  • Page 1 User Manual WISE-4210 Series...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
  • Page 3 This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
  • Page 4 1x I/O sticker WISE-S250-A  1x WISE-S250-A I/O Module  1x China RoHS  4x Screws  1x I/O sticker WISE-S251-A  1x WISE-S251-A I/O Module  1x China RoHS  4x Screws  1x I/O sticker WISE-4210 Series User Manual...
  • Page 5 STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C (140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN A CONTROLLED ENVIRONMENT. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE WISE-4210 Series User Manual...
  • Page 6 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
  • Page 7 Les types d'antenne non inclus dans cette liste, et dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur. Approved antenna(s) list Type Gain Brand Manufacturer Dipole 2.19 dBi Advantech 1750008836-01 Dipole 1.33 dBi Advantech 1750008837-01 WISE-4210 Series User Manual...
  • Page 8 WISE-4210 Series User Manual viii...

  • Page 9: Table Of Contents

    Figure 2.6 WISE-S251 Pin Assignment........20 2.6.3 Application Wiring ............... 21 Figure 2.7 WISE-S214 Digital Input Wiring Diagram ....21 Figure 2.8 WISE-S214 Analog Input Wiring Diagram....21 Figure 2.9 WISE-S250 Digital Input Wiring Diagram ....22 WISE-4210 Series User Manual...
  • Page 10 Connection between AP and Nodes ............44 WISE-4210-AP Configuration ..............45 Setup WISE-4210 Network ..............47 Access WISE-4210 I/O Data by Modbus/TCP Protocol......47 Push WISE-4210 data by RESTful Web Service........50 Access WISE-4210 I/O Data by RESTful API......... 51 WISE-4210 Series User Manual...

  • Page 11: Chapter 1 Product Overview

    Chapter Product Overview...

  • Page 12: Series Family And Specifications

    Wireless Sensor Node WISE-4210-S231 with Temperature and Humidity Sensor I/O Module WISE-S214 4AI/4DI I/O Module WISE-S250 6DI, 2DO & 1RS-485 I/O Module WISE-S251 6DI, 1RS-485& 1RS-485 Mechanical Design and Dimensions Figure 1.1 WISE-4210 Dimension Front & Side WISE-4210 Series User Manual...

  • Page 13: System Diagram

    System Diagram Figure 1.2 WISE-4210 System Diagram WISE-4210 Series User Manual...

  • Page 14: Led Definition

    Receiving data from RS-485 Steady On Turn on at last 10ms COM Rx Green No data received from RS-485 Sending data to RS-485 Steady On Turn on at last 10ms COM Tx Yellow No data sent to RS-485 WISE-4210 Series User Manual...

  • Page 15: Wise-4210-S231

    Figure 1.4 WISE-4210-AP LAN Port LED Color Indication Behavior Both ends of devices are connected Link Green Not connected yet 100 Mbps Speed Yellow Less than 100 Mbps 1.4.2 WISE-4210-S231 Figure 1.5 WISE-4210-S231 LED Indicator WISE-4210 Series User Manual...
  • Page 16 No signal All Off Battery level (0%) All of LEDs will automatically go OFF after 15 seconds when battery power is used. RF RX and Signal Strength LEDs are only available in WISE Link v2 mode. WISE-4210 Series User Manual...

  • Page 17: Wise-4210

    1.4.3 WISE-4210 Figure 1.6 WISE-4210 LED Indicator WISE-4210 Series User Manual...
  • Page 18 No signal All Off Battery level (0%) All of LEDs will automatically go OFF after 15 seconds when battery power is used. RF RX and Signal Strength LEDs are only available in WISE Link v2 mode. WISE-4210 Series User Manual...

