Summary of Contents for Wren 700
- Page 1 WALL UNIT 700 - 800 2 Door Assembly Guide For Internal Use: FI.WR.INS.035_WKIN00125_WALL_700 _800_2Door_Rev4.indd...
- Page 2 WALL UNIT BEFORE YOU START 700 - 800 2 Door INSTALLATION Assembly Guide SHOULD BE PERFORMED BY A COMPETENT PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Panel A Panel B Panel C Shelf Frontal x1 Back Panel...
- Page 3 WALL UNIT 700 - 800 2 Door Step 1. Seat dowel (F) Assembly Guide into holes in end panel (B) as shown. Seat (G) cam dowel into hole as shown. Step 2. Seat cam dowel (G) into holes in end panel (B) as shown.
- Page 4 WALL UNIT 700 - 800 2 Door Step 6. Seat dowel (F) into Assembly Guide holes in both panels (B) as shown. Seat (G) cam dowel Step 7. into hole as shown. Seat cam dowel (G) into holes in both end panels (B) as shown.
- Page 5 WALL UNIT Step 10. 700 - 800 2 Door Ensure carcass is square. Assembly Guide Step 11. Slide the back panel clips (T) into the groove of both panels (B) & (C). The back panel clips (T) should be evenly spaced as shown and positioned to allow the hanging bracket and corner gussets to be fitted.
- Page 6 WALL UNIT 700 - 800 2 Door Assembly Guide Step 13. Step 13a. Step 13b. Step 13c. Insert hanging Rotate locking Secure with provided bracket into pre-drilled lever 180 degrees 2 x 20mm screws (S) per bracket holes Step 14.
- Page 7 WALL UNIT Step 16. 700 - 800 2 Door Measure appropriately and attach the 2 x hanging bracket plates Assembly Guide onto the wall screwing through the provided holes into your wall. Screws for fixing to walls are not provided as these vary depending on your wall material and construction.
- Page 8 WALL UNIT Step 19. 700 - 800 2 Door Insert hinge in top & bottom Assembly Guide holes as shown. Hinges Step 20. Secure hinges by tightening 2 x screws with hinge dowels attached. These are already positioned within the hinges.
- Page 9 WALL UNIT 700 - 800 2 Door Assembly Guide...
- Page 10 WALL UNIT 700 - 800 2 Door Assembly Guide...
- Page 11 WALL UNIT 700 - 800 2 Door Assembly Guide...
