1
Since 1987
PRODUCT AND INSTALLATION MANUAL
Spectrum Series Systems
Whole Home Water Filtration
Model Numbers:
Spectrum Chlorine Systems:
CS-EWS-1354-7000
CS-CWL-1354-7000
Spectrum Chloramine Systems:
EWS-CC-1865-7
CWL-CC-1865-7
ALL FILTRATION PRODUCT PROUDLY MADE & ASSEMBLED IN THE USA
EWS, Inc./Environmental Water Systems
office. 702.256.8182
Monday - Friday, 8:30 am - 4:30 pm Pacific Standard Time
fax. 702.256.3744
www.ewswater.com
e-mail. customerservice@ewswater.com
Retain this Product & Installation Manual for Maintenance and Information
Please Register this Product - It is a Requirement for Warranty
Revised 11/11
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Environmental Water Systems Spectrum CS-EWS-1354-7000
Summary of Contents for Environmental Water Systems Spectrum CS-EWS-1354-7000
- Page 1 CS-EWS-1354-7000 CS-CWL-1354-7000 Spectrum Chloramine Systems: EWS-CC-1865-7 CWL-CC-1865-7 ALL FILTRATION PRODUCT PROUDLY MADE & ASSEMBLED IN THE USA EWS, Inc./Environmental Water Systems office. 702.256.8182 Monday - Friday, 8:30 am - 4:30 pm Pacific Standard Time fax. 702.256.3744 www.ewswater.com e-mail. customerservice@ewswater.com Retain this Product & Installation Manual for Maintenance and Information...
-
Page 2: Table Of Contents
Table of Contents SCHEMATIC: SPECTRUM SYSTEM ....................SCHEMATIC: VALVE, BYPASS, CONTROLS - ALL SYSTEMS .............. SCHEMATIC: SPECTRUM CHLORAMINE SYSTEM ............... SPECTRUM CHLORAMINE SYSTEM: ON SITE ASSEMBLY PROCEDURE ........... IMPORTANT SAFETY INFORMATION – All Systems Instructions Before Using ..................SETUP - All Systems ........................ -
Page 3: Schematic: Spectrum System
SCHEMATIC: SPECTRUM SYSTEMS Model #’s: CS-EWS-1354-7000, CS-CWL-1354-7000 For Illustration Purposes Only: Cut-away of CS-EWS-1354-7000 Tank, valve and all contents (as pictured below) delivered fully assembled. Bypass and supplied adaptors some assembly required. 18” clearance needed from center of tank for proper installation Valve (front view) Not pictured: Bypass Valve to the rear of the Valve. -
Page 4: Schematic: Valve, Bypass, Controls - All Systems
SCHEMATIC: ALL SYSTEMS - Valve, Bypass, Adaptors and Valve Controls ALL SYSTEMS: Illustration of Complete Valve Assembly, Bypass and Provided Adaptors: 18” Overall Length Front to Back built-in bypass valve body 1”, 1 1/4” & 1 1/2” MNPT adaptors provided removable valve cover... -
Page 5: Schematic: Spectrum Chloramine System
SCHEMATIC: SPECTRUM CHLORAMINE SYSTEMS Model #’s: EWS-CC-1865-7, CWL-CC-1865-7 For Illustration Purposes Only: Cut-away of EWS-CC-1865-7 On-Site Assembly Required Due to shipping weight for all Spectrum Chloramine Systems, tank, valve and all contents (as pictured below) must be assembled on site. Bypass and supplied adaptors some assembly required. -
Page 6: Spectrum Chloramine System: On Site Assembly Procedure
Assembly Instructions - Spectrum Chloramine Systems Only CHECKING THE PARTS LIST PRIOR TO ASSEMBLY Below is a box count for each system and its’ contents. EWS-CC-1865-7 and CWL-CC-1865-7 should have 8 boxes. One Box - Tall containing the 18” x 65” Tank with a 1.26” (32mm) Riser (ICN Riser Manifold - EWS Series only) ... -
Page 7: Important Safety Information - All Systems
Important Safety Information - All Systems CAUTION: Read and follow the information in this manual to minimize the risk of electric shock or personal injury. IMPORTANT! If you are unsure about the installation of your system, con- tact EWS customer service or consult a professional plumber. IMPORTANT! This system must be installed in compliance with applicable state and local codes, law, and regulations. -
Page 8: Setup - All Systems
