- Page 1 User Manual WISE-4671 Advanced Industrial Cat.NB1/ Cat.M1 Wireless IO Module...
- Page 2 The documentation and the software included with this product are copyrighted 2020 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. also reserves the right to improve the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
- Page 3 In this event, users are required to correct the interference at their own expense. Technical Support and Assistance Visit the Advantech website at www.advantech.com/support to obtain the latest product information. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
- Page 4 WISE-S617T 2AI/2DI/1DO/1RS-485 with Terminal Block WISE-S672 6DI/1RS-485/1RS-485 or RS-232 with M12 Connec- tors Note! A micro-B USB cable for configuring WISE-4671 nodes is available for order: 1700023619-01 Micro USB type-B male to USB type-A male cable, 1 M WISE-4671 User Manual...
- Page 5 According to IEC 704-1:1982 standards, the sound pressure level at the opera- tor's position does not exceed 70 dB (A). DISCLAIMER: These instructions are provided in accordance with IEC 704-1. Advan- tech disclaims all responsibility for the accuracy of any statements contained herein. WISE-4671 User Manual...
- Page 6 Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. WISE-4671 User Manual...
- Page 7 L’exploitation est autorisée aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable. WISE-4671 User Manual...
- Page 8 WISE-4671 User Manual viii...
-
Page 9: Table Of Contents
NB-IoT (Cat. NB) and LTE-M (Cat.M) ............2 WISE-4671 Feature Highlights..............2 WISE Series Family .................. 3 System Diagram & Battery Switch ............3 Figure 1.1 WISE-4671 System Diagram & Battery Switch ..4 LED Indicators................... 4 Figure 1.2 WISE-4671 LED Indicators......... 4 Membrane Button..................6 Figure 1.3 WISE-4671 Membrane Button........ - Page 10 WISE-S617T I/O Application Wiring ........... 27 Figure 3.6 WISE-S617T I/O Application Wiring Diagram ..27 3.10 Power Supply Wiring................28 3.11 Block Diagram..................28 Figure 3.7 WISE-4671 with WISE-S600/S600T Block Diagram 28 3.12 Configuration Interface................28 Chapter Firmware Specifications....29 Connection....................
-
Page 11: Chapter 1 Product Introduction
Chapter Product Introduction... -
Page 12: Nb-Iot (Cat. Nb) And Lte-M (Cat.m)
IoT applications such as smart cities, smart agriculture and remote asset management. WISE-4671 series is a cellular based IoT wireless sensor node compliant with LTE Cat. NB1 and Cat. M1 with external for flexible installation. In addition to offering var-... -
Page 13: Wise Series Family
GPS, a solar rechargeable battery, and an IP65-rated enclosure to protect from water and dust ingress. The WISE-4671 wireless I/O module features an intelligent modular design that sup- ports various I/O configurations according to usage requirements. This allows users to easily integrate their desired I/O module (WISE-S672, WISE-S614 etc.) with the WISE-4671 module. -
Page 14: Led Indicators
Figure 1.1 WISE-4671 System Diagram & Battery Switch Note! Turn on the battery switch to recharge the battery. LED Indicators Figure 1.2 WISE-4671 LED Indicators WISE-4671 User Manual... - Page 15 2 ON – 40% <= v < 60% Button) 3 ON – 60% <= v < 80% 4 ON – v >= 80% Note! If WISE-4671 is powered by battery, the LED indicators will turn off after 15 seconds for power saving. WISE-4671 User Manual...
-
Page 16: Membrane Button
Membrane Button There is a membrane button on the WISE-4671 front panel that can be used to con- figure between operating modes and light up the LED indicators. Please see the membrane button and behavior diagrams below. Figure 1.3 WISE-4671 Membrane Button External Line Power Mode When the battery is powered up (when the device is in “Line Power”... -
Page 17: Packing List
Figure 1.4 WISE-4671 Membrane Button Behavior Packing List WISE-4671 NB-IoT/LTE-M Wireless I/O Module 1 x WISE-4671 Wireless I/O Module 1 x Antenna 1 x Mounting Bracket 1 x WISE-4671 Startup Manual 1 x China RoHS Declaration ... - Page 18 WISE-S672 6DI/1RS-485/1RS-485 or RS-232 Module 1 x WISE-S672 I/O Module 1 x I/O Information Label A micro-B USB cable for configuring WISE-4671 is available for order: Note! 1700023619-01 Micro USB type-B male to USB type-A male cable, 1 M...
