3. Engage the brakes on all (4)
casters.
Locate the casters on the opposite
side from the side handle.
Loosen the (2) bolts & washers
closest to the outer edge of the cart.
DO NOT REMOVE BOLTS! ONLY
LOOSEN THE BOLTS!
4. Slide the open slots of the
Caster Locking Bracket into
the gap between the washer
and the caster plate. The long
part of the bracket will slide
in between the caster forks to
prevent them from turning.
Securely tighten the bolts.
5. Repeat Step 4 for the other
caster.
Installed Caster
Locking Bracket
Loosen (2)
outer bolts
DO NOT
REMOVE!
