PRODUCT AND INSTALLATION MANUAL
5 Stage Reverse Osmosis Systems
Model Numbers:
RU500T35 w/BP
RU500T35 w/BP w/UV
ALL FILTRATION PRODUCT PROUDLY MADE & ASSEMBLED IN THE USA
EWS, Inc./Environmental Water Systems
office. 702.256.8182
Monday - Friday, 8:30 am - 4:30 pm Pacific Standard Time
fax. 702.256.3744
www.ewswater.com
e-mail. customerservice@ewswater.com
Retain this Product & Installation Manual for Maintenance and Information
Please Register this Product - It is a Requirement for Warranty
Revised 11/11
www.ewswater.com
O: 702.256.8182; M-F 8:30am-4:30pm PST
E: customerservice@ewswater.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Environmental Water Systems RU500T35 w/BP
Summary of Contents for Environmental Water Systems RU500T35 w/BP
-
Page 1: Model Numbers
PRODUCT AND INSTALLATION MANUAL 5 Stage Reverse Osmosis Systems Model Numbers: RU500T35 w/BP RU500T35 w/BP w/UV ALL FILTRATION PRODUCT PROUDLY MADE & ASSEMBLED IN THE USA EWS, Inc./Environmental Water Systems office. 702.256.8182 Monday - Friday, 8:30 am - 4:30 pm Pacific Standard Time fax. - Page 2 A Special Message to Our Customers, EWS, Inc. and Environmental Water Systems would like to thank you for your consideration in selecting from our comprehensive list of residential filtration and conditioning product. We recommend that you take the time to read the information that pertains to your product as you begin to use it.
-
Page 3: Table Of Contents
Table of Contents INSTALLATION SUMMARY AND INDEX OF YOUR REVERSE OSMOSIS SYSTEM Dispenser/Faucet Q & A Placement or Locating the Dispenser/Faucet Installation of the Supplied Dispenser/Faucet Dispenser/Faucet with Air Gap Dispenser/Faucet without Air Gap Inlet Supply Water Connection Basic Supplied Connection Preferred Connection for All Applications Placement or Locating the System Placement or Locating the Storage Tank... -
Page 4: Dispenser/Faucet Q & A
Dispenser/Faucet Q & A - Reverse Osmosis Spout pulls out from faucet body that’s why it swivels. Spout has 2 o-rings at base and is inserted completely into bottom of body to prevent leaking. Handle and tip can also be removed I do not want to drill any extra holes or use a separate dispenser/faucet - what can I do? Nothing. -
Page 5: Placement Or Locating The Dispenser/Faucet
Placement or Locating Dispenser/Faucet - Reverse Osmosis Step by step instructions to mount and secure the supplied dispenser/faucet Professional Installation is Strongly Recommended Step 1: Locate Faucet Parts Bag Parts Included: faucet body with handle, faucet spout with tip, decorative washer, black rubber washer, white beveled washer, lock washer, hex nut, 1/4”... -
Page 6: Dispenser/Faucet With Air Gap
Installation of the Supplied Dispenser/Faucet with Air Gap Step by step instructions to mount and secure the supplied dispenser/faucet If using another faucet, please review the instructions included with that product** ***Other Air Gap connections can be found with Drain Installation and Connection and System Interconnection instructions Above the Surface Enclosed Dispenser/Faucet Dimensions*** Step 2:... -
Page 7: Dispenser/Faucet Without Air Gap
Installation of the Supplied Dispenser/Faucet without Air Gap Step by step instructions to mount and secure the supplied dispenser/faucet If using another faucet, please review the instructions included with that product** Enclosed Dispenser/Faucet Dimensions*** Above the Surface Step 2: Height: from deck to top of dispenser 8”... -
Page 8: Basic Supplied Connection
Basic Inlet Supply Water Connection ** Professional Installation Using a Preferred Connection is Strongly Recommended **This unit is supplied with a saddle tapping valve and should be considered a basic connection for copper, steel or brass 3/8” to 1/2” O.D. pipe prior to the angle stop shut-off of the cold water line to the kitchen faucet. This should be considered a “do-it-yourself”... -
Page 9: Preferred Connection For All Applications
Preferred Inlet Supply Water Connection - All Applications Professional Installation Using a Preferred Connection is Strongly Recommended A qualified plumber should choose to connect the inlet supply water supply by a more preferred connection. *** The Preferred Inlet Supply Water Connection is Applicable in All Applications and Codes Replace the Angle Stop with a Proper 3-Way Fitting: There are a number of options to properly install any one of these drinking water filtration systems. -
Page 10: Placement Or Locating The System