-
Page 19: Chapter 2 Hardware Installation
Chapter Hardware Installation... -
Page 20: Modular Design
The wireless sensor nodes for WISE-4671, like those for all WISE-4000 series mod- ules, are designed as separate units. The procedure for installing these nodes in the module is explained in the following sections. Modular Design WISE-4671 features a modular design that supports various I/O configurations. The... -
Page 21: System Dimensions
System Dimensions Figure 2.2 WISE-4671 Dimensions Figure 2.3 WISE-S600 Series I/O Module Dimensions WISE-4671 User Manual... -
Page 22: Din-Rail Mounting
Figure 2.4 WISE-S600T Series I/O Module Dimensions DIN-Rail Mounting WISE-4671 modules can be fixed to a cabinet with mount rails. Use a flathead screw- driver to affix the DIN rail mounting adapter to the module. Then attach the end brackets provided with the product to prevent sliding. - Page 23 Figure 2.6 DIN-Rail Mounting Adapter Installation Figure 2.7 DIN-Rail Mounting (Front View) WISE-4671 User Manual...
-
Page 24: Wall Mounting
Figure 2.8 DIN-Rail Mounting (Rear View) Wall Mounting The plastic wall-mount bracket provided with the product, can be used to mount WISE-4671 on a wall, panel, or cabinet. Figure 2.9 Wall Mount Bracket Installation WISE-4671 User Manual... -
Page 25: Pole Mounting
The pole-mounting ring must be unlocked with a screwdriver before inserting it into the module. To mount the module on the pole, tightly lock the pole-mounting ring. Figure 2.10 Pole Mount Bracket Installation (Front View) Figure 2.11 Pole Mount Bracket Installation (Rear View) WISE-4671 User Manual... - Page 26 WISE-4671 User Manual...
-
Page 27: Chapter 3 Hardware Specifications
Chapter Hardware Specifications... -
Page 28: General Specifications
Storage Humidity: 0 ~ 95% RH (non-condensing) Note! Batteries are at risk of exploding if it is incorrectly installed. Do not attempt to replace the battery yourself. Batteries should only be replaced by qualified service personnel. WISE-4671 User Manual... -
Page 29: Power
±0.2% of FSR (current) Input Range: ±150mV, ±500mV, ±1 V, ±5V, ±10V, 0 ~ 150mV, 0 ~ 500mV, 0 ~ 1V, 0 ~ 5V, 0 ~ 10V, 0 ~ 20mA, 4 ~ 20mA, ±20mA Input Impedance: WISE-4671 User Manual... -
Page 30: Wise-S615/Wise-S615T Rtd I/O Module
Supports 32-bit counter input function (maximum signal frequency: 200 Hz) Supports keep/discard counter value when power OFF. (Only work with line powered model) Supports frequency input function (maximum signal frequency: 200 Hz) Supports inverted digital input status WISE-4671 User Manual... - Page 31 Signals: DATA+ and DATA- Protection: 15 kV ESD Supported Protocols: – Modbus/RTU (Up to 32 addresses with a maximum of 8 instructions) – Modbus/RTU (Up to 64 addresses with a maximum of 30 instructions) WISE-4671 User Manual...