  • Page 19: Membrane Button

    WISE-4210-Sxxx end nodes have one membrane button on name plate. This button is design for switching different LED display mode or operation mode. Note! WISE-4210-AP doesn't have membrane button, please use LAN port to do further configuration. Figure 1.7 WISE-4210 Membrane Button WISE-4210 Series User Manual...
  • Page 20 Light Press (0.5 Sec) Read battery level Reset OTA mode Configuration Long Press (2 Sec) Leave OTA mode Tx Firmware Leave OTA mode NA *(LED indicator will go off automatically 15 secs later when using battery power.) WISE-4210 Series User Manual...

  • Page 21: Battery Power Switch

    1x China RoHS (UA series only)  1x Antenna (UA series only)  WISE-4210 NA/UA 1 x WISE-4210 NA/UA module   1 x Mounting bracket  1x China RoHS (UA series only)  1x Antenna (UA series only) WISE-4210 Series User Manual...
  • Page 22 Battery needs to order separately.  1760002647-01 3.6V/2500mAh AA Cylindrical Battery (non- rechargeable) Note! Micro-B USB cable for configuring WISE-4210 nodes can be ordered optionally.  1700023619-01 1M micro USB type-B male to USB type-A male cable WISE-4210 Series User Manual...

  • Page 23: Chapter 2 General Specification

    Chapter General Specification...

  • Page 24: General Specification

    868.4 Chanel 9 924.0 Chanel 10 868.8 Chanel 10 924.4 Note! The transmitting distance is subject to the environment of application site. Please perform site survey to determine the set up range of the wireless network. WISE-4210 Series User Manual...

  • Page 25: General

    625bps: 5 years with 10 minute update rate – 50kbps: 5 years with 1 minute update rate Note! The battery life is estimated with 2500mAh battery, SB-AA11 by Vitzro- cell Co.,Ltd. Testing condition:  WISE-4210-S231: Temperature/Humidity sensor  WISE-4210-S251: Digital input only WISE-4210 Series User Manual...

  • Page 26: Software

    Uplink Communication Port LAN port  Ethernet: IEEE 802.3u 10/100Base-T(X)  Connector: 1-port RJ-45  Protocol: Modbus/TCP, RESTful web API RS-485 port  Signal: DATA+, DATA-  Connector: 3.5-mm spacing plug-in screw terminal block  Protocol: Modbus/RTU WISE-4210 Series User Manual...

  • Page 27: Pin Assignment

    Response Time: 15 seconds (Achieving 63% of a step function) Long Term Drift: 0.05°C/Year (0.09°F/Year)  Humidity Sensor Input  Operating Range: 10~90% RH  Resolution: 0.1% RH  Accuracy: – ±4% for 0%~50% RH – ±6% for 50%~60% RH WISE-4210 Series User Manual...

  • Page 28: Pin Assignment

    Channels: 4  Support Data Scaling and Averaging Digital Input Channels 4 (Dry Contact)  Supports 32-bit counter input function (maximum signal frequency 200Hz)  Supports keep/discard counter value on power-off Support inverted digital input status  WISE-4210 Series User Manual...

  • Page 29: Pin Assignment

    Data Bits: 7, 8  Stop Bits: 1, 2  Parity: None, Odd, Even  Baud Rate (bps): 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200  Protocol: Modbus/RTU (Total 32 addresses by 8 max. instructions) WISE-4210 Series User Manual...

  • Page 30: Pin Assignment

    Stop Bits: 1, 2  Parity None, Odd, Even  Baud Rate (bps): 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200  Protocol: Modbus/RTU (Total 32 address by max. 8 instructions) 2.6.2 Pin Assignment Figure 2.6 WISE-S251 Pin Assignment WISE-4210 Series User Manual...

  • Page 31: Application Wiring

    2.6.3 Application Wiring WISE-S214 Figure 2.7 WISE-S214 Digital Input Wiring Diagram Figure 2.8 WISE-S214 Analog Input Wiring Diagram WISE-4210 Series User Manual...
  • Page 32 WISE-S250 Figure 2.9 WISE-S250 Digital Input Wiring Diagram Figure 2.10 WISE-S250 Digital Output Wiring Diagram WISE-4210 Series User Manual...
  • Page 33 Figure 2.11 WISE-S250 RS-485 Wiring Diagram WISE-4210 Series User Manual...
  • Page 34 WISE-S251 Figure 2.12 WISE-S251 Digital Input Wiring Diagram Figure 2.13 WISE-S251 RS-485 Wiring Diagram WISE-4210 Series User Manual...

