- Page 1 Installation Guide Third Brake Light Camera with Cargo and Side Blind Spot Views Ford Super Duty Trucks (1999-2016)
- Page 2 Installation Guide PCAM-CHMSL2-FD99 Third Brake Light Camera Thank you for purchasing your EchoMaster Pro automotive camera. EchoMaster cameras are designed to improve safety while driving by providing high quality images of surrounding areas and obstacles in the vicinity of the vehicle. They will also improve vehicle maneuvering capability by displaying blind spots not normally visible to the driver.
- Page 3 Installation Guide PCAM-CHMSL2-FD99 Third Brake Light Camera Box Contents Third Brake Light Camera and Bracket 17.5’ Extension Cable 2 Phillips Mounting Screws Camera Adjustment Tool Installation Guide Warranty Card Illustrations are typical and may not match exact vehicle details.
- Page 4 Installation Guide PCAM-CHMSL2-FD99 Third Brake Light Camera Installing the CHMSL Camera Step 1 Remove the 2 screws that secure the third brake light. Step 2 a. Remove the third brake light from the vehicle and disconnect connector. b. Place the third brake light onto the third brake light camera bracket and line up the screw holes.
- Page 5 Installation Guide PCAM-CHMSL2-FD99 Third Brake Light Camera Step 4 Connect the extension cable to the camera. Step 5 Route the cable to the front of the vehicle and behind the radio, monitor, or mirror monitor. Step 6 Remount third brake light and camera assembly using the longer mounting screws provided in the kit.
- Page 6 Installation Guide PCAM-CHMSL2-FD99 Third Brake Light Camera Step 7 Route the reverse and turn signal wires to their respective locations according to the table below 1999 - 2001 Turn Signal (Left) Light Green / White + Turn signal switch Turn Signal (Right) White / Lt.
- Page 7 Installation Guide PCAM-CHMSL2-FD99 Third Brake Light Camera Step 8 Connect the yellow video RCA to the rear camera input on the radio, monitor, or mirror monitor. Step 9 Connect the Blue “Reverse power anode output” wire to the reverse trigger input on the radio, monitor, or mirror monitor.
- Page 8 Installation Guide PCAM-CHMSL2-FD99 Third Brake Light Camera Using the CHMSL Camera Using the CHMSL Camera Rear Cargo View Camera With the ignition in the on position, shift the vehicle into reverse. The image should appear on the screen. Left Blind Spot Camera With the ignition in the on position, apply the left turn signal.
- Page 9 Installation Guide PCAM-CHMSL2-FD99 Third Brake Light Camera Views REAR 90°...
-
Page 10: Wiring Diagram
Installation Guide PCAM-CHMSL2-FD99 Third Brake Light Camera Wiring Diagram 174 in Parking Lines (Green) On - Joined (Default) O - Cut Video +12V... - Page 11 Installation Guide PCAM-CHMSL2-FD99 Third Brake Light Camera Notes:...
- Page 12 AGREEMENT: End user agrees to use this product in compliance with the instructions and terms of use above and with all State and Federal laws. EchoMaster provides instructions and safety warnings with respect to this product and disclaims all liability for any use not in conformity with those instructions or other misuse of its product.
