- Page 1 PRODUCT AND INSTALLATION MANUAL Pre-Sediment Filtration System Model NuMbers: self-cleaning system - reduction of particulate sediment down to 3 microns: Presed-1354 Retain this Product & Installation Manual for Helpful Information Please Register Your System Revised 12/01/2017 V: 1.7...
-
Page 2: Simple Steps For A Correct Installation And Happy Customer
If you don’t read this service guide at least read these 7 simple steps SIMPLe STePS FOR A CORReCT INSTALLATION AND A HAPPY CUSTOMeR set up system and install it on the main water supply coming into the home Page 6-7 Use corrugated flexible stainless or some other flexible piping to make the plumbing connections Page 8... -
Page 3: Installation Dimensions For Systems
- Model #’ Presed-1354 For Illustration Purposes Only: Tank, valve and all contents (as pictured below) for these systems are delivered fully assembled*. Electric transformer, bypass and supplied adaptors some assembly required. Pictured: Presed-1354 depth: minimum 22” needed for proper installation... -
Page 4: Table Of Contents
table of contents SIMPLe STePS FOR A CORReCT INSTALLATION AND HAPPY CUSTOMeR ........INSTALLATION DIMeNSIONS FOR SYSTeMS ..................IMPORTANT SAFeTY INFORMATION – All Systems Instructions Before Using ......................LOCATION AND SeTUP - All Systems ....................... unpacking and Inspection Where to Install the system drain location Outside Installation (where applicable) INSTALLATION INSTRUCTIONS - All Systems... -
Page 5: Important Safety Information - All Systems
IMPORTANT SAFeTY INFORMATION - ALL SYSTeMS CAUTION: read and follow the information in this manual to minimize the risk of electric shock or personal injury. IMPORTANT! If you are unsure about the installation of your system, contact EWS customer service or consult a professional plumber. IMPORTANT! This system must be installed in compliance with applicable state and local codes, law, and regulations. -
Page 6: Location And Setup - All Systems
location and setup UNPACKING AND INSPeCTION - Check the system components for damage or missing parts. wHeRe TO INSTALL THe SYSTeM Place system on the main water supply in order to supply filtered water to the entire home. Place the system where you want to install the unit. Whether inside or outside, make sure the unit is level and on a firm base. ... -
Page 7: Installation Instructions - All Systems
installation instructions - all systems INSTALLATION Turn off gas or electric supply to the water heater(s). Turn off the main water supply. open a hot and cold faucet to drain house water pipes. NOTe: Keep those hot and cold faucets open until these instructions tell you to close. Keep bypass closed. Move the assembled system into installation position and check that Valve is securely fastened to the Tank. - Page 8 installation Instructions - all systems - plumbing connections Locate water line or pipe to be cut and make sure of direction of water flow. CAUTION: Do not cross-connect or plumb backwards. Make sure of the direction of water flow from cut pipe to be connected.
-
Page 9: Drain Line
installation Instructions - all systems - drain connections A word about the proper installtion of a drain line. It appears simple, however if simple mistakes are made it can create many problems associated with this or any system. Please read the instructions below to avoid any issues. Plumb rigid tubing only (PVC recommended if code applicable) directly to the 1”... -
Page 10: Electrical Connection
installation Instructions - all systems - electrical connections INSTALL eLeCTRICAL CONNeCTION Connect electrical power by plugging the transformer into a standard grounded and unswitched 110/115/120v electrical outlet. If outlet is over 9 feet away use 18 gauge extension cord to connect up to 100 feet away. Do not exceed 100 feet. -
Page 11: Set The Time Of Day
setting the clock Touch the box in the upper left hand corner where a day & time are blinking. The day And Time screen will appear Day And Time NoTe: Month Year Day & Time are the only changes needed. system does not need any additional programming. -
Page 12: Tank Fill Slowly
start up procedure - fill the tank and flush the system outlet closed FILL THe TANK - SLOwLY Turn on main water supply open Open the inlet slightly on the bypass inlet as shown slightly inlet flow CAUTION: Open slowly to prevent rapid flow and high initial pressure into the system water Treatment 23 h START UP TO FLUSH THe SYSTeM... - Page 13 this is what the system is doing and we want to see clear drain water Keep the inlet to the bypass open and make sure the outlet is still closed These are the system start up and self-cleaning cycles and the duration: Backwash 10 minutes purges air in system and begins filling the tank...
-
Page 14: Last Steps Before Leaving The System
open outlet for service and go through a checklist to avoid any issues OPeN OUTLeT ON THe BYPASS SYSTeM IN FINAL SeRVICe POSITION outlet open inlet & outlet system is in service position inlet System is ready for use. Turn on gas or electric supply to the water heater(s). To ready home for filtered water, please flush all the water throughout the home. -
Page 15: Touch Screen Other Options
other buttons you can push on the screen water Treatment Vacation Mode: 2500 Press the button and Vacation Mode will be in the upper right box. 10:30 am treatment The system will not backwash until the button is pressed again and the upper right box returns to the normal setting. -
Page 16: Product Blow-Out (For Illustration Purposes)
Adaptor 1”: Most Common direct threaded attachment to the bypass for 3/4” up to 1-1/4” Drain Adaptor (DLFC) main water lines Presed-1354 - 7gpm Adaptor 1-1/2”: Note: drain line to properly air gapped direct threaded attachment location is not supplied by EWS to the bypass for 1-1/4”... -
Page 17: Schematic For The Correct Order Of Equipment (If Applicable)
schematic for varied or difficult well water conditions CONDITIONS APPLICATIONS source Water - Test results based on Test results Pre-Treatment: Chlorination/Chemical Feed Coliform/Bacterial/E-Coli microorganism problems, decaying vegetation, organic (as needed) bonding, Iron/manganese bacteria Ozonation Tannins (yellow) UV (only safeguard, not a solution) Pre-treatment is the primary need to disinfect, break down organic bonds and/or add oxygen to water. - Page 18 left blank...
-
Page 19: Warranty
Warranty Notification - As Published and Available Online Notification: This warranty is referenced by EWS, Inc. in all literature, addressed in general Terms and Standard Conditions of Sale, and is published in its entirety in all EWS, Inc. product manuals, websites, and in all service guides supplied with all product. Limited warranty: EWS, Inc., a Nevada corporation, hereby warrants all products to the original consumer purchaser to be free from defects in material and workmanship as stated in the following paragraphs:... -
Page 20: Back Cover With Ews Contact Information
Digestive: Crohn’s & Colitis • • • • • • • oceans Inland Water Ways Wetlands Forestry soil ALL FILTRATION PRODUCT PROUDLY MADE & ASSEMBLED IN THE USA EWS Logo and Environmental Water Systems are Registered Trademarks and the Property of EWS, Inc.
