- Page 1 PRODUCT AND INSTALLATION MANUAL Iron Removal Systems Model NuMbers: for the removal or reduction of iron, manganese and hydrogen sulfide eWs-IroN-1054-A, eWs-IroN-1354-A Retain this Product & Installation Manual for Helpful Information Please Register Your System Revised 12/01/2017 V: 1.7...
-
Page 2: Simple Steps For A Correct Installation And Happy Customer
If you don’t read this service guide at least read these 7 simple steps SIMPLe STePS fOR A CORReCT INSTALLATION AND A HAPPY CUSTOMeR set up system and install it on the main water supply coming into the home Page 7-8 Use corrugated flexible stainless or some other flexible piping to make the plumbing connections Page 9... -
Page 3: Table Of Contents
table of contents SIMPLe STePS fOR A CORReCT INSTALLATION AND HAPPY CUSTOMeR ........INSTALLATION DIMeNSIONS SYSTeMS ....................ON SITe ASSeMBLY PROCeDURe ......................IMPORTANT SAfeTY INfORMATION – All Systems Instructions Before Using ......................LOCATION AND SeTUP - All Systems ....................... unpacking and Inspection Where to Install the system drain location Outside Installation (where applicable) -
Page 4: Installation Dimensions Systems
- Model #’s eWs-IroN-1054-A, eWs-IroN-1354-A for Illustration Purposes Only: On-Site Assembly Required due to shipping weight for all Iron systems, tank, all tank contents and valve must be assembled on site. Please review the simple steps for proper assembly. -
Page 5: On Site Assembly Procedure
Check to see if you have all the boxes before assembly - Below is the box count for each system Model # EWS-IrOn-1054-A should have 6 boxes. ______________________________________________________ 1 Box - tall with 10” x 54” tank with a riser tube inside and tank Wrap ... -
Page 6: Important Safety Information - All Systems
IMPORTANT SAfeTY INfORMATION - ALL SYSTeMS CAUTION: read and follow the information in this manual to minimize the risk of electric shock or personal injury. IMPORTANT! If you are unsure about the installation of your system, contact EWS customer service or consult a professional plumber. IMPORTANT! this system must be installed in compliance with applicable state and local codes, law, and regulations. -
Page 7: Location And Setup - All Systems
location and setup UNPACKING AND INSPeCTION - Check the system components for damage or missing parts. wHeRe TO INSTALL THe SYSTeM Place system on the main water supply in order to supply filtered water to the entire home. Place the system where you want to install the unit. Whether inside or outside, make sure the unit is level and on a firm base. ... -
Page 8: Plumbing Connections
installation instructions - all iron systems INSTALLATION Turn off gas or electric supply to the water heater(s). Turn off the main water supply. open a hot and cold faucet to drain house water pipes. NOTe: Keep those hot and cold faucets open until these instructions tell you to close. Keep bypass closed. Move the assembled system into installation position and check that valve is securely fastened to the tank. - Page 9 installation Instructions - all iron systems - plumbing connections Locate water line or pipe to be cut and make sure of direction of water flow. CAUTION: do not cross-connect or plumb backwards. Make sure of the direction of water flow from cut pipe to be connected.
-
Page 10: Drain Line
installation Instructions - all systems - drain connections A word about the proper installtion of a drain line. It appears simple, however if simple mistakes are made it can create many problems associated with this or any system. Please read the instructions below to avoid any issues. Plumb rigid tubing only (PvC recommended if code applicable) directly to the 1”... -
Page 11: Electrical Connection
installation Instructions - all systems - electrical connections INSTALL eLeCTRICAL CONNeCTION Connect electrical power by plugging the transformer into a standard grounded and unswitched 110/115/120v electrical outlet. If outlet is over 9 feet away use 18 gauge extension cord to connect up to 100 feet away. do not exceed 100 feet. -
Page 12: Set The Time Of Day
setting the clock touch the box in the upper left hand corner where a day & time are blinking. The day And Time screen will appear Day And Time NoTe: Month Year day & time are the only changes needed. system does not need any additional programming. -
Page 13: Tank Fill Slowly
start up procedure - fill the tank and flush the system outlet fILL THe TANK - SLOwLY closed Main water supply is open, plumbing lines have been flushed and tub or faucet is closed (Step #12) open inlet Open the inlet slightly on the bypass slightly as shown inlet... -
Page 14: Flushing The System Procedure
this is what the system is doing and we want to see clear drain water Keep the inlet to the bypass open and make sure the outlet is still closed These are the system start up and self-cleaning cycles and the duration: Backwash 14 minutes initially fills the tank... -
Page 15: System Ready For Use
open outlet for service and go through a checklist to avoid any issues OPeN OUTLeT ON THe BYPASS outlet SYSTeM fINAL SeRVICe POSITION open inlet & outlet system is in service position inlet System is ready for use. Turn on gas or electric supply to the water heater(s). To ready home for filtered water, please flush all the water throughout the home. -
Page 16: Touch Screen Other Options
other buttons you can push on the screen Vacation Mode: water Treatment Press the button and vacation 4000 1667 Mode will be in the upper right box. 10:30 am the system will not backwash until treatment the button is pressed again and the upper right box returns to the normal setting. -
Page 17: Product Blow-Out (For Illustration Purposes)
parts breakdown - iron systems (for illustration only) Valve - Inlet Side Valve - Outlet Side Injection: Drain Adaptor (dlFC) Oxidation or air Brass Line flow Control: Brass Spring Check: into brine line Drain flow Rates: Install on incoming line Install on outgoing line 1054 - 8gpm, in proper flow direction... -
Page 18: Schematic For The Correct Order Of Equipment (If Applicable)
schematic for varied or difficult well water conditions CONDITIONS APPLICATIONS source Water - Test results based on Test results Pre-Treatment: Coliform/Bacterial/E-Coli microorganism problems, Chlorination/Chemical feed (as needed) decaying vegetation, organic bonding, Iron/manganese bacteria ozonation Tannins (yellow) uV (only safeguard, not a solution) Pre-treatment is the primary need to disinfect, break down organic bonds and/or add oxygen to water. -
Page 19: Warranty
Warranty Notification - As Published and Available Online Notification: this warranty is referenced by EWS, Inc. in all literature, addressed in general terms and Standard Conditions of Sale, and is published in its entirety in all EWS, Inc. product manuals, websites, and in all service guides supplied with all product. Limited warranty: EWS, Inc., a nevada corporation, hereby warrants all products to the original consumer purchaser to be free from defects in material and workmanship as stated in the following paragraphs:... -
Page 20: Back Cover With Ews Contact Information
Crohn’s & Colitis • • • • • • • oceans Inland Water Ways Wetlands Forestry soil ALL FILTRATION PRODUCT PROUDLY MADE & ASSEMBLED IN THE USA EWS Logo and Environmental Water Systems are Registered Trademarks and the Property of EWS, Inc.