Setup - All Systems UNPACKING AND INSPECTION Check the system components for damage or missing parts. WHERE TO INSTALL THE SYSTEM Consider the following points when determining where to install any Spectrum System point of entry filter: Place system on the main water supply in order to filter and supply filtered water to the entire home. CAUTION: DO NOT install on a soft water loop or bypass of other water lines where the filtered water will not be available for household use. -
Page 9: Plumbing Connections
Installation Instructions - All Systems - Plumbing Connections INSTALLATION Turn off gas or electric supply to the water heater(s). Turn off the main water supply. Open a hot and cold faucet to drain house water pipes. NOTE: Keep those hot and cold faucets open until these instructions tell you to close. Move the system assembly into installation position and check that Valve is securely fastened to the Tank. - Page 10 Installation Instructions - All Systems - Plumbing Connections - continued Locate water line or pipe to be cut and make sure of direction of water flow. CAUTION: Do not cross-connect or plumb backwards. Make sure of the direction of water flow from cut pipe to be connected. Plumb INLET and OUTLET connections to and from the system.** •...
-
Page 11: Drain Line
Installation Instructions - All Systems - Drain Line and Electrical INSTALL DRAIN LINE Plumb rigid tubing only (PVC recommended if code applicable) directly to the 1” MNPT drain fitting. NOTE: Install a union on the drain line in order make any service or need to disconnect easier in the future. Connect and route the drain line to the drain point. -
Page 12: Start-Up Procedures - All Systems
Startup Procedures - All Systems - Tank Fill FLUSH AND CLEAR HOME LINES WITH SYSTEM STILL IN BYPASS Illustration of Bypass Valve in Bypass Keep Bypass Valve in “bypass” position Top View and follow startup procedures Outlet Inlet NOTE: Holes appear on the top and bottom of Bypass Valve when in bypass Outlet Valve Inlet Valve... -
Page 13: Setting The Time Of Day While The Tank Is Filling Slowly
Startup Procedures - All Systems - Flushing the System SETTING THE TIME OF DAY WHILE THE TANK IS FILLING SLOWLY While tank is slowly filling, Set the Time of Day by presssing either the Up or Down Button. The Parameter Display will read “TD” for Time of Day and the Programming Icon will appear Continue to press either Up or Down Button until the Data Display reads the current time of day. - Page 14 Startup Procedures - All Systems - Flushing the System FLUSHING THE SYSTEM - CONTINUED When the air in the system is pushed out and water begins to flow continuously through the drain line, it is time to completely open the Inlet Side (only) of the BypassValve. This will purge air and relieve the pressure within the tank and completely fill the tank in the proper order.
-
Page 15: Last Steps Before Leaving The System
Final Steps - All Systems LAST STEPS BEFORE LEAVING THE SYSTEM Check the drain water is clear of any filtration media dust and/or fines. A quick repeat of the the flushing procedure is recommended. Start a backwash again (Page 13, Step # 19) and once water flows under full pressure through the drain line check for any dust and/or fines. - Page 16 INTENTIONALLY LEFT BLANK Complete sections to assist with any troubleshooting, parts listings, replacement filters, media replacement information, product specifications and information are all available online. If you need any additional information or assistance, please call EWS, Inc. customer service. 702.256.8182 m-f, 8:30am - 4:30pm, pacific standard time customerservice@ewswater.com www.ewswater.com...
- Page 17 Lung & Respiratory Allergy & Asthma Dermatology & Skin Digestive: Crohn’s & Colitis • • • • • • • Oceans Inland Water Ways Wetlands Forestry Soil EWS Logo and Environmental Water Systems are Registered Trademarks and the Property of EWS, Inc.