  • Page 35: Wise-4210 Node Block Diagram

    WISE-4210 Node Block Diagram Figure 2.14 WISE-4210 Node Block Diagram WISE-4210 Series User Manual...
  • Page 36 WISE-4210 Series User Manual...

  • Page 37: Hardware Installations

    Chapter Hardware Installations...

  • Page 38: Modular Design

    I/O modules via a board-to-board connector. This allows users to install two I/O modules according to their specific usage requirements. Moreover, the modules can be affixed to WISE-4210 using the six screws provided (as shown in Figure 3.1). Figure 3.1 I/O Module Installation WISE-4210 Series User Manual...

  • Page 39: Interface Introduction

    Interface Introduction Figure 3.2 WISE-4210 Interface Introduction WISE-4210 Series User Manual...

  • Page 40: Mounting

    Mounting Like all WISE-4000 series modules, the WISE-4210 series of wireless sensor nodes are designed as compact units. Applicable installation methods are briefly described in the following sections. Figure 3.3 WISE-4000 Series Mounting Kit Dimensions 3.3.1 DIN-Rail Mounting WISE-4210 modules can be fixed to a cabinet with mounting rails. Use a flathead screwdriver to fasten the DIN rail adapter to your module.
  • Page 41 Figure 3.5 DIN-rail Mounting (front) Figure 3.6 DIN-rail Mounting (back) WISE-4210 Series User Manual...

  • Page 42: Wall Mounting

    3.3.2 Wall Mounting The plastic wall-mounting bracket that comes with the module can be used to mount it on a wall, panel, or cabinet. Figure 3.7 Wall Mounting Installation WISE-4210 Series User Manual...
  • Page 43 Figure 3.8 Wall Mounting Installation WISE-4210 Series User Manual...

  • Page 44: Pole Mounting

    Put the pole mounting ring through the middle hole. Note that you should unlock the pole mounting ring with a screw driver before mounting. Mount the WISE-4200 module steadily onto the pole by locking the pole mounting ring tightly. Figure 3.9 Pole Mounting (front) WISE-4210 Series User Manual...

  • Page 45: Wiring And Connections

    200 mV of peak-to-peak power ripple. The immediate ripple voltage should be maintained between +10 and +50 V . The screw terminals labeled "+Vs" and "-Vs" are for the power supply wiring. Figure 3.11 WISE-4210-AP Power Wiring WISE-4210 Series User Manual...

  • Page 46: Battery Installation

    Open the battery cover on the back of module. There are 3 battery sockets for 3.6 VDC AA batteries. Since the batteries are parallel connection, batteries are installed in same direction, positive pole (+) on left and negative pole (-) on right. Figure 3.14 WISE-4210 Battery Socket WISE-4210 Series User Manual...

  • Page 47: I/O Units

    Use the shortest wire length possible  Use wire trays for routing wherever possible  Avoid running wires near to high-energy wiring Avoid running input wiring near output wiring  Avoid creating sharp bends or kinks in the wires  WISE-4210 Series User Manual...
  • Page 48 WISE-4210 Series User Manual...

  • Page 49: System Configuration

    Chapter System Configuration...

  • Page 50: Connection

    USB driver: CP210x USB to UART Bridge VCP Drivers (https:// www.silabs.com/products/development-tools/software/usb-to-uart-bridge-vcp-driv- ers) Figure 4.2 USB configuration port of WISE-4210 node Note! Micro-B USB cable for configuring WISE-4210 nodes is available for ordered:  1700023619-01 1M micro USB type-B male to USB type-A male cable WISE-4210 Series User Manual...