-
Page 32: Wise-S672 I/O Module
Parity: None, Odd, Even Flow Control: Auto flow control (RS-485 only) Signals: DATA+ and DATA- Protection: 15 kV ESD Supported Protocols: – Modbus/RTU (Up to 32 addresses with a maximum of 8 instructions) WISE-4671 User Manual... -
Page 33: Wise-S600 I/O Pin Assignment
DI_COM RS-232 TX Yellow IA1- RS-232 RX Gray IA2+ RTD1+ DO_GND DATA 1- Pink IA2- RTD1- RS-485 D+ DATA 1+ Blue IA3+ RTD1 COM RS-485 D- IA3- RS-485 GND RS-232 GND Brown White -VS/ SP- Blue Black WISE-4671 User Manual... -
Page 34: Wise-S600T I/O Pin Assignment
DI 0 RTD 3- RS-485 AI 3+ DATA1+ DI 1 COM 3 VOUT AI 3- DATA1- DI COM IO INT DATA+ MCU INT RS-485 RS-232 DATA- DATA+ DATA- Panel In Panel In Panel In Panel In VOUT GND WISE-4671 User Manual... -
Page 35: Application Wiring Of Wise-S600 I/O Module With M12 Connectors
Application Wiring of WISE-S600 I/O Module with M12 Connectors 3.8.1 WISE-S614 I/O Application Wiring Figure 3.2 WISE-S614 I/O Application Wiring 3.8.2 WISE-S615 I/O Application Wiring WISE-4671 User Manual... -
Page 36: Wise-S617 I/O Application Wiring
3.8.3 WISE-S617 I/O Application Wiring Figure 3.3 WISE-S617 I/O Application Wiring Diagram 3.8.4 WISE-S672 Application Wiring Figure 3.4 WISE-S672 Application Wiring Diagram WISE-4671 User Manual... -
Page 37: Application Wiring Of Wise-S600T I/O Module With Terminal Block
Application Wiring of WISE-S600T I/O Module with Terminal Block 3.9.1 WISE-S614T I/O Application Wiring Figure 3.5 WISE-S614T I/O Application Wiring Diagram 3.9.2 WISE-S617T I/O Application Wiring Figure 3.6 WISE-S617T I/O Application Wiring Diagram WISE-4671 User Manual... -
Page 38: Power Supply Wiring
3.10 Power Supply Wiring WISE-4671 modules are designed to support a standard unregulated 24-V indus- trial power supply. However, they can also accept 10 ~ 50 V input with a peak-to- peak power ripple of 200 mV. The immediate ripple voltage should be maintained at 10 ~ 50 V . -
Page 39: Firmware Specifications
Chapter Firmware Specifications... -
Page 40: Connection
Internet Explorer 10 or above 4.2.2 Installing WISE Studio The latest version of WISE Studio is available on the Advantech support site: http:// support.advantech.com/. To install the program, download the installation file and execute it locally. WISE-4671 User Manual... -
Page 41: A Brief Introduction To Wise Studio
Figure 4.1 Communication Box There are several communication interfaces for configuring different WISE modules. The WISE-4671 series uses the USB-serial interface for configuration. Refresh: Pressing this button refreshes the USB-serial interface. USB-Serial: This block is for connecting to a WISE module via USB. The available USB-serial port number will be shown here. -
Page 42: Information Page
Description: Any comments describing this module can be given here. Power Status The power status displays the power source and its status. If there is no battery included, it will show line power (no battery) on the module. PIN Status: WISE-4671 User Manual... - Page 43 Module Description: Description of the WISE module. Firmware Description: Firmware and bootloader version of the WISE module. Web Page Version: The web page version is given at the bottom of the Config- uration page before the copyright information. WISE-4671 User Manual...
-
Page 44: Connecting To A Cellular Network
Operator Name: Name of the cellular network operator. Modem Manufacturer: Manufacturer of the RF module. IMEI Code: International Mobile Equipment Identity of the modem. IMSI Code: International Mobile Subscriber Identity of the SIM card. WISE-4671 User Manual... -
Page 45: I/O Status Configuration
Tag Name: Each channel can be given a tag name for identification. Mode: The operation mode of each channel can be configured here, or chan- nels can be disabled to improve the performance of enabled channels. After a WISE-4671 User Manual... - Page 46 In the Status page, the current count value of the selected channel is displayed in the Counter value box. The counter can be started/stopped by pressing Start/Stop, which is located beside the counter WISE-4671 User Manual...
- Page 47 "logic low" the latch is cleared manually, which will return the logic status to "logic high". The logic status is viewable on the latch status LED dis- play on the DI Status page. Clear the latch by clicking Clear on this page. WISE-4671 User Manual...
- Page 48 After a channel has been configured, pressing Submit at the end of this page will apply the changes. Channel Mask: Each channel can be disabled individually for reducing date traffic during communication. Refresh: Refresh the configuration. WISE-4671 User Manual...
- Page 49 The number of pulses to be generated can be set by entering the value in the box to the right of Fixed total. After the pulse output mode has been selected, click Start or Stop to generate or stop the pulse output. WISE-4671 User Manual...
