WISE-2200-M
LoRaWAN RS-485 Modbus I/O Module
Startup Manual

Packing List

Before installation, please ensure that the following items
have been included in your shipment:
1. 1 x WISE-2200-M module
2. 1 x Mounting bracket
3. 1 x Quick start manual
4. 1 x China RoHS declaration (WISE-2200-MNA only)
5. 1 x Antenna
If any of the above items are missing or damaged, contact
your distributor or sales representative immediately.

User Manual

Thank you for purchasing the WISE-2200-M module.
This quick start guide is intended to help you deploy your
new module. The guide contains basic information on the
power and application wiring. Should you require additional
instructions, please refer to the user manual.
For more information on this and other Advantech
products, please visit our website at
http://www.advantech.com
For technical support services, please visit our support
website at
https://www.advantech.com/support
This manual is for the WISE-2200-M.
Part No. 2043220000
Printed in Taiwan
5 – 50 Vdc connect to –VS, +VS channels.
Edition 1
January 2022

Specifications

WISE-2200-M Startup Manual 1