Placement or Locating the Reverse Osmosis System Simply place the water system on a level floor, cabinet bottom or horizontal surface. Always assume for enough space for the system and the storage tank, and tubing to remove, move and/or adjust for filter and membrane replacement and maintenance. If mounting the system to a wall, cabinet side or other vertical surface, Please see the following;... -
Page 11: Placement Or Locating The Storage Tank
Placement or Locating the Storage Tank Open the box containing the storage tank and plastic base. Place storage tank on the plastic base near the system and allow for room for connections. Locate the Tank Valve in the parts box Tank Valve 1/4”... -
Page 12: Drain Installation And Connection
Drain Installation and Connection sink #1 sink #2 WARNING: Never mount off the garbage Mount drain saddle disposal drain pipes. here when When installing drain saddle on a using only disposal horizontal pipe - install connection Illustration one (1) sink Mount at the 10 o’clock or 2 o’clock drain saddle... -
Page 13: Connection Of Tubing For Reverse Osmosis Systems
Connection of Tubing for Reverse Osmosis Systems Step 1: Before Making the Connections - Remove Colored Vinyl Plugs Correctly This system may have come with sample plugs. Please remove before installation. WARNING: NEVER ATTEMPT TO REMOVE TUBING OR SAMPLE PLUGS BY JUST PULLING. Follow simple instructions illustrated below to remove properly. - Page 14 Connection of Tubing Illustrated Air Gap use: Non-Air Gap use: 1/4”MPT x 3/8” quick connect 1/4”MPT x 1/4” quick connect fitting connected to drain saddle fitting connected to drain saddle Air Gap Tubing Connections: Non-Air Gap Tubing Connection: 1/4” black tubing from unit to 1/4”...
-
Page 15: System Start-Up And Operation Procedures
System Start-Up and Operation Procedures Reverse Osmosis Systems have specific issues with air in system, proper pressure in tank, the proper draining of reject water, and proper connection between various components. Follow these procedures for new installations and all filter/membrane replacements. A proper start-up insures the system is without issues. -
Page 16: System Start-Up And Operation Procedures
System Start-Up and Operation Procedures - Continued Continue with the proper start-up of the reverse osmosis system Step 9: Allow system to fill (this may take up 7 hours) and use as normal. If applicable, only open water supply to other devices connected to this unit after storage tank is filled. Step 10: Inspect for leaks at all connections, fittings and/or housings. -
Page 17: Replacement Of Uv Lamp (If Applicable)
Register this Product - It is a Requirement for Warranty Familiarize yourself with the system, its’ replacement filters and maintenance. To Register, take note of the Model # and WQA Serial # found on the unit’s bracket, Understand your system’s capabilities, put the enclosed Spanner Wrench and this Service Guide on top of the unit bracket, See your options in water treatment, for you , your family and your home by EWS, Inc. -
Page 18: Replacement Of Filter Cartridges
Replacement of Filter Cartridges - All RO Units It is recommended that all filters be changed at least annually or more frequently based on usage and local water conditions. The quantity and quality of the water processed effects the life of the filters. Step 1: Upper Open dispenser/faucet. -
Page 19: Replacement Of Membranes
Replacement of Membranes - All RO Units Step 1: Open dispenser/faucet. Lock handle in the up and open position and allow water to flow. Water will eventually only drip then almost come to a stop. Now go to Step 2. Keep dispenser/faucet open until instructed to close. Step 2: When water has come to a stop or very slow drip, Close inlet water supply to the system. -
Page 20: Cleaning Of Empty Housings, Rsr Control Valve, Booster Pump (If Applicable)
R.O. - Cleaning of Empty Housings NOTE: All containers, surfaces and items exposed to water can accumulate a clear or discolored film which may also be slippery or slimey to the touch. This is a bio-film that is non-pathenogenic and usually of no harm. This film is most commonly a nuisance and is readily wiped off. - Page 21 NOTES What unit(s) do I have? What filters do I need to order? Reminder to Register your Purchase ww.ewswater.com Helpful Hint: Find the enclosed Spanner Wrench that came with the unit and place it on top of the bracket. When finished, roll up this Service Guide and place on top with wrench. This Service Guide and the wrench will come in very handy when it’s time for filter replacement.
