zip ties through the holes provided. Please select the size of the monitor using dip switch 1 u Up for 8”...
  • Page 10 Installation Guide FC-GMOESWR-TC Integrated Towing Assistance Package LVDS Connection Locate HMI module high in glove compartment cavity. Disconnect thr BLUE LVDS connector. Connect the loose male LVDS connector into female EchoMaster connector. Connect the male EchoMaster LVDS connector into HMI module. Secure loose wiring with zipties.
  • Page 11: Wiring Diagram

    Installation Guide FC-GMOESWR-TC Integrated Towing Assistance Package Wiring Diagram email - gmsupport@echomaster.com (US) - tel - 866-766-2267 Illustrations are typical and may not match exact vehicle details...
  • Page 12 AGREEMENT: End user agrees to use this product in compliance with the instructions and terms of use above and with all State and Federal laws. ECHOMASTER provides instructions and safety warnings with respect to this product and disclaims all liability for any use not in conformity with those instructions or other misuse of its product.
