1
PRODUCT AND INSTALLATION MANUAL
Whole Home Water Filtration Systems
Model NuMbers:
Whole Home Water Filtration & Conditioning systems:
eWs-sPeCTruM, eWs-CC-1465, eWs-CC-1865, eWs-1035
Whole Home Water Filtration systems:
CWl-sPeCTruM, CWl-CC-1465, CWl-CC-1865, CWl-1035
Retain this Product & Installation Manual
for Helpful Information
Please Register Your System
Revised 12/01/2017 V: 1.7
Advertisement
Table of Contents
Related Manuals for Environmental Water Systems EWS-SPECTRUM
Summary of Contents for Environmental Water Systems EWS-SPECTRUM
- Page 1 PRODUCT AND INSTALLATION MANUAL Whole Home Water Filtration Systems Model NuMbers: Whole Home Water Filtration & Conditioning systems: eWs-sPeCTruM, eWs-CC-1465, eWs-CC-1865, eWs-1035 Whole Home Water Filtration systems: CWl-sPeCTruM, CWl-CC-1465, CWl-CC-1865, CWl-1035 Retain this Product & Installation Manual for Helpful Information Please Register Your System Revised 12/01/2017 V: 1.7...
- Page 2 If you don’t read this service guide at least read these 7 simple steps SIMPLe STePS FOR A CORReCT INSTALLATION AND A HAPPY CUSTOMeR set up system and install it on the main water supply coming into the home Page 7-9 Use corrugated flexible stainless or some other flexible piping to make the plumbing connections Page 10...
- Page 3 - Model #’s eWs-sPeCTruM, CWl-sPeCTruM, eWs-1035, CWl-1035 For Illustration Purposes Only: Tank, valve and all contents (as pictured below) for these systems are delivered fully assembled*. Electric transformer, bypass and supplied adaptors - some assembly required. Pictured: Pictured:...
- Page 4 installation dimensions - Model #’s eWs-CC-1465, CWl-CC-1465, eWs-CC-1865, CWl-CC-1865 For Illustration Purposes Only: On-Site Assembly Required due to shipping weight for all larger systems, tank, all tank contents and valve must be assembled on site. Please review the simple steps for proper assembly. Pictured: Pictured: eWs-CC-1465...
- Page 5 assembly instructions for larger systems CHeCk TO See IF YOU HAVe ALL THe bOxeS beFORe ASSeMbLY - beLOW IS THe bOx COUNT FOR eACH SYSTeM Model #’s EWS-CC-1465 and CWL-CC-1465 should have 6 boxes. ______________________________________________________ 1 Box - Tall with 14” x 65” Tank with a Capped 1-1/2” Riser Tube (or ICN (2) Riser Manifold - EWS Series only) inside and Tank Wrap ...
-
Page 6: Table Of Contents
table of contents SIMPLe STePS FOR A CORReCT INSTALLATION AND HAPPY CUSTOMeR ........INSTALLATION DIMeNSIONS FOR COMMOM SPeCTRUM AND SMALLeR 1035 SYSTeMS ..... INSTALLATION DIMeNSIONS FOR LARGeR 1465 AND 1865 SYSTeMS ..........ON SITe ASSeMbLY PROCeDURe FOR LARGeR 1465 AND 1865 SYSTeMS ........IMPORTANT SAFeTY INFORMATION –... -
Page 7: Important Safety Information - All Systems
IMPORTANT SAFeTY INFORMATION - ALL SYSTeMS CAUTION: Read and follow the information in this manual to minimize the risk of electric shock or personal injury. IMPORTANT! If you are unsure about the installation of your system, contact EWS customer service or consult a professional plumber. IMPORTANT! This system must be installed in compliance with applicable state and local codes, law, and regulations. -
Page 8: Where To Install The System
location and setup UNPACkING AND INSPeCTION - Check the system components for damage or missing parts. WHeRe TO INSTALL THe SYSTeM Place system on the main water supply in order to supply filtered water to the entire home. Place the system where you want to install the unit. Whether inside or outside, make sure the unit is level and on a firm base. ... - Page 9 installation instructions - all filter systems INSTALLATION Turn off gas or electric supply to the water heater(s). Turn off the main water supply. open a hot and cold faucet to drain house water pipes. NOTe: Keep those hot and cold faucets open until these instructions tell you to close. Keep bypass closed. Move the assembled system into installation position and check that Valve is securely fastened to the Tank.
- Page 10 installation Instructions - all filter systems - plumbing connections Locate water line or pipe to be cut and make sure of direction of water flow. CAUTION: Do not cross-connect or plumb backwards. Make sure of the direction of water flow from cut pipe to be connected.
- Page 11 installation Instructions - all systems - drain connections A word about the proper installtion of a drain line. It appears simple, however if simple mistakes are made it can create many problems associated with this or any system. Please read the instructions below to avoid any issues. Plumb rigid tubing only (PVC recommended if code applicable) directly to the 1”...
-
Page 12: Electrical Connection
installation Instructions - all systems - electrical connections INSTALL eLeCTRICAL CONNeCTION Connect electrical power by plugging the transformer into a standard grounded and unswitched 110/115/120v electrical outlet. If outlet is over 9 feet away use 18 gauge extension cord to connect up to 100 feet away. Do not exceed 100 feet. - Page 13 setting the clock Touch the box in the upper left hand corner where a day & time are blinking. The day And Time screen will appear Day And Time NoTe: Month Year day & Time are the only changes needed. system does not need any additional programming.
- Page 14 start up procedure - fill the tank and flush the system outlet closed FILL THe TANk - SLOWLY Main water supply is open, plumbing lines have open been flushed and tub or faucet is closed (Step #12) inlet slightly Open the inlet slightly on the bypass inlet as shown CAUTION:...
- Page 15 this is what the system is doing and we want to see clear drain water Keep the inlet to the bypass open and make sure the outlet is still closed These are the system start up and self-cleaning cycles and the duration: Backwash 2 minutes purges air in system and begins filling the tank...
-
Page 16: System Ready For Use
open outlet for service and go through a checklist to avoid any issues OPeN OUTLeT ON THe bYPASS TO PUT THe SYSTeM IN FINAL SeRVICe POSITION outlet open inlet & outlet system is in service position inlet System is ready for use. Turn on gas or electric supply to the water heater(s). - Page 17 other buttons you can push on the screen Water Treatment vacation Mode: 4000 Press the button and Vacation Mode will be in the upper right box. 10:30 am treatment The system will not backwash until the button is pressed again and the upper right box returns to the normal setting.
- Page 18 1035 and CWl-spectrum systems the system. 4” opening: all eWs-spectrum, and all 1465 and 1865 systems Note - Freeboard: Top 1/3 of tank is empty for proper backwash and lift of filtration media for the automatic self...
-
Page 19: Warranty
Warranty Notification - As Published and Available Online Notification: This warranty is referenced by EWS, Inc. in all literature, addressed in General Terms and Standard Conditions of Sale, and is published in its entirety in all EWS, Inc. product manuals, websites, and in all service guides supplied with all product. Limited Warranty: EWS, Inc., a Nevada corporation, hereby warrants all products to the original consumer purchaser to be free from defects in material and workmanship as stated in the following paragraphs:... - Page 20 Digestive: Crohn’s & Colitis • • • • • • • oceans Inland Water Ways Wetlands Forestry soil ALL FILTRATION PRODUCT PROUDLY MADE & ASSEMBLED IN THE USA EWS Logo and Environmental Water Systems are Registered Trademarks and the Property of EWS, Inc.
