Advantech PCM-9366 Startup Manual

PCM-9366 Intel Pentium
Intel Atom
®
48-bit LVDS/*eDP, 2GbE, M.2 Key E, Mini PCIe/mSATA,
M.2 Key E, Wide-range Power Input, iManager
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
1. 1 PCM-9366 SBC
2. 1 Startup Manual
3. 1 Audio cable
4. 2 COM cable
5. 1 SATA Power cable
6. mini jumper pack
7. 2 USB Cable
8. 1 SATA cable
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note 1: For detailed contents of PCM-9366, please refer
to Advantech website for detailed information.
Note 2:
Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
http://get.adobe.com/reader/ (Acrobat is a trade-
mark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the PCM-9366 Series Rev. A1
Part No. 2006936600
Printed in China
E3950/E3940/E3930, DDR3L, HDMI, VGA,
p/n: 2006936600
p/n: 1700019584
p/n: 1701200220
p/n: 1700018785
p/n: 1700018730
p/n: 1700008941
1st Edition
June 2020
N4200 Celeron
®
Specifications
General
• CPU: Intel Pentium N4200 Quad-Core 1.1 GHz, burst
frequency 2.4 GHz/ Intel Celeron N3350 Dual-Core 1.1
GHz, burst frequency 2 GHz/ Intel Atom E3950 E3940
Quad-Core 1.6 GHz, burst frequency 1.8 GHz/ Intel Atom
E3930 Dual-Core 1.3 GHz
• System Memory: 1 x 204-pin SODIMM DDR3L 1867
MHz, up to 8 GB
• L2 Cache: 2 MB
• BIOS: AMI uEFI 64 Mbit
• Watchdog Timer: 255 levels timer interval, program-
mable by software. Multi-level WDT (set by iManager)
• Battery: Lithium 3 V/210 mAH
• Audio: High definition audio (HD), line-in, line-out, Mic-in
Expansion Interface
• 1 x Full-size Mini PCIe w/ SIM holder
• MIOe expansion: SMBus, 4 x USB2.0, LPC, 1 x PCIe x1,
line out, +5 Vsb/+12 Vsb, Power On, Reset, DisplayPort
(shared with HDMI/DisplayPort)
• Total peripheral power supply output: 3 A @ 5 V for
PCM-9366 and MI/O Extension module totally, 2 A @ 12
V for MI/O Extension module
Display
• Controller: Intel
• Maximum Resolution:
- VGA: 2560 x 1600
- HDMI/DisplayPort:
* HDMI 1.4a for HD video playback, 1080P at 60Hz
* DisplayPort supported by T-P/N, DP 1.2a with audio,
4096 x 2160
- LVDS/eDP:
* 48-bit LVDS: 1920 x 1200 at 60Hz,
* eDP supported by T-P/N, eDP 1.4 with audio,
4096 x 2160
- Multiple Display: VGA + HDMI+ LVDS/eDP*
Ethernet Interface
• Speed: 10/100/1000 BASE-T
• Controller: Intel® i210
Mechanical and Environmental
• Dimensions: 146 x 102 mm (5.7" x 4")
• Power Supply Type: ACPI support
Power Requirement: 9 (-5%) - 36 (+10%)V, power hot
plug operation (Default support 2-pin Phoenix power
connector)
N3350 &
®
Gen9 Graphic engine
®
PCM-9366 Startup Manual 1