  • Page 51: Configuring Wise-4210-Ap With Browser

    IP Mode: Static  HTTP Port: 80 4.2.3 Module Authorization Account Default Password Access Ability root 00000000 All privileges admin 00000000 All privileges except access control configuration View module status only. user 00000000 Not allow to change configurations WISE-4210 Series User Manual...
  • Page 52 Edit Edit View I/O statuses monitor View View View Reset AI calibration to default Edit Deny Deny MODBUS addresses Edit Edit View Data log configuration and query Edit Edit View Clear data log Edit Edit Deny WISE-4210 Series User Manual...

  • Page 53: Install Wise Studio And Configure End Devices

    USB to UART Bridge VCP Drivers from the following website: https://www.silabs.com/products/development-tools/software/usb-to-uart-bridge-vcp- drivers) Step 6. Click "Connect" to access the end device. Step 7. Once everything is all set, you should be successfully into the configuration page. WISE-4210 Series User Manual...

  • Page 54: Connection Between Ap And Nodes

    Note that each WISE-4210 end node devices in the same net- work should use the same baseband as WISE-4210-AP. Once the network configuration is finished, go to "End Devices \ IO Status" for I/O function configuration. WISE-4210 Series User Manual...

  • Page 55: Wise-4210-Ap Configuration

    Step 4. Enter the IP address of WISE-4210-AP in the browser, or you can keep using WISE Studio to make further configurations. The default account and password of WISE-4210-AP to log into the web page is root and 00000000. Cick "Login". WISE-4210 Series User Manual...
  • Page 56 Baseband (kHz): If several WISE-4210-AP or sub-GHz networks are in the same area, users can select different base bands to reduce the interference of each network. Note that each WISE-4210 end node device in the same network should use the same baseband as WISE-4210-AP. WISE-4210 Series User Manual...

  • Page 57: Setup Wise-4210 Network

    Go to "Configuration \ Modbus \ Modbus ID" to check MAC address of AP and each end node device, and to configure the Modbus ID. Use Modbus/TCP protocol to access each end device by WISE-4210-AP, polling different Modbus ID for different end node devices, or AP. WISE-4210 Series User Manual...
  • Page 58 WISE-4210 Series User Manual...
  • Page 59 Modbus Address Table for WISE-4210-S231 Modbus Address Sensor Input 40501 Temperature 40502 Humidity 45302 RSSI (-dBm) Modbus Address Table for WISE-4210-S250 Modbus Address 00001 00002 00003 00004 00005 00006 01001~01032 RS-458 Coils 41001~41032 RS-458 Registers 45302 RSSI (-dBm) WISE-4210 Series User Manual...

  • Page 60: Push Wise-4210 Data By Restful Web Service

    Push WISE-4210 data by RESTful Web Service Step 1. Configure the Private Server in "Configuration \ Cloud" Step 2. Enable the Data Logger function in "Advanced \ Data Logger \ Logger Configuration" WISE-4210 Series User Manual...

  • Page 61: Access Wise-4210 I/O Data By Restful Api

    "Record" : [0,0,1,0], [0,0,2,50], [0,0,3,10], [0,1,4,0], [0,1,5,456], [0,1,6,0], [0,0,30,0], [0,0,31,16], [0,0,32,32767]  JSON array name definition: Field Abbreviation Data Type Array of I/O records Record Array  Resource value definitions: Field Abbreviation Data Type Property Description WISE-4210 Series User Manual...
  • Page 62 * The data type in array is as follows. [Number, Number, Number, Number] * The information in array is as follows. [Slot-index, Recording Record Array Channel-index, message I/O-type-index, I/O-value] * See I/O Type Index Table for I/O type-index WISE-4210 Series User Manual...
  • Page 63 DI period (counter mode) DI low-to-high trigger tick Expansion bit data Expansion bit error code Expansion word data Expansion word error code Sensor engineering value Sensor maximum engineering value Sensor minimum engineering value Sensor status Sensor alarm status WISE-4210 Series User Manual...