- Page 50 Channel: Indicates the number of bits. A maximum 64 bits can be shown here, but you may map only fewer than 64 coils as bits, which makes the empty bits invalid. The same applies to words, which may also have empty channels. WISE-4671 User Manual...
- Page 51 Slave ID: Different slave devices in the same RS-485 port have different slave IDs; enter the slave address of the Modbus devices that are connected to the WISE module here. WISE-4671 User Manual...
- Page 52 After you have changed the rule configurations, logged data in the data logger will be cleared to accommodate the new data structure of the data logger under the new configuration. Note! You can hover your mouse over the table title rows to view tooltips. WISE-4671 User Manual...
- Page 53 4.2.6.4 Analog Input For WISE-4671, users can choose WISE-S614 to support Analog Input. For the AI channel, the Current/Max/Min status will be shown in the status page, which includes the input range. The current status shows the latest AI value, and also the input range.
- Page 54 WISE-4671 User Manual...
- Page 55 0~10 V which shows 0~100°C. It would be better to read 0~100 in Modbus with float- ing data format. In the previous case, you can configure the “Physical Min Scaling Value” and “Low Scaling Value” as 0, which shows the input voltage 0 V as physical value 0°C; and WISE-4671 User Manual...
- Page 56 After you choose the alarm mode for high alarm or low alarm, you can define the high alarm value or low alarm value by entering the value in Alarm limit text box. WISE-4671 User Manual...
- Page 57 The Burnout Detection function, or open-wired function, is designed for 4~20mA input range or temperature input range. For the WISE-4671, the burnout signal is activated when the current is less than 3mA. The Modbus flag indicates that the wire of the sensor connected to the channel has burned out.
- Page 58 WISE and sensors. 4.2.6.5 Power Output For WISE-4671, users can choose WISE-S617 or WISE-S617T to support Power Output function to power on the external sensors. WISE-S617 and WISE-S617T have 2 power output pins. Specification as follows.
- Page 59 Analog Input pin runs. Default setting on Power Output Delay Time is 1 second. This means the Analog input channel will run after 1 second delay time from the power output pin. WISE-4671 User Manual...
- Page 60 Delay Time setting: Power Output Delay Time setting makes sure the sensor is ready before the COM1 runs. Default setting on Power Output Delay Time is 1 sec- ond, which means the COM1 will run after 1 second delay time from power output pin. WISE-4671 User Manual...
-
Page 61: System Configuration
WISE module is not able to connect to cellular base station. RF Reset Interval: Decides the time interval in minutes to reset the RF module in WISE module when WISE module is not able to connect to cellular base sta- tion. WISE-4671 User Manual... - Page 62 There is an RTC battery inside the WISE module that allows the user to view the cur- rent time. And since the cellular device will automatically adjust the time with the NTP server, WISE-4671 is not allowed to set the time zone and adjust the time manually. Control Restore to Default: The system configuration will be cleared and restored to fac- ...
- Page 63 You can find the latest official firm- ware releases on the Advantech support site (http://support.advantech.com/). You can also upload the configuration file or export the configuration file here.
-
Page 64: Data Logger
4.2.8 Data Logger The WISE-4671 series supports data logging. The I/O status can be logged in and queried from the module with up to 10,000 records. WISE-4671 also supports mini- mum 100,000 program-erase cycle per sector. Before you start the log function, please ensure that the RTC inside the WISE module has the correct time. - Page 65 Logger Configuration On this page, you can enable the local memory storage function. There are separate switches for enabling the logging of I/O data or system data. Simply turn ON the switches to enable logging. WISE-4671 User Manual...
- Page 66 Now you can click Query to query the data from local memory. Then, the data will be shown in a chart and table. Click Save to save the data from the WISE module in .Json format, or click Clear to clear all data in local memory. WISE-4671 User Manual...
-
Page 67: Diagnostician
The WISE module will push a notification in .Json format to your MQTT broker. You can switch the I/O Log to ON, and the WISE module will then start pushing the latest logged data to the MQTT broker. WISE-4671 User Manual... -
Page 68: Isensing Mqtt
4.2.11 iSensing MQTT WISE-4671 supports MQTT function, go to Configuration \ Cloud and select iSens- ing MQTT. Enter the Host Name of MQTT broker, here we use public broker provided by HiveMQ for demonstration. Then go to Advanced \ Data Logger \ Data Configuration, user can decide the update period in Log Conditions. - Page 69 I/O Log in Push Notification, then WISE will star to update the data. Go to HiveMQ web site http://www.hivemq.com/demos/websocket-client/, enter the Host and Port as following figure, then click Connect. Go to Subscriptions block, and click Add New Topic Subscription. WISE-4671 User Manual...