-
Page 22: Filter, Membrane And Uv Lamp Replacements
Filter, Membrane and UV Lamp Replacements Model No: PRESED-05 Pre-Sediment Filter (5-micron) 5-Micron Prefilter is a pure polypropylene full-bed depth filter with exceptional dirt holding capability. The removal of any dirt, silt, rust or suspended matter protects the remaining cartridges and extends the performance of other filters and membranes. -
Page 23: Ordering Filters, Membranes, Uv Lamp Replacements, And Parts
(similar to any other distributor) and will ship your order directly to the address you designated in the store. Thank you and we hope we have been of assistance in this matter. EWS, Inc. and Environmental Water Systems – Customer Service www.ewswater.com O: 702.256.8182;... -
Page 24: Maintenance Guide
Maintenance Guide - Reverse Osmosis Systems INITIAL INSTALLATION Follow the proper procedures for the set-up, installation and start-up of all systems. Problems (short and long-term) occur when the systems are installed incorrectly. If any questions arise after installation, consult the trouble shooting guide for assistance. -
Page 25: Troubleshooting Guide
Trouble Shooting Guide - Reverse Osmosis Systems Problems with Start-Up &/or Possible Causes Solution Filter Replacements No water after installing the Improper start-up of the unit upon Start with the start-up procedures and follow them as system installation or filter replacement if the unit was just installed No water after replacing It takes hours after a proper install... - Page 26 Trouble Shooting Guide - Reverse Osmosis Systems Problem - Leaks Possible Causes Solution Connections & Tubing Any or All Leaks Excessive pressure or pressure Pressure reducing valve (PRV) at main water supply surges above 65 PSI to maintain pressure at or below 65 PSI or the addi- tion of a Pressure Limiting Valve (item# FMP-60) on the inlet tube prior to the point of use unit Leaks at any of the...
- Page 27 Trouble Shooting Guide - Reverse Osmosis Systems Leaks - Housings Possible Causes Solution Leak at cartridge housing, Misaligned, damaged or •Locate and align O-ring into groove inside cartridge missing o-ring housing, Leak at membrane housing, At Cap: Misaligned, damaged or •Same for o-ring in membrane or uv housing caps or UV housing (if applicable) missing o-ring...
- Page 28 Trouble Shooting Guide - Reverse Osmosis Systems Problem - Water Quality Possible Causes Solution Air in the system is a normal occurrence with initial Air in system Water Cloudy start-up of the RO system. This milky or cloudy System start-up look will disappear during normal use within 1-2 Filter or membrane replacement weeks.
- Page 29 Trouble Shooting Guide - Reverse Osmosis Systems Problem - Water Quality Possible Causes Solution TDS “Creep” Tank has never been At night before bedtime, open dispenser, close other High Total Dissolved completely emptied devices, then empty all the water from the tank. Allow Solids (TDS) in the water to produce overnight.
- Page 30 Trouble Shooting Guide - Reverse Osmosis Systems Drain - Issues Possible Causes Solution No drain water Clogged brine restricter Replace brine restricter Leaking drain assembly Misalignment of hole in drain Realign drain saddle, check for open drain hole saddle. Leak from air gap opening in Black 1/4”...
-
Page 31: Schematics
Five-Stage Reverse Osmosis 5, 6 Schematic, Parts: Shown with Booster Pump Option for illustration purposes only illustrated quick connect fitting and proper tubing Optional: UV Disinfection Moduleshown below connection 31 Double Clips not shown with this UV illustration Optional: Ref. No. Part No. -
Page 32: Warranty
Warranty Notification Notification: This warranty is referenced by EWS, Inc. in all literature, addressed in General Terms and Standard Conditions of Sale, and is published in its entirety in all EWS, Inc. product manuals, websites, and in all service guides supplied with all product. Limited Warranty: EWS, Inc., a Nevada corporation, hereby warrants all products to the original consumer purchaser to be free from defects in material and workmanship as stated in the following paragraphs:... - Page 33 EWS, Inc. and the distributors of EWS, Inc. will stand behind the warranties of materials and workmanship. However, EWS, Inc. and the distributors of EWS, Inc. and the Environmental Water Systems Product Line do not bear any responsibility for improper applications of product and/or improper installation.
-
Page 34: Terms And Conditions Of Sale
Published and Printed in the U.S.A. EWS Inc./Environmental Water Systems 9101 W. Sahara Ave., Suite # 105-J8, Las Vegas, Nevada 89117 ph 702-256-8182, fx 702-256-3744 customerservice@ewswater.com... - Page 35 www.ewswater.com O: 702.256.8182; M-F 8:30am-4:30pm PST E: customerservice@ewswater.com...
- Page 36 The EWS, Inc./Environmental Water System Product available through: Authorized Kitchen & Bath Showrooms, Appliance Showrooms, Building & Plumbing Wholesale Supply Locations and their building, plumbing, HVAC and service contractors, and Authorized Online Distributors. Contact Information: EWS, INC. Environmental Water Systems ewswater.com 702.256.8182 (M-F 8:30am-4:30pm PST) customerservice@ewswater.com 702.256.3744...
