WALL/SHALLOW BASE UNIT 700 - 800 WALL/SHALLOW BASE Assembly Guide 700 WALL 800 BASE 800 WALL SHALLOW For Internal Use: FI.WR.INS.035_WKIN00125_MULTI_700-800_WALL_ShallowBASE_Rev6.indd...
Page 2
WALL/SHALLOW BASE UNIT BEFORE YOU START 700 - 800 INSTALLATION WALL/SHALLOW BASE SHOULD BE PERFORMED BY A Assembly Guide COMPETENT PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Panel A Panel B Panel C Shelf Frontal x1 Back Panel x2 End Panel x2 Base Panel (packed separately)
Page 3
WALL/SHALLOW BASE UNIT 700 - 800 WALL/SHALLOW BASE Assembly Guide Step 1. Seat dowel (F) Seat (G) into holes in cam dowel end panel (B) as shown. into hole as shown. Step 2. Seat cam dowel (G) into holes in end panel (B) as shown.
Page 4
WALL/SHALLOW BASE UNIT 700 - 800 Seat (G) WALL/SHALLOW BASE cam dowel Assembly Guide into hole as Step 6. shown. Seat dowel (F) into holes in both panels (B) as shown. Step 7. Seat cam dowel (G) into holes in both end panels (B) as shown.
Page 5
WALL/SHALLOW BASE UNIT 700 - 800 WALL/SHALLOW BASE Assembly Guide Step 10. Ensure Carcase is square. Step 11. Slide the back panel clips (T) into the groove of both panels (B) & (C)s. The back panel clips (T) should be evenly spaced as shown and positioned to allow the hanging bracket and corner gussets to be fitted.
Page 6
WALL/SHALLOW BASE UNIT WALL CABINETS ONLY for Shallow Base see pages 7 & 8 700 - 800 Step 13. Hanging Brackets steps a,b & c to be carried WALL/SHALLOW BASE out on both sides as shown Assembly Guide Care to be taken. Hanging procedure is neccesary for a safe installation.
Page 7
WALL/SHALLOW BASE UNIT WALL CABINETS ONLY Step 16. 700 - 800 Measure appropriately and attach the 2 x hanging bracket plates onto the WALL/SHALLOW BASE wall screwing through the provided holes into your wall. Assembly Guide Screws for fixing to walls are not provided as these vary depending on your wall material and construction.
Page 8
WALL/SHALLOW BASE UNIT SHALLOW BASE CABINETS ONLY for WALL see pages 5 & 6 700 - 800 WALL/SHALLOW BASE Assembly Guide Corner Gusset Detail Step 20. Secure Corner Gussets to the top left and right hand side of the wall unit using 4 x 15mm screws (L) per plate.
Page 9
WALL/SHALLOW BASE UNIT SHALLOW BASE CABINETS ONLY 700 - 800 Step 23. WALL/SHALLOW BASE Secure each of the legs into place with 4 x 15mm Assembly Guide Screws (L) per leg base. FRONT Ensure legs are rotated as shown so that part of it is supporting the end panels (B).
Page 10
WALL/SHALLOW BASE UNIT Step 25. Insert hinge in top & bottom 700 - 800 holes as shown. WALL/SHALLOW BASE Assembly Guide Step 26. Secure hinges by tightening 2 x screws with hinge dowels attached. These are already positioned within the hinges. Hinge Plates Step 27.
Page 11
WALL/SHALLOW BASE UNIT 700 - 800 WALL/SHALLOW BASE Assembly Guide For Internal Use: FI.WR.INS.035_WKIN00125_MULTI_700-800_WALL_ShallowBASE_Rev6.indd Page 10...
Page 12
WALL/SHALLOW BASE UNIT 700 - 800 WALL/SHALLOW BASE Assembly Guide Page 11 For Internal Use: FI.WR.INS.035_WKIN00125_MULTI_700-800_WALL_ShallowBASE_Rev6.indd...