- Page 70 Enter the topic Advantech/IMEI_Code/data, you can find the IMEI code in WISE- Studio in the Configuration \ Cellular \ Cellular Information page. After subscribing to the WISE topic, you will see the data from WISE. WISE-4671 User Manual...
-
Page 71: Software Specifications
Chapter Software Specifications... -
Page 72: Connection Setting On Wise-4671
Communication Box In this screen, there are several communication interfaces for configuring various WISE modules. The WISE-4671 series uses the USB serial interface for configura- tion. Refresh: Pressing this button refreshes the USB serial interface. - Page 73 The default UUID is a combination of the model name and IMEI. Users can modify this value. Location Information: The module location is provided here. Description: Any comments about the module can be displayed here. Power Status displays the power source and battery status. WISE-4671 User Manual...
- Page 74 Operator Name: Name of the cellular network operator. Modem Manufacturer: Manufacturer of the RF module. IMEI Code: International Mobile Equipment Identity of the modem. IMSI Code: International Mobile Subscriber Identity of the SIM card. WISE-4671 User Manual...
- Page 75 Use WISE-Studio to obtain data of the WISE-4671 node for configuring the WISE- 3610 gateway. Cellular Configuration Basic setting After the SIM card has been inserted into the WISE module, it can be configured in this page: – Auto Write PIN Code: Enables the PIN code to be saved to the WISE mod- ule.
- Page 76 Advanced Setting – RAT Type: Select the operating mode category. – Band Mask: Select the specific band by shortening the connection time. On this page, users can obtain the WISE module coordinates. WISE-4671 User Manual...
- Page 77 The WISE-4671 module is equipped with GPS. The options on this page allow users to enable/disable GPS positioning. To save power, GPS is disabled by default. More- over, users can configure the specific update interval. As shown below, the GNSS System field features a dropdown menu with different GPS system combination options.
- Page 78 The filter can be enabled/disabled by clicking the Digital Filter check box. When the filter is enabled, the minimum acceptable signal width can be defined in the Min. Low Signal Width and Min. High Signal Width fields (increment: 0.1 ms). WISE-4671 User Manual...
- Page 79 “logic low” until the latch is cleared manually, which will return the logic status to “logic high”. The logic status can be determined via the latch sta- tus LED included on the IO Status page. Clear the latch by clicking Clear. WISE-4671 User Manual...
- Page 80 COM1 (RS-485 Port) WISE-4671 features one RS-485 port for Modbus gateway functionality. This port can be used to poll data from RS-485 Modbus/RTU slave devices, such as Advant- ech’s ADAM-4000 or ADAM-5000/485 series devices. Status Navigate to the COM1 tab to check the status or configure the RS-485 Modbus mas- ter function.
- Page 81 Modbus slaves Delay Between Polls: This item allows users to set the delay time between each Modbus instruction CRC Check: This item allows users to set the CRC check to ignore Modbus CRC errors WISE-4671 User Manual...
- Page 82 However, the read scan interval may depend on factors such as the Baud rate, slave device response time, and delay between polls. See the Diagnostician page to check the real response time as a reference for the scan interval value. WISE-4671 User Manual...
- Page 83 Move the mouse cursor over the table title rows to view tips. Diagnostician Because every device has a different response time, the WISE-4671 module sup- ports a diagnostics function for testing the response time of each rule. This is intended to reduce the scan interval. Users can refer to the response time shown on this page when configuring the Scan Interval in the Rule Setting pages.
- Page 84 System Configuration Time & Date WISE modules have a built-in RTC that allows users to view the current time, set the time zone, and adjust the time by pressing Click Me to read the time from host devices. WISE-4671 User Manual...
- Page 85 Firmware To update the firmware, go to the Firmware page in System Configuration and click the update file. The latest official firmware releases are available on the Advantech support website (http://support.advantech.com/). Users can also upload or export the configuration file.
- Page 86 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2020...
