begin.
•
The print head begins to measure at the front in the middle point. At the
bottom of the screen, you can see the scale of the deviation.
•
If the deviation is large, the dashes are dense and several
arrows indicate which direction the knob under the
current position is rotated will result in a better reading.
•
For smaller deviations, the stripe is more scattered and
only one arrow indicates the rotateing direction.
•
To achieve optimum value, the meter should be wrapped
between two prominent lines.
•
After 3 optimal measurements, the NEXT button
appears. If one or more of the 3 measurements is out of range, the
calibration will not continue and will need to be adjusted on the button.
•
After pressing the NEXT button, the head is positioned above the back
right button and then above the back left button screw.
•
Repeat the procedure for the other buttons.
•
Mesh bed
•
Both calibrations are performed by the printer without external intervention or
adjustment.
