- Page 1 Installation Guide Trailering Camera System Compatible with IOS and IOT Touchscreen Radios Silverado/Sierra Heavy Duty Trucks (2020-Present)
- Page 2 Installation Guide FCTP-GM2003 Trailering Camera System Important Please read and follow the instructions carefully. To emphasize special information, the symbol and the words Warning, Caution and Note have special meanings. Pay special attention to messages highlighted by these signal words.
-
Page 3: What's In The Box
Installation Guide FCTP-GM2003 Trailering Camera System What’s in the Box Parts Description FCTP-GM2003 Image Part Number Description GMS3-USB-CBL USB Update Cable for FC-GMS3 Interface GMS3-CEH-HAR Camera Harness for FC-GMS3 GMS3-LVDS-HAR LVDS Harness for FC-GMS3 GMS3-M2F-48 48” 4 Pin Camera Extension Harness... -
Page 4: Setting The Dip Switches
Installation Guide FCTP-GM2003 Trailering Camera System Setting the Dip Switches Please be sure to set all Dip Switches before plugging the interface module into the vehicle. Dip Switch Settings Function Left Camera On / Off Right Camera On / Off... -
Page 5: Door Disassembly
Installation Guide FCTP-GM2003 Trailering Camera System Door Disassembly Indentation Indentation Step 1 Using a small flat blade pry tool remove the inner handle trim panel to access the 7mm bolt behind it. Step 2 Remove the 7mm bolt located behind the inner handle trim... - Page 6 Installation Guide FCTP-GM2003 Trailering Camera System Door Disassembly (continued) Step 4 Starting at the front side of the door trim, use a plastic panel removal tool to pry towards you to release the 3 clips attaching it to the door. Once the 3 clips have been released, slide the panel forward and set aside.
- Page 7 Installation Guide FCTP-GM2003 Trailering Camera System Step 7 Once all the fasteners have been released in step 6, lift up on the door panel to remove it from the door. Step 8 With the door panel leaned toward you and away from the door, remove the door latch release cable.
- Page 8 Installation Guide FCTP-GM2003 Trailering Camera System Routing the Camera Cables Step 1 Locate and remove the T15 screw from the bottom of the mirror cap. Step 2 Using a small flat blade pry tool remove the bottom cap of the mirror. There are indentations in the cap from the factory to aide in this procedure.
- Page 9 Installation Guide FCTP-GM2003 Trailering Camera System Step 4 Remove the plastic cap on the upper inside corner of the door to gain access to the rubber membrane and the factory connectors. Step 5 Using a razor knife, make a small slit between the two connectors at the bottom of the rubber membrane just large enough for the camera cable to pass through.
- Page 10 Installation Guide FCTP-GM2003 Trailering Camera System Routing the Camera Cables (continued) Step 7 On the outside of the door secure the connector side of the camera extension cable without the threads to the fish tape using electrical tape. This will allow us to route the cable from outside of the door to the inside of the door.
- Page 11 Installation Guide FCTP-GM2003 Trailering Camera System Step 11 Remove the 7mm bolt securing the speaker, unplug the speaker and set aside. This will aide in routing the camera cable in the door. Step 12 Route the camera cable down to the grommet removed in step 9 making certain that it is run along side and secured to the factory wiring.
- Page 12 Installation Guide FCTP-GM2003 Trailering Camera System Routing the Camera Cables (continued) Step 14 Connect the GMS3-M2F-48 (passenger side) or the GMS3-M2F-108 (driver side) to the camera cable by lining up the arrows and pushing them together until fully seated. Step 15...
- Page 13 Installation Guide FCTP-GM2003 Trailering Camera System Step 17 Remove the door sill plate using a plastic trim tool starting at the rear of the panel. Work your way forward and release from the kick area. NOTE Once the door sill plate is removed, place in safe area to avoid damage.
- Page 14 Installation Guide FCTP-GM2003 Trailering Camera System Routing the Camera Cables (continued) Step 20 Remove the under dash beauty panel by removing the push pin fasteners. (2 under the glove compartment and 1 towards the front of the vehicle.) Step 21...
