- Page 1 WALL UNIT 700 - 800 Tall 2 Door Assembly Guide 700 Tall 800 Tall For Internal Use: FI.WR.INS.046_WKIN00131_WALL_700-800_2Dr_Tall_Rev3.indd...
- Page 2 WALL UNIT BEFORE YOU START 700 - 800 Tall 2 Door INSTALLATION Assembly Guide SHOULD BE PERFORMED BY A COMPETENT PERSON ONLY. THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED Panel A Panel B Panel C Loose Shelf Frontal x1 Back Panel x2 End Panel x2 Base Panel (packed separately)
- Page 3 WALL UNIT 700 - 800 Tall 2 Door Step 1. Seat dowel (F) Assembly Guide into holes in Seat (G) end panel (B) as cam dowel shown. into hole as shown. Step 2. Seat cam dowel (G) into holes in end panel (B) as shown.
- Page 4 WALL UNIT 700 - 800 Tall 2 Door Step 6. Seat dowel (F) Assembly Guide into holes in both panels (B) as Seat (G) cam dowel shown. into hole as shown. Step 7. Seat cam dowel (G) into holes in both end panels (B) as shown.
- Page 5 WALL UNIT 700 - 800 Tall 2 Door Step 10. Assembly Guide Ensure carcass is square. Step 11. Slide the back panel clips (T) into the groove of both panels (B) & (C)s. The back panel clips (T) should be evenly spaced as shown and positioned to allow the hanging bracket and corner gussets to be fitted.
- Page 6 WALL UNIT Step 13. Hanging Brackets steps a,b & c to be carried out on both 700 - 800 Tall 2 Door sides as shown Assembly Guide Detail A Detail A Detail A Step a Step b Step c Insert Hanging Rotate locking Secure with provided Bracket into pre-drilled holes...
- Page 7 WALL UNIT Step 16. Measure appropriately and attach the 2 x hanging bracket plates onto the 700 - 800 Tall 2 Door wall screwing through the provided holes into your wall. Assembly Guide Screws for fixing to walls are not provided as these vary depending on your wall material and construction.
- Page 8 WALL UNIT 700 - 800 Tall 2 Door Assembly Guide Step 19. Insert hinge in top & bottom holes as shown. Step 20. Secure hinges by tightening 2 x screws with hinge dowels attached. These are already positioned within the hinges. Step 21.
