Maintenance
7.4

Replacing the air filter

Change the air filters monthly (more frequently if necessary).
To replace the air filter, proceed as follows:
1. Disconnect the instrument from the power supply (see page 22).
2. Release the "unit/transport
carriage" locking mechanism
and take the instrument off the
transport carriage.
3. Loosen the knurled screws.
4. Lower the base plate (2).
5. Remove the clogged filter (1).
6. Insert the new filter.
— 34
Fig. 11
Fig. 12
Fig. 13