- Page 15 Installation Guide FCTP-GM2003 Trailering Camera System Step 22 Continue routing the fish tape through the door boot and into the speaker opening. Secure the loose end of the GMS3-M2F extension cable to the fish tape like done previously in step 6.
- Page 16 Installation Guide FCTP-GM2003 Trailering Camera System Installing the Camera Caps Step 1 (Passenger Side Only) Insert the temperature sensor into the camera pod. Step 2 Connect the camera pigtail to the camera harness. Make certain the connector is fully seated and twist the locking portion of the connector until tight.
- Page 17 Installation Guide FCTP-GM2003 Trailering Camera System Rear Wireless Camera Receiver Step 1 Clean the surface and secure the 3M double sided tape to the wireless camera receiver. Step 2 Clean the surface and secure the wireless cam- era receiver to the back window as shown in the picture.
- Page 18 Installation Guide FCTP-GM2003 Trailering Camera System Rear Wireless Camera Receiver (continued) Step 3 Release the retaining clips and remove the upper trim panel from the C pillar and route the pigtail cable from the wireless camera receiver. Make certain the cable is routed behind any air bag hardware that is located in that area.
- Page 19 Installation Guide FCTP-GM2003 Trailering Camera System Step 5 Remove the passenger side rear door sill using a plastic trim tool. Pull loose the rubber door seal between the rear door sill and the upper trim panel removed in step 3.
- Page 20 Installation Guide FCTP-GM1903 Trailering Camera System Module Assembly and Installation Step 1 At this time, refer to page 4 and set the DIP switches according to your install. NOTE DIP switches must be set prior to connecting the module to the vehicle. Step 2 Connect the GMS3-PTH-HAR, GMS3-CEH-HAR &...
- Page 21 Installation Guide FCTP-GM1903 Trailering Camera System Step 4 Place the GMS3 mounting bracket onto the vehicle’s plastic Multifunction Power Supply Converter Bracket bracket according to the picture. Make sure that the C portion of the mounting bracket clips all the way around the plastic factory bracket.
- Page 22 Installation Guide FCTP-GM2003 Trailering Camera System Module Assembly and Installation (continued) Step 6 Connect the factory Gray and Black 28 pin connectors to the GMS3-PTH-HAR and the factory LVDS connector to the GMS3-LVDS-HAR. Step 7 Connect the 2 Gray 28 pin connectors from the GMS3-PTH-HAR and the LVDS connector from the GMS3-LVDS-HAR into the factory radio brain.
- Page 23 Installation Guide FCTP-GM2003 Trailering Camera System Step 8 Connect the GMS3-M2F extension and TRAILER cables to the GMS3-CEH-HAR harness. Line up the labels and connect in the following orientation. RIGHT ----------------- GMS3-M2F48 LEFT ------------------- GMS3-M2F108 FRONT ---------------- GMS3-M2F144 (Optional Front Camera)
-
Page 24: Additional Testing
Installation Guide FCTP-GM2003 Trailering Camera System Testing (continued) Step 3 Once the Intellihaul 2.0 home screen appears press the corresponding button for the camera you wish to test. Pressing the BACK button on the radios control panel will return you to the Intellihaul 2.0 home screen. - Page 25 Installation Guide FCTP-GM2003 Trailering Camera System Notes: tel - 1-866-766-2267 email - gmsupport@echomaster.com...
- Page 26 Installation Guide FCTP-GM2003 Trailering Camera System Notes: tel - 1-866-766-2267 email - gmsupport@echomaster.com...
- Page 27 Installation Guide FCTP-GM2003 Trailering Camera System Notes: tel - 1-866-766-2267 email - gmsupport@echomaster.com...
- Page 28 AGREEMENT: End user agrees to use this product in compliance with the instructions and terms of use above and with all State and Federal laws. EchoMaster provides instructions and safety warnings with respect to this product and disclaims all liability for any use not in conformity with those instructions or other misuse of its product. If you do not agree, please discontinue use immediately and contact EchoMaster.
