Summary of Contents for EchoMaster Pro FCTP-MB1903
- Page 1 Installation Guide Integrated Blind Spot Kit Compatible with 7” and 10” LCD Touchscreen Radios Mercedes-Benz Sprinter (2019-Present)
- Page 2 Installation Guide FCTP-MB1903 Sprinter Tow Package Important Please read and follow the instructions carefully. To emphasize special information, the symbol and the words Warning, Caution and Note have special meanings. Pay special attention to messages highlighted by these signal words.
-
Page 3: What's In The Box
Installation Guide FCTP-MB1903 Sprinter Tow Package What’s in the box Parts Description FCTP-MB1903 Image Part Number Description FC-MBS Interface Module For 2019+ Mercedes Sprinter FC-MBS-CAM-HAR Camera Harness for FC-MBS FC-MBS-LVDS-HAR LVDS Harness for FC-MBS BSCM-MB1101 Side Mirror Cap Camera Mounts (L&R) -
Page 4: Setting The Dip Switches
Installation Guide FCTP-MB1903 Sprinter Tow Package Setting the DipSwitches 2 3 4 Please be sure to set all DipSwitches before plugging the interface module into the vehicle. Side DipSwitch Settings Function Left Camera On / Off Right Camera On / Off... -
Page 5: Tools Required
Installation Guide FCTP-MB1903 Sprinter Tow Package Tools Required T-20, T-30 Trim Towel Painters Torx Drivers Removal Tool Tape Dash Disassembly Step 1 Carefully tape off the dash trim piece around the radio display including the cup holders below the radio. - Page 6 Installation Guide FCTP-MB1903 Sprinter Tow Package Dash Disassembly (continued) Step 3 Remove the two T20 Torx bolts, one behind each vent, that were exposed by removing the vents. Step 4 Using both hands, pull at the upper corner of the dash panel that houses the LCD screen from the dash.
- Page 7 Installation Guide FCTP-MB1903 Sprinter Tow Package Step 6 Release the radio brain by removing the four T20 Torx bolts, one at each corner, that were exposed by removing the dash panel. Rest the radio brain on the lower dash. Step 7...
-
Page 8: Interface Connections
Installation Guide FCTP-MB1903 Sprinter Tow Package Interface Connections Step 1 Remove a small portion of the electrical tape banding the main harness together to expose the power, ground and CANBus connections. Step 2 Connect the wiring as follows: Interface Wire Color... - Page 9 Installation Guide FCTP-MB1903 Sprinter Tow Package Step 4 Route the LVDS cable behind the plastic sub dash on the right side. Route the Power and Camera harnesses behind the plastic sub dash on the left side. Step 5 Connect the Power, Camera and LVDS harnesses to the FC-MBS control module.
- Page 10 Installation Guide FCTP-MB1903 Sprinter Tow Package Interface Connections (continued) Step 7 Using the zip tie secure the module to the sub dash center support. Step 8 Remove the access panels just below the dash by pulling the door seal back and pulling the panels towards the rear of the vehicle.
-
Page 11: Mirror Disassembly
Installation Guide FCTP-MB1903 Sprinter Tow Package Mirror Disassembly Step 1 Push the bottom of the top mirror glass in to gain access to the lower mirror glass. Using even pressure, pull the bottom mirror glass off towards you. The mirror will pop off. - Page 12 Installation Guide FCTP-MB1903 Sprinter Tow Package Mirror Disassembly (continued) Step 3 Tilt the top mirror glass so you can place both hands up un- der the glass to get to the center of the back of the glass. Applying even pressure, pop the glass off.
- Page 13 Installation Guide FCTP-MB1903 Sprinter Tow Package Step 6 Remove the outer trim ring. Support the back cover while removing the outer trim ring. Place in a safe area to avoid damage. Step 7 Remove the back cover of the mirror housing.
-
Page 14: Cable Routing
Installation Guide FCTP-MB1903 Sprinter Tow Package Mirror Disassembly (continued) Step 9 Disconnect the turn signal indicator. Place the turn signal indicator in a safe area to avoid damage. Cable Routing Tow Mirror Step 1 For the tow mirror, fold the arm in towards the door to gain access to the inner hinge area. - Page 15 Installation Guide FCTP-MB1903 Sprinter Tow Package Step 3 Remove the three Torx T30 screws holding the mirror to the door of the truck. One of the Torx T30 screws has a small cap covering it. Use something slim to pry the cover off to access the screw.
-
Page 16: Mirror Assembly
Installation Guide FCTP-MB1903 Sprinter Tow Package Cable Routing (continued) Step 6 Unsnap the door boot on the door side, and feed the wire tie through with the camera cable taped to the end. It is not necessary to remove the boot from the black snap ring. - Page 17 Installation Guide FCTP-MB1903 Sprinter Tow Package Mirror Assembly (continued) Step 2 There are two sets of camera inserts per side. Right hand side RH-T Right hand side towing Left hand side LH-T Left hand side towing The towing inserts are for the mirrors that extend out farther from the vehicle.
- Page 18 Installation Guide FCTP-MB1903 Sprinter Tow Package Mirror Assembly (continued) Step 5 When installing the camera insert on to the mirror caps, the locating tab will line up with a small hole on the front of the camera insert. Step 6...
-
Page 19: Wiring Diagram Overview
Installation Guide FCTP-MB1903 Sprinter Tow Package Wiring Diagram Overview Factory LVDS Factory Harness To Radio Remove Tape and make connections FC-MBS BLINDSPOT CAMERA INTERFACE CAMERA POWER Illustrations are typical and may not match exact vehicle detail tel - 1-800-477-2267 email - support@aampglobal.com... -
Page 20: Firmware Updates
Firmware Updates Please visit www.EchoMaster.com and type “FCTP-MB1903” into the search bar. Once on the product page, click on the downloads tab and download the application and firmware file needed to perform the update. The FC-MBS module will need to be disconnected from the vehicle and placed into firmware update mode. - Page 21 Installation Guide FCTP-MB1903 Sprinter Tow Package Notes: Illustrations are typical and may not match exact vehicle detail tel - 1-800-477-2267 email - support@aampglobal.com...
- Page 22 AGREEMENT: End user agrees to use this product in compliance with the instructions and terms of use above and with all State and Federal laws. EchoMaster provides instructions and safety warnings with respect to this product and disclaims all liability for any use not in conformity with those instructions or other misuse of its product. If you do not agree, please discontinue use immediately and contact EchoMaster.
